Cold-Drawn Hastelloy X Round Bar with Polished Surface for High-Temperature Resistance

  • Cold-Drawn Hastelloy X Round Bar with Polished Surface for High-Temperature Resistance
  • Cold-Drawn Hastelloy X Round Bar with Polished Surface for High-Temperature Resistance
  • Cold-Drawn Hastelloy X Round Bar with Polished Surface for High-Temperature Resistance
  • Cold-Drawn Hastelloy X Round Bar with Polished Surface for High-Temperature Resistance
  • Cold-Drawn Hastelloy X Round Bar with Polished Surface for High-Temperature Resistance
  • Cold-Drawn Hastelloy X Round Bar with Polished Surface for High-Temperature Resistance
Certification ISO, ASTM, EN, DIN
Quantité de commande min 50 kg
Détails sur le produit
Diamètre 10 - 350mm Longueur À moins de 6m
Traitement de surface Brillant Résistance à la traction Minimum 760 MPa
Limite d'élasticité Minimum 380 MPa Élongation Minimum 30%
Réduction de la superficie Minimum 40 % Dureté 200 - 240 HB (laminé à chaud), 230 - 280 HB (étiré à froid)
Résistance à haute température 450 MPa à 800°C, 280 MPa à 1000°C Résistance à la rupture par fluage 180 MPa à 800°C, 80 MPa à 1000°C
Température de fonctionnement Jusqu'à 1 200 °C en continu, 1 300 °C à court terme Finition de surface Ra ≤ 1,6 μm
Tolérance dimensionnelle ± 0,05 mm Contenu en nickel 47,0% - 50,0%
contenu de chrome 20,5% - 23,0%
Mettre en évidence

High-Temperature Resistance Hastelloy X Round Bar

,

Cold-Drawn Technique Nickel Alloy Round Bar

,

Polished Surface Super Alloy Round Bar
Laisser un message
Description de produit
Hot Rolled and Cold Drawn Hastelloy X Round Bar
High-performance nickel-chromium-iron-molybdenum superalloy round bar designed for extreme high-temperature applications with exceptional mechanical properties and corrosion resistance.
Product Specifications
Product Name Hastelloy X Round Bar
Diameter 10 - 350mm
Length Custom cutting to requested length
Surface Bright, Black, Pickling, Polishing
Brand DELTA
Service Cutting, Polishing
MOQ 2 Kgs
Other Types Bar, Strip, Coil, Pipe, Sheet, Plate, Wire, etc.
Packing Wooden Box
Loading Port Shanghai Port
Price Term EXW, FOB, CIF, CFR
Delivery Time Within 12 days
Material Overview
Hastelloy X is a nickel-chromium-iron-molybdenum superalloy renowned for exceptional performance in high-temperature environments. The hot rolled and cold drawn Hastelloy X round bar combines excellent mechanical properties, chemical stability, and processing versatility for reliable performance under extreme heat conditions.
Chemical Composition
Precisely controlled composition ensuring outstanding high-temperature resistance and corrosion resistance:
  • Nickel (Ni): 47.0% - 50.0% (base element providing excellent ductility and thermal fatigue resistance)
  • Chromium (Cr): 20.5% - 23.0% (enhances oxidation resistance and high-temperature corrosion resistance)
  • Iron (Fe): 17.0% - 20.0% (improves strength and processability while maintaining cost-effectiveness)
  • Molybdenum (Mo): 8.0% - 10.0% (boosts high-temperature strength and resistance to pitting corrosion)
  • Cobalt (Co): 0.5% - 2.5% (improves high-temperature creep strength and thermal stability)
  • Tungsten (W): 0.2% - 1.0% (enhances high-temperature strength and hardness)
  • Carbon (C): Maximum 0.10% (controls carbide formation to avoid brittleness)
  • Silicon (Si): Maximum 1.0% (assists in deoxidation and improves oxidation resistance)
  • Manganese (Mn): Maximum 1.0% (enhances workability and toughness)
  • Phosphorus (P): Maximum 0.04% (prevents brittleness at high temperatures)
  • Sulfur (S): Maximum 0.03% (minimizes harmful sulfide inclusions)
Mechanical Properties
Optimized mechanical properties through hot rolled and cold drawn processes:
  • Tensile Strength (σb): Minimum 760 MPa (increases 10-15% after cold drawing)
  • Yield Strength (σ0.2): Minimum 380 MPa (420-480 MPa after cold drawing)
  • Elongation (δ5): Minimum 30% (maintains above 20% after cold drawing)
  • Reduction of Area (ψ): Minimum 40% (excellent toughness and fracture resistance)
  • Hardness (HB): Hot rolled: 200-240 HB; Cold drawn: 230-280 HB
  • High-Temperature Performance: 800°C tensile strength above 450 MPa; 1000°C tensile strength around 280 MPa
Key Features
Excellent High-Temperature Resistance
Withstands continuous operating temperatures up to 1200°C and short-term exposure to 1300°C. Resists oxidation, carburization, and nitridation in high-temperature atmospheres.
Superior Mechanical Stability
Refined grain structure with low thermal expansion coefficient and excellent thermal fatigue resistance under cyclic heating and cooling conditions.
Outstanding Corrosion Resistance
Excellent resistance to dilute sulfuric acid, hydrochloric acid, and organic acids in high-temperature and corrosive environments.
Good Processability
Hot rolled bars offer good plasticity for forging and welding; cold drawn bars provide high dimensional accuracy (±0.05 mm) and smooth surface finish (Ra ≤ 1.6 μm).
Long Service Life
Excellent resistance to high-temperature creep, thermal fatigue, and corrosion ensures stable performance in harsh conditions, reducing maintenance frequency.
Applications
Aerospace Industry
Manufacture of high-temperature components in aircraft engines including turbine blades, turbine disks, combustion chambers, and afterburners. Also used in rocket engines and space shuttle structural parts exposed to extreme temperatures during launch and re-entry.
Energy Industry
High-temperature components for gas turbines in power plants including rotor shafts, stator blades, and combustion chambers. Applications in nuclear power industry for heat exchanger tubes and reactor structural parts.
Petrochemical Industry
Production of high-temperature and high-pressure valves, fittings, and pipelines. Manufacture of catalyst supports and reactor internals for chemical synthesis processes.
Other High-Temperature Applications
Heating elements, furnace linings, and structural parts for industrial heating furnaces. High-performance exhaust system components for automotive applications requiring thermal fatigue resistance.
