ASTM En Standard CuZn40 Brass Rod - Corrosion Resistant High Strength Excellent Machinability Round Bar
Product Details
| Model NO. | CuZn40 | Shape | Round |
|---|---|---|---|
| Diameter | 5 - 180mm | Length | 3m 4m 6m Or As Request |
| Other Shape | Flat, Square, Hexagonal | Material | C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,C10930,C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,C12500,C14200,C14420,C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,C26000,C27000,C27400,C28000,C33000,C33200,C37000,C443 |
| Standard | ASTMB152,B187,B133,B301,B196,B441,B465,JISH3250-2006,GB/T4423-2007 | Tensile Strength | 360 MPa, Min |
| Yield Strength | 140 MPa, Min | Elongation | 52%, Min |
| Hardness | 78 HRB, Max | Density | 8.0 G/cm³ |
| Melting Point | 900 °C [1652 °F] | Modulus Of Elasticity | 100 GPa |
| Thermal Conductivity | 120 W/m·K | ||
| Highlight | Corrosion Resistant Brass Rod,High Strength CuZn40 Brass Bar,Excellent Machinability ASTM Brass Round Bar |
||
Product Description
ASTM EN GN Standard Brass Bar Round Square Brass Rod CuZn40
High-quality brass bars and rods manufactured to international standards including ASTM B152, B187, B133, and others. Available in round and square profiles with excellent mechanical properties and corrosion resistance.
Product Specifications
| Item | Brass bar, brass rod |
| Material | C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910, C10920, C10930, C11000, C11300, C11400, C11500, C11600, C12000, C12200, C12300, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000, C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800, C63020, C65500, C68700, C70400, C70620, C71000, C71500, C71520, C71640, C72200, etc. |
| Standard | ASTM B152, B187, B133, B301, B196, B441, B465, JIS H3250-2006, GB/T4423-2007, etc. |
| Diameter | 3mm ~ 800mm |
| Length | 5.8m, 6m, or as required |
Material Description - UNS C28000 Brass
UNS C28000 brass, also known as Muntz metal, is a copper-zinc alloy containing approximately 60% copper and 40% zinc. This versatile material offers excellent corrosion resistance, high strength, good ductility, and superior machinability. Its bright yellow appearance makes it suitable for both functional and decorative applications.
Chemical Composition (%)
| Element | Composition |
|---|---|
| Cu | 59.00-63.00 |
| Fe, max | 0.070 |
| Zn | 36.30-41.00 |
| Pb, max | 0.30 |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength, MPa, min | 360 |
| Yield Strength, MPa, min | 140 |
| Elongation (%), min | 52 |
| Hardness, max | 78 HRB |
Physical Properties
| Property | Value |
|---|---|
| Density | 8.0 g/cm³ |
| Melting Point | 900 °C [1652 °F] |
| Modulus of Elasticity | 100 GPa |
| Poisson's Ratio | 0.31 |
| Coefficient of Thermal Expansion | 21 µm/m·K |
| Thermal Conductivity | 120 W/m·K |
| Electrical Conductivity | 28% IACS |
Key Features
- Excellent corrosion resistance
- High strength and good ductility
- Superior machinability and weldability
- Good electrical and thermal conductivity
- Excellent formability and stamping performance
- Good wear resistance with low friction properties
- Resistance to rust and oxidation
Applications
UNS C28000 brass is widely used across multiple industries due to its excellent corrosion resistance and mechanical properties:
- Screws, bolts, nuts and fasteners
- Taps, valves and plumbing fixtures
- Electrical components and connectors
- Marine propellers, shafts and accessories
- Door handles, hinges, locks and architectural hardware
- Musical instruments
- Gears, bearings and mechanical components
- Coins, medals and decorative items
Equivalent Grades
| Standard | Designation |
|---|---|
| UNS | C28000 |
| WERKSTOFF NR. | 2.0360 |
| DIN | CuZn40 |
| JIS | C2801 |
| BS | CZ109 |
| EN | CW509L |
Export & Packaging
We export worldwide to Singapore, India, Iran, Indonesia, Ukraine, Spain, Korea, Thailand, Canada, USA, Ireland, Saudi Arabia, Vietnam, England, Egypt, Oman, and other countries. Standard export seaworthy packaging suitable for all transport methods. Available price terms: Ex-Work, FOB, CNF, CFR, CIF.
