API 5L ASTM A106 Cold Drawn Seamless Steel Pipe for High Precision Applications
Product Details
| Outer Diameter | 6-630mm | Surface Treatment | Black |
|---|---|---|---|
| Material | Carbon Steel And Alloy Steel | Production Capacity | 50000kgs |
| Cold Drawn Tolerance | +/-0.1mm | Cold Rolled Tolerance | +/-0.05mm |
| Tensile Strength | ≥415-570 Mpa | Yield Strength | ≥245-485 Mpa |
| Carbon Content | ≤0.28 | Manganese Content | ≤1.20-1.40 |
| Chromium Content | ≤0.50 | Molybdenum Content | ≤0.15 |
| Phosphorus Content | ≤0.030 | Sulfur Content | ≤0.030 |
| Nickel Content | ≤0.50 | ||
| Highlight | API 5L Seamless Steel Pipe,ASTM A106 Carbon Steel Pipe,Cold Drawn API 5L Pipe |
||
Product Description
Seamless Pipe API 5L/ASTM A106/ASTM A53 Carbon Steel Pipe
Product Overview
High-precision seamless steel pipes manufactured through cold rolled and cold drawn processes for demanding industrial applications.
| Product Name | Seamless steel pipe |
| Material | Carbon Steel and Alloy Steel |
| Surface | Oiled, Polished, Brightness, Metallic color |
| Standards | ASTM A106 A53 A192 A179 A210 A519, DIN17175 1629 2391, EN10216-1 10216-2 10305-1 |
| Grades | St35, St45, St52, E215, E235, E355, sch10, sch20, A106, A179, A192, A210, T11, T22, T12, AISI4130, SAE1010, SAE1020 |
| Manufacturing Process | Cold rolled and Cold drawn |
| Size Range | OD: 8mm-100mm, WT: 1-8mm |
| Length | Customized |
| Tolerance | Cold drawn pipe: +/-0.1mm, Cold rolled pipe: +/-0.05mm |
| Applications | Gas spring, Shock absorber, Cylinder and other high precision areas |
Seamless Pipe Applications
Seamless steel pipes are manufactured through hot rolled and cold drawn technologies, with hot rolled pipes offering superior strength. These pipes are essential for various industrial applications including:
- Steam pipeline systems
- Gas pipeline networks
- Liquefied gas pipeline infrastructure
- Natural gas pipelines
- Petroleum product transportation
- Various other gas and liquid conveyance systems
Technical Specifications
| Standard | Steel Grade | Chemical Components | Mechanical Properties |
|---|---|---|---|
| API Spec 5L PSL1 | B | C≤0.28, Mn≤1.20, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 | Tensile: ≥415 MPa, Yield: ≥245 MPa |
| X42 | C≤0.28, Mn≤1.30, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 | Tensile: ≥415 MPa, Yield: ≥290 MPa | |
| X46 | C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 | Tensile: ≥435 MPa, Yield: ≥320 MPa | |
| X52 | C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 | Tensile: ≥460 MPa, Yield: ≥360 MPa | |
| X56 | C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 | Tensile: ≥490 MPa, Yield: ≥390 MPa | |
| X60 | C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 | Tensile: ≥520 MPa, Yield: ≥415 MPa | |
| X65 | C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 | Tensile: ≥535 MPa, Yield: ≥450 MPa | |
| X70 | C≤0.28, Mn≤1.40, Cr≤0.50, Mo≤0.15, P≤0.030, S≤0.030, Ni≤0.50, Cu≤0.50 | Tensile: ≥570 MPa, Yield: ≥485 MPa |
