ASTM A106 DIN2391 Q195 St37 Seamless Steel Pipe Carbon Steel Tube for High Precision Applications

Minimum Order Quantity	1 Ton
Price	US $650-1,350 / Ton

Product Details

Model NO.	A106 DIN2391 Q195 St37	Surface Treatment	Black
Section Shape	Round	Outer Diameter	6-630mm
Material	Carbon Steel And Alloy Steel	Surface Finish	Oiled, Polished, Brightness, Metallic Color
Craft	Cold Rolled And Cold Drawn	Size Range	OD:8mm-100mm, WT:1-8mm
Length	Customized	Tolerance	Cold Drawn Pipe: +/-0.1mm, Cold Rolled Pipe: +/-0.05mm
Steel Grade	St35, St45, St52, E215, E235, E355, Sch10, Sch20, A106, A179, A192, A210, T11, T22, T12, AISI4130, SAE1010, SAE1020	Wall Thickness	SCH10... STD, SCH40, SCH80... SCH160, XS, XXS
Tensile Strength	≥415-570 Mpa	Yield Strength	≥245-485 Mpa
Production Capacity	50000kgs
Highlight	ASTM A106 Seamless Steel Pipe , DIN2391 Carbon Steel Pipe , Q195 St37 Steel Tube

Leave a Message

Product Description

ASTM A106 DIN2391 Q195 St37 Seamless Steel Pipe Carbon Steel Pipe

Product Overview

High-precision seamless steel pipes manufactured using cold rolled and cold drawn processes for demanding industrial applications.

Product Name	Seamless Steel Pipe
Material	Carbon Steel and Alloy Steel
Surface Finish	Oiled, Polished, Brightness, Metallic Color
Manufacturing Process	Cold Rolled and Cold Drawn
Size Range	OD: 8mm-100mm, WT: 1-8mm
Length	Customized
Tolerance	Cold Drawn Pipe: ±0.1mm, Cold Rolled Pipe: ±0.05mm
Applications	Gas Spring, Shock Absorber, Cylinder and other High Precision Areas

Standards & Grades

Standards: ASTM A106, A53, A192, A179, A210, A519, DIN17175, 1629, 2391, EN10216-1, 10216-2, 10305-1

Grades: St35, St45, St52, E215, E235, E355, sch10, sch20, A106, A179, A192, A210, T11, T22, T12, AISI4130, SAE1010, SAE1020

Applications of Seamless Steel Pipes

Seamless steel pipes are manufactured through hot rolled and cold drawn processes, with hot rolled pipes offering superior strength. These pipes are essential for various industrial applications including:

Steam Pipeline Systems
Gas Pipeline Networks
Liquefied Gas Pipeline Infrastructure
Natural Gas Transmission Lines
Petroleum Product Transportation
Various Gas and Liquid Conveyance Systems

Technical Specifications

Standard: API5L PSL 1 & PSL 2
Steel Grade Range: GrB to X70
Size and OD: 1/2"-152" (21.3mm-3800mm)
Wall Thickness: SCH10, STD, SCH40, SCH80, SCH160, XS, XXS

Standard	Steel Grade	C	Mn	Cr	Mo	P	S	Ni	Cu	Tensile Strength (Mpa)	Yield Strength (Mpa)
API Spec 5L PLS1	B	≤0.28	≤1.20	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥415	≥245
	X42	≤0.28	≤1.30	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥415	≥290
	X46	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥435	≥320
	X52	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥460	≥360
	X56	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥490	≥390
	X60	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥520	≥415
	X65	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥535	≥450
	X70	≤0.28	≤1.40	≤0.50	≤0.15	≤0.030	≤0.030	≤0.50	≤0.50	≥570	≥485
