EN 1.0832 Alloy Steel Seamless Tubes ASTM A210-C St52.4
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Carbon Steel , Alloy Steel |
| Minimum Order Quantity | 2 Tons |
| Price | 600 - 800 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, Western Union, T/T |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Seamless Steel Pipe | Diameter | DN10 - DN600 |
|---|---|---|---|
| Thickness | 1.0 - 50.0mm | Length | 6-10m Or Cutting As Request |
| Standard | ASTM EN GB DIN | Technique | Hot Rolled |
| Service | Cutting | MOQ | 2 Ton |
| Highlight | EN 1.0832 alloy steel seamless tubes,alloy steel seamless tubes ASTM,St52.4 alloy steel tubes |
||
Product Description
ASTM A210-C Seamless Steel Pipe Steel Pipe St52.4 EN 1.0832 Steel Pipe Seamless Pipe Tube
Description Name: ASME SA210 / ASTM A210 Grade C boiler pipes; A210 Grade C pipes; A210 carbon steel tube; ASTM A210 seamless tubing; ASTM A210 carbon steel pipe; SA210 SEAMLESS PIPE; ASTM A210 cold drawn seamless steel tubes; ASTM A210 pipes and tubing; carbon steel tube; Seamless steel tube; steel tube.
Size: 1⁄2 in. to 16 in. [12.7 to 406.4mm]
W.T.: 1.5mm-50mm
Shape: Round
Production Type: Hot finished and cold finished.
Length: Single random length/ Double random length or as customer’s actual request max length is 25m
Grade: Grade C
Heat Treatment: Hot-finished tubes need not be heat treated. Cold- finished tubes shall be given a subcritical anneal, a full anneal, or a normalizing heat treatment after the final cold finishing process.
Test requirement:
ASTM A210 / A210M Grade C Chemical Compositions
| Chemical Components (%) | ||||||||
| Grade | C | Si | Mn | P | S | Mo | Cr | V |
| C | ≤0.35 | ≥0.10 | 0.29-1.06 | ≤0.035 | ≤0.035 | / | / | / |
ASTM A210 / A210M Grade C Mechanical Tests Required
| Mechanical Properties | ||||
| Grade | Tensile
Strength (Mpa) |
Yield
Strength (Mpa) |
Elongation
(%) |
Hardness
(HRB) |
| C | ≥485 | ≥275 | ≥30 | ≤89 |
ASTM A210 / A210M Tube Wall Thickness Tolerance
| Seamless, Cold-Finished Tubes | ||
|
Outside Diameter In. (mm) |
Wall thickness Tolerance % | |
| Over (+) | Under (-) | |
| 1 ½ (38.1) and under | 20 | 0 |
| Over 1½ (38.1) | 22 | 0 |
ASTM A210 / A210M Tube Outside Diameter Tolerance
| Cold-Finished Seamless Tubes | ||
|
Outside Diameter In. (mm) |
Permissible Variations In. (mm) | |
| Over (+) | Under (-) | |
| Under 1 (25.4) | 0.004 (0.10) | 0.004 (0.10) |
| 1 to 1 ½ (25.4 to 38.1), Incl | 0.006 (0.15) | 0.006 (0.15) |
| Over 11⁄2 to 2 (38.1 to 50.8), Excl | 0.008 (0.20) | 0.008 (0.20) |
| 2 to 21⁄2 (50.8 to 63.5), Excl | 0.010 (0.25) | 0.010 (0.25) |
| 21⁄2 to 3 (63.5 to 76.2), Excl | 0.012 (0.30) | 0.012 (0.30) |
ASTM A210 / A210M Tube Cut Length Tolerance
| Cold-Finished Seamless Tubes | ||
| Outside Diameter, In.(mm) |
Cut Length, in.(mm) | |
| Over (+) | Under (-) | |
| All Sizes | 3⁄16 [5] | 0 [0] |
| Under 2 (50.8) | 1⁄8 [3] | 0 [0] |
| 2 (50.8) and over | 3⁄16 [5] | 0 [0] |
| Under 2 (50.8) | 1⁄8 [3] | 0 [0] |
| 2 (50.8) and over | 3⁄16 [5] | 0 [0] |
| These permissible variations in length apply to tubes before bending. They apply to cut lengths up to and including 24 ft [7.3 m]. For lengths greater than 24 ft [7.3 m], the above over-tolerances shall be increased by 1⁄8 in. [3 mm] for each 10 ft [3 m] or fraction thereof over 24 ft or 1⁄2 in. [13 mm], whichever is the lesser. | ||
ASTM A210 / A210M Tube Hydrostatic Test Pressures
Each tube shall be subjected to the hydrostatic pressure test, or instead of this test, a nondestructive test may be used when specified by the purchaser.
| Hydrostatic Test Pressures | |
| Outside Diameter of Tube, in. [mm] | Hydrostatic Test Pressure, psi [MPa] |
| Under 1 [25.4] | 1000 [7] |
| 1 to 11⁄2 [25.4 to 38.1], excl | 1500 [10] |
| 11⁄2 to 2 [38.1 to 50.8], excl | 2000 [14] |
| 2 to 3 [50.8 to 76.2], excl | 2500 [17] |
ASTM A210 / A210M Flattening Test
One flattening test shall be made on specimens from each end of one finished tube from each lot, but not the one used for the flaring test. Tears or breaks occurring at the 12 or 6 o’clock positions on Grade C tubing with sizes of 2.375 in. [60.3 mm] in outside diameter and smaller shall not be considered a basis for rejection.
ASTM A210 / A210M Flaring Test
One flaring test shall be made on specie- men from each end of the one finished tube from each lot, but not the one used for the flattening test.
Ordering Information
Orders for ASTM A210 / A210M, ASME SA210 should include the following, as required, to describe the desired material adequately:
- Quantity (feet, meters, or number of lengths),
- Name of material (seamless tubes),
- Grade,
- Manufacture (hot-finished or cold-finished),
- Size (outside diameter and minimum wall thickness),
- Length (specific or random),
- Optional requirements,
- Test report required (see section on Certification of Specification A 450/A 450M),
- Specification designation,
- Special requirements.
Note:
- Mill test certificates will be issued according to EN10204.3 3.1 or 3.2
- The tubes Shall be Seamless, and the testing shall be as per A 450 / A450M.
Application:
Apply to Boiler Tubes, Seamless Steel Tubes, Steel Tubes, and Superheater Tubes.
Packing:
Packed in wooden box or bundles protected with plastic paper, and suitably protected for sea-worthily delivery or as requested.
The Product marking shall include the ASTM A210 or ASME SA210, size, heat no., Lot No. and Manufacture name or logo.
