CuZn37 / C27200 Brass Round Bar ASTM Standard Copper Bar with 4-200mm Diameter
Product Details
| Model NO. | CuZn37 / C27200 | Shape | Round |
|---|---|---|---|
| Diameter | 4 - 200mm | Length | 4-6m Or Cutting Any Length As Request |
| Other Shape | Square, Flat, Hexagonal | Density | 8.5g/cm3 |
| Hardness | 1/16 Hard,1/8 Hard,3/8 Hard,1/4 Hard,1/2hard,full Hard,soft | Chemical Composition Zn | Remains |
| Chemical Composition Cu | 63 | Chemical Composition Pb | 0.05 Max |
| Chemical Composition Sn | 0.2 Max | Electrical Conductivity | 26%IACS |
| Thermal Conductivity | 120 W/m.K | Modulus Of Elasticity | 110 Kn/mm² |
| Melting Temperature | 910 - 950°C | ||
| Highlight | CuZn37 / C27200 Brass Round Bar,ASTM Standard Copper Bar,4-200mm Diameter Brass Rod |
||
Product Description
CuZn37 / C27200 Brass Round Bar Chemical Composition & Specifications
Comprehensive technical data for CuZn37 / C27200 brass round bars, rods, shafts, and sticks with detailed chemical composition and material properties.
Product Specifications
| Product Type | Brass Bar, Brass Rod, Brass Shaft, Brass Stick |
| Standards | ASTM, AISI, EN, BS, JIS, GB/T, BSI, AS/NZS, ISO, etc. |
| Material Grades | H96, H90, H85, H80, H70, H68, H65, H63, H62, H60, C21000, C22000, C23000, C24000, C26000, C26800, C27000, C27200, C28000, C35000, etc. Or as required |
| Surface Finish | Mill, polished, bright, oiled, or as required |
| Density | 8.5 g/cm³ |
| Diameters | 1-200mm |
| Hardness | 1/16 hard, 1/8 hard, 3/8 hard, 1/4 hard, 1/2 hard, full hard, soft, etc. |
| Shapes | Square, Rectangular, Round |
| Length | 500-6000mm, or as required |
| Package | Standard Sea-worthy package, fixed by belt then loaded into fumigated wooden box |
Applications
- Aviation, aerospace, and shipbuilding industries
- Electrical and industrial equipment
- Applications requiring unusual wear resistance and corrosion resistance
- High property level components
- High yield strength applications
- High hardness value requirements
Shipping & Export Details
| Container Sizes |
20GP - 2.352m (width) × 2.385m (height) × 5.90m (inside length) 40GP - 2.352m (width) × 2.385m (height) × 11.8m (inside length) 40HQ - 2.352m (width) × 2.69m (width) × 5.90m (inside length) |
| Export Regions | America, Canada, Japan, England, Saudi Arabia, India, Singapore, Korea, Australia, Brazil, Argentina, Mexico, Russia, Turkey, Greece, France, Germany, Spain |
| Port of Shipment | Tianjin Xingang port, Qingdao port, Shanghai port, Ningbo port, Guangzhou port, etc. |
CuZn37 Brass Bar Material Description
CuZn37 brass features a homogeneous single-phase structure, although it may contain traces of phase under certain cooling conditions. The phase is particularly malleable when cold, enabling strong deformation through stamping or rolling processes. CuZn37 is frequently used for stamping applications and ranks among the best brass types for polishing.
The stirring of CuZn37 brass is relatively simple, though welding presents challenges similar to most brass types due to insufficient steam pressure.
International Standards Designations
| France (AFNOR) | Cu Zn 37 (or CUZN37) |
| Germany (DIN) | Cu Zn 37 (or CUZN37) |
| Europe (EN) | CW508L |
| ASTM | C27200 |
CuZn37 Applications
With excellent mechanical properties, superior flexural strength, and low conductivity, CuZn37 brass serves critical roles in:
- Watchmaking: dials, hands, and precision components
- Household appliances: resistance wires and electrical elements
- Automotive industry: fuel injectors and engine components
- Musical instrument manufacturing: guitar strings and other instrument parts
- Heating applications and thermal systems
Chemical Composition & Physical Characteristics of CuZn37 Brass
| Chemical Composition (%) | Value | Physical Characteristics (at 20°C) | Value |
|---|---|---|---|
| Zn | Remains | Density (kg/dm³) | 8.44 |
| Cu | 63 | Electrical conductivity (%IACS) | 26 |
| Pb | 0.05 max | Electrical resistivity (MS/m) | 6.6 |
| Sn | 0.2 max | Thermal conductivity (W/m·K) | 120 |
| Al | 0.02 max | Modulus of elasticity (kN/mm²) | 110 |
| Fe | 0.05 max | Coefficient of thermal expansion (10⁻⁶/K) | 20.2 |
| Ni | 0.3 max | Melting temperature (°C) | 910 - 950 |
| Total other impurities | 0.1 max | Shear modulus (kN/mm²) | 40 |
