Heat Resistant 310S Stainless Steel Round Bar Cold Rolled with Bright Surface OD 6-630mm
Product Details
| Model NO. | 310s | Shape | Round |
|---|---|---|---|
| Technique | Cold Rolled | Surface Treatment | Bright |
| Specification | OD 6-630mm | Diameter | 4.7 - 100mm |
| Length | 2000mm~6500mm | Chemical Composition | C:≤0.08, Si:≤1.0, Mn:≤2.0, Cr:24.0~26.0, Ni:19.0~21.0, P:≤0.045, S:0.020~0.030 |
| Tensile Strength | 540-740 MPa | Proof Strength | 250 MPa |
| Modulus Elasticity | 195 GPa | Elongation Break | 40% |
| Brinell Hardness | 95 | Thickness | 3mm-20mm |
| Width | 25mm-200mm | ||
| Highlight | Heat Resistant Stainless Steel Round Bar,Cold Rolled 310S Stainless Steel Bar,OD 6-630mm Stainless Steel Bright Bar |
||
Product Description
Stainless Steel Bars Heat Resistant 310S Stainless Steel Round Bar
Product Specifications
| Product Name | Cold Drawn Stainless Steel Round Bar |
| Grade | 310S, 314, 310 |
| Standard | ASTM, JIS, DIN |
| Diameter | 4.7 - 100mm |
| Length | 2000mm - 6500mm or custom lengths available |
| Shape | Round Section |
| Surface | Cold drawn |
| Place Of Origin | China (Mainland) |
Available Grades: 201, 301, 303, 309S, 310S, 316L, 317L, 321, 410, 420, 440A/B/C, 2205, 2507, 904L, 17-4ph, 17-7ph, 15-5ph
Chemical Composition - Grade 310
| Element | Content (%) |
|---|---|
| Carbon (C) | ≤ 0.08 |
| Silicon (Si) | ≤ 1.0 |
| Manganese (Mn) | ≤ 2.0 |
| Chromium (Cr) | 24.0 - 26.0 |
| Nickel (Ni) | 19.0 - 21.0 |
| Phosphorus (P) | ≤ 0.045 |
| Sulfur (S) | 0.020 - 0.030 |
Material Equivalents
DIN 1.4845, DIN X12CrNi25-21, DIN X8CrNi25-21, AFNOR Z12CN2520, BS 310S24, UNI X6CrNi2520, SS 2361, UNE F.331, SAE 310S, JIS SUH310, JIS SUS310S, JIS SUS310STP, JIS SUS310STPY, JIS SUS310STB, JIS SUS310SFB, EN X8CrNi25-21, EN 1.4845, UNS S31008
TP 310 / 310S Stainless Steel Technical Data
Chemical Composition
| Element | Content (%) |
|---|---|
| Iron, Fe | Balance |
| Chromium, Cr | 24-26 |
| Nickel, Ni | 21-23 |
| Molybdenum, Mo | 2-2.50 |
| Manganese, Mn | ≤ 2 |
| Nitrogen, N | 0.10-0.16 |
| Silicon, Si | ≤ 0.70 |
| Phosphorous, P | 0.025 |
| Carbon, C | ≤ 0.020 |
| Sulfur, S | ≤ 0.010 |
Mechanical Properties
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 540-740 MPa | 78,320-107,327 psi |
| Proof strength | 250 MPa | 36,259 psi |
| Modulus of elasticity (20°C) | 195 GPa | 28,282 ksi |
| Elongation at break | 40% | 40% |
| Hardness, Brinell | 95 | 95 |
Hot Rolled 310S 309S Stainless Steel Bright Bar
Ideal for boiler and heat resistant applications
| Standard | AISI, ASTM, JIS, GB, DIN |
| Grade Series | 200S/300S/400S/600S |
| Thickness | 3mm-20mm |
| Width | 25mm-200mm |
| Length | 2m-6m, customizable up to 12m maximum |
| Surface Treatment | Polished, Bright, Hairline, Grinded, Sandblast, Pickled, Mill Finish |
| Technology | Cold-draw, Hot-rolled |
Available Materials by Grade Series
300 Series: 301, 302, 303, 304, 304L, 309, 309S, 310, 310S, 316, 316L, 316Ti, 317L, 321, 347
200 Series: 201, 202, 202CU, 204
400 Series: 409, 409L, 410, 420, 430, 431, 440
Others: 2205, 2507, 2906, 330, 660, 630, 631, 17-4PH, 17-7PH, 904L
200 Series: 201, 202, 202CU, 204
400 Series: 409, 409L, 410, 420, 430, 431, 440
Others: 2205, 2507, 2906, 330, 660, 630, 631, 17-4PH, 17-7PH, 904L
Stainless Steel Bar Size Ranges
| Grade | Hot Rolled (Black) | Hot Forged (Black) | Cold Drawn (Bright) | Smooth Turned (Bright) |
|---|---|---|---|---|
| 2205 | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
| 904L | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
| 321 | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
| 304 | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
| 304L | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
| 309 | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
| 310S(2520) | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
| 316 | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
| 316L | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
| 317 | 8mm-200mm | 150mm-500mm | 3mm-50mm | 10mm-300mm |
Additional Chemical Composition Data
| Grade | C | Si | Mn | P | S | Ni | Cr | Mo |
|---|---|---|---|---|---|---|---|---|
| 201 | ≤0.15 | ≤0.75 | 5.5-7.5 | ≤0.06 | ≤0.03 | 3.5-5.5 | 16.0-18.0 | - |
| 202 | ≤0.15 | ≤1.0 | 7.5-10.0 | ≤0.06 | ≤0.03 | 4.0-6.0 | 17.0-19.0 | - |
| 301 | ≤0.15 | ≤1.0 | ≤2.0 | ≤0.045 | ≤0.03 | 6.0-8.0 | 16.0-18.0 | - |
| 302 | ≤0.15 | ≤1.0 | ≤2.0 | ≤0.035 | ≤0.03 | 8.0-10.0 | 17.0-19.0 | - |
| 304 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤0.03 | 8.0-10.5 | 18.0-20.0 | - |
