20# S20C Seamless Steel Tube Pipe ASTM EN DIN GB Standard SAE1020
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Carbon Steel , Alloy Steel |
| Minimum Order Quantity | 2 Tons |
| Price | 600 - 800 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, Western Union, T/T |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Seamless Steel Pipe | Diameter | DN10 - DN600 |
|---|---|---|---|
| Thickness | 1.0 - 50.0mm | Length | 6-10m Or Cutting As Request |
| Standard | ASTM EN GB DIN | Technique | Hot Rolled |
| Service | Cutting | MOQ | 2 Ton |
| Highlight | S20C seamless steel tube pipe,20# seamless steel tube pipe,SAE1020 seamless steel tube |
||
Product Description
ASTM EN DIN GB Standard SAE1020 20# Steel Pipe / Seamless Pipe S20C Steel Seamless Tube
|
Product name
|
Carbon steel pipe
|
|
Material
|
10#, 20#, 45#, 16Mn, A53(A,B), Q235, Q345, Q195, Q215, St37, St42, St37-2, St35.4, St52.4, ST35
|
|
Wall Thickness
|
4.5MM~60MM
|
|
Outer Diameter
|
21.3MM~762MM
|
|
Length
|
Length:Single random length/Double random length
5m-14m,5.8m,6m,10m-12m,12m or as customer's actual reques |
|
Standard
|
API 5L, ASTM A53-2007, ASTM A671-2006, ASTM A252-1998, ASTM A450-1996, ASME B36.10M-2004, ASTM A523-1996, BS 1387, BS EN10296, BS
6323, BS 6363, BS EN10219, GB/T 3091-2001, GB/T 13793-1992, GB/T9711 |
|
Grade
|
10#-45#, 16Mn, A53-A369, Q195-Q345, ST35-ST52
Grade A, Grade B, Grade C |
|
Section Shape
|
Square, Rectangular, Round,
|
|
Pipe Ends
|
Plain end/Beveled,protected by plastic caps on both ends, cut quare,grooved,threaded and coupling,etc.
|
|
Surface Treatment
|
1. Galvanized
2. PVC,Black and color painting 3. Transparent oil,anti-rust oil 4. According to clients requirement |
|
Product Application
|
1. Fence, greenhouse, door pipe,greenhouse
2. Low pressure liquid, water, gas, oil, line pipe 3. For both indoor and outdoor the building construction 4. Widely used in scaffolding construction which is much cheaper and convenient |
1020 steel pipe is a low carbon (non-alloy) steel pipe that offers better mechanical and physical property like weldability, ductility and high corrosion resistance, commonly used the automotive, mechanical and construction application.
The 1020 steel has a carbon content up to 0.28 percent according to AISI, SAE and ASTM standards. ASTM A512, A513 and A519 which can be used to specified mechanical tubing. ASTM A513 specified for Resistance Welded (ERW) carbon and alloy Electric mechanical tubing, while ASTM A512 covers cold drawn buttweld carbon steel mechanical tubing, ASTM A519 is a standard specification for Seamless Carbon and Alloy Steel Mechanical Tubing. Grade 1020 belong to ASTM A513 and ASTM A513 is a commonly used grades of mechanical steel tubing.
1020 Steel Pipe Chemical Composition:
| C | Mn | P | S | Fe |
| 0.17 – 0.23 | 0.3 – 0.6 | ≤ 0.04 | ≤ 0.05 | 99.0 – 99.5 |
1020 Steel Pipe Mechanical Property:
| Tensile Strength | Yield strength | Brinell hardness |
| 420 Mpa | 350 Mpa | 121 |
1020 Cold drawn seamless tubing is finished in “as drawn” treatment condition. It offers good surface quality and increased mechanical properties compared with hot finished seamless tubing according to ASTM A519.
1020 hot finished seamless tubing is most applicable and lower in cost than cold drawn where precise dimensions and surface quality are of secondary importance. Meets ASTM A519 which either hot-finished or cold-finished.
1020 DOM (Drawn –over-mandrel) tubing is a cold drawn electric resistance welded tube meets ASTM A513 Type 5.
1020 buttweld tubing is electric resistance welded tubing is normalized and cold drawn over a mandrel for improved mechanical properties, surface finish and controlled tolerances, specified in ASTM A512 for pressure applications
