ASTM A335 P91 Alloy Steel Pipe for High-temperature Service with Corrosion Resistance and Cold Drawn Seamless Steel Tube

Minimum Order Quantity	1 Ton
Price	US $650-1,830 / Ton

Product Details

Model NO.	P91	Surface Treatment	Black
Section Shape	Round	Outer Diameter	6-630mm
Production Capacity	50000kgs	Material Grade	X10CrMoVNb9-1
Chromium Content	9%	Molybdenum Content	1%
Temperature Resistance	580°C - 600°C	Heat Transfer	Higher
Thermal Expansion	Lower	Wall Thickness	STD, 40, XH, 60, 80, 100, 120, 140, 160, XXH
Standard	ASTM A335, A 213, EN 10216-2	Micro-alloy Elements	Vanadium, Niobium
Nitrogen Content	Controlled
Highlight	High-temperature Service Alloy Steel Pipe , Corrosion Resistant Seamless Steel Tube , Cold Drawn ASTM A335 P91

Leave a Message

Product Description

ASTM A335 P91 Alloy Steel Pipe Cold Drawn T91 Alloy Steel Tube

Product Overview

X10CrMoVNb9-1 Alloy Steel Seamless pipes for High-temperature Service T91/P91 (X10CrMoVNb9-1)

Material Definition

Grade T/P91 is a ferritic-martensitic (9% chromium, 1% molybdenum) steel micro-alloyed with vanadium and niobium, with controlled nitrogen content according to ASTM A335, A213, or EN 10216-2 standard under the designation X10CrMoVNb9-1.

Primary Applications

On fossil-fuelled power plants, this grade is mainly used for high-temperature applications in superheater and reheater tubes, headers, and steam piping (main steam and hot reheat).

Performance Characteristics

Excellent elevated-temperature strength and creep behavior up to 580°C - 600°C
9% chromium content provides superior corrosion and oxidation resistance compared to grade 22
Reduced weight of boiler and piping components enables higher resistance to thermal fatigue
Higher heat transfer and lower thermal expansion coefficients compared to austenitic steels

Available Specifications

Standard Sizes: STD, 40, XH, 60, 80, 100, 120, 140, 160, XXH

Special customer designated nominal and minimum wall thicknesses can be furnished. Non-standard OD & ID dimensions are available.

Alternative Manufacturing Options

Best Pipeline offers pipe from turned and bored forgings in accordance with Specifications A/SA369 when client requirements for size, wall thickness, quantity, or delivery cannot be met by material available under Specifications A/SA335.

A/SA369 material is manufactured in grades including FP11, FP22, FP5, FP9, FP91, and FP92 corresponding to the same grades listed for A/SA335.

Material Grades and Standards Comparison

Carbon Steel and Alloy Steel Grades

EN/DIN Grade	Steel	Standard
P235GH	1.0345	EN10216-2
P265GH	1.0425	EN10216-2
16Mo3	1.5415	EN10216-2
15NiCuMoNb5-6-4	1.6368	EN10216-2
13CrMo4-5	1.7335	EN10216-2
10CrMo9-10	1.7380	EN10216-2
X11CrMo5	1.7362	EN10216-2
X11CrMo9-1	1.7386	EN10216-2
X10CrMoNVb9-1	1.4903	EN10216-2
X10CrwMoVNb9-2	1.4901	EN10216-2

International Standards Organizations

Standard	Country	Organization
ASTM	USA	American Society of Mechanical Engineers
AISI	USA	Acronym of American Iron and Steel Institute
JIS	JP	Japanese Industrial Standards
DIN	GER	Deutsches Institut fur Normung e.V.
UNS	USA	Unified Numbering System
