EN 10210 S355J2+N Carbon Steel Seamless Tube Steel Round Pipe Hollow Tubes
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Carbon Steel , Alloy Steel |
| Minimum Order Quantity | 4 Tons |
| Price | 609 - 820 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 10 days based on the quantity |
| Payment Terms | L/C, Western Union, T/T |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Seamless Steel Pipe | Diameter | DN10 - DN600 |
|---|---|---|---|
| Thickness | 1.0 - 50.0mm | Length | 6-10m Or Cutting As Request |
| Standard | ASTM EN GB DIN | Technique | Hot Rolled |
| Service | Cutting Any Length As Request | MOQ | 2 Ton |
| Highlight | Steel Round Pipe EN 10210 S355J2+N,Hollow Carbon Steel Seamless Tube,EN 10210 carbon steel seamless tube |
||
Product Description
EN 10210 S355J2+N Carbon Steel Seamless Tube Steel Round Pipe Hollow Tubes
S355J2 Tube Specifications and Thickness
| Name | S355J2 Hot Rolled Seamless Steel Pipe |
| Surface | Bare,oiled |
| Material | ASTM A106B, ASTM A53B, API 5L Gr.B, ST52, ST37, ST44 SAE1010/1020/1045,S45C/CK45,SCM435,AISI4130/4140 |
| MOQ | 5 tons for normal size and material |
| WT | As customer's requests |
| Payment terms | TT deposit + the balanced against BL copy / LC or 100% LC at sight |
| Trade terms | FOB,C&F,CIF,EXW |
| Length | fixed or random,as customer request. |
| End Treatment | Plain(can be beveled, threaded,punch,shrink,extension... ) |
| Lead time | within 7 days from stock with 6m length (stock pipe with our factory name in Chinese),20-25 days for customized pipe according to the qty |
S355J2 grade of pipes is a low carbon grade. This S355J2 Pipe has a good chemical composition of silicon, sulfur, manganese, and potassium. These pipes possess good corrosion resistance and don’t erode easily. They don’t dissociate or deform under any levels of pressure or temperature. We are only supplier of S355J2+N pipe which is a welder-friendly pipe that can readily be machined. The pipe is highly versatile and is utilized for critical applications due to its superior strength. These pipes can be availed in lengths up to 18000mm. An S355J2 Carbon Steel Pipe possesses a tensile strength between 490Mpa to 630Mpa and a yield strength between 315Mpa to 355Mpa. They can be elongated by a minimum of 22%. The EN 10210 S355J2+N Carbon Steel Seamless Pipe is designed with high concentrations of carbon. This single piece of metal pipe possesses superior strength and exceptional tolerances in stress-induced environments. An S355J2 Seamless Pipe can be availed in lengths between 4mm to 219mm. All our products are quality tested and performance certified.
EN 10025 S355J2 Tube Dimension chart
| Nominal Bore (mm) |
O.D. (mm) |
Thk. (mm) |
Wght (kg/m) |
| 15 | 21.3 | 2.00 | 0.95 |
| 2.60 | 1.21 | ||
| 3.20 | 1.44 | ||
| 20 | 26.9 | 2.30 | 1.38 |
| 2.60 | 1.56 | ||
| 3.20 | 1.87 | ||
| 25 | 33.7 | 2.60 | 1.98 |
| 3.20 | 0.24 | ||
| 4.00 | 2.93 | ||
| 32 | 42.4 | 2.60 | 2.54 |
| 3.20 | 3.01 | ||
| 4.00 | 3.79 | ||
| 40 | 48.3 | 2.90 | 3.23 |
| 3.20 | 3.56 | ||
| 4.00 | 4.37 | ||
| 50 | 60.3 | 2.90 | 4.08 |
| 3.60 | 5.03 | ||
| 5.00 | 6.19 | ||
| 65 | 76.1 | 3.20 | 5.71 |
| 3.60 | 6.42 | ||
| 4.50 | 7.93 | ||
| 80 | 88.9 | 3.20 | 6.72 |
| 4.00 | 8.36 | ||
| 4.80 | 9.90 | ||
| 100 | 114.3 | 3.60 | 9.75 |
| 4.50 | 12.20 | ||
| 5.40 | 14.50 | ||
| 125 | 139.7 | 4.50 | 15.00 |
| 4.80 | 15.90 | ||
| 5.40 | 17.90 | ||
| 150 | 165.1 | 4.50 | 17.80 |
| 4.80 | 18.90 | ||
| 5.40 | 21.30 | ||
| 150 | 168.3 | 5.00 | 20.1 |
| 6.3 | 25.2 | ||
| 8.00 | 31.6 | ||
| 10.00 | 39 | ||
| 12.5 | 48 | ||
| 200 | 219.1 | 4.80 | 25.38 |
| 6.00 | 31.51 | ||
| 8.00 | 41.67 | ||
| 10.00 | 51.59 | ||
| 250 | 273 | 6.00 | 39.51 |
| 8.00 | 52.30 | ||
| 10.00 | 64.59 | ||
| 300 | 323.9 | 6.30 | 49.36 |
| 8.00 | 62.35 | ||
| 10.00 | 77.44 |
EN 10025-2 S355J2+N Chemical Composition
| Grade | C | Si | Mn | P | S |
| S355J2H (1.0576) | max 0.22 | max 0.55 | max 1.6 | max 0.03 | max 0.03 |
Spec Chart of S355J2 Square Tube
| Standard | BS EN 10210 |
|---|---|
| Sizes | 300 mm NB |
| Outside Diameter | 21.3 to 457.2 millimeter. |
| Grade | S355J2+N |
| Type | Welded | ERW | Seamless |
| Length | 6000 - 14000 millimeter, Cut to length |
| Surface Treatment | Supplier in Black Painted | Corrosion Resistant Coating | Galvanized | FBE |
| Wall Thickness | 1.8 to 14.27mm |
| Delivery Condition |
Annealed & Pickled, Polished, Bright & Annealed, etc
|
Equivalent Material of EN 10210 S355J2+N Welded Pipe
| USA | Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Italy UNI |
European old EN |
Sweden SS |
Czechia CSN |
| A656 | 1.0577 ASt52 St52-3N |
SS490YA | A52FP | 224-460 | S355J2G4 | Fe510D2 S355J2G4 |
2134-01 | 11531 |
Steel Grade S355J2+N Seamless Tube Dimension Tolerance
| Execution | Size Range | O.D. Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall - 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall - 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 - 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 - 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Standard length tolerance
| Component length (mm) | O.D. 30-100 mm | O.D. 100-254 mm |
|---|---|---|
| 10-100 | + 1.0/- 0 | + 2.0/- 0 |
| 100-600 | + 2.0/- 0 | + 3.0/- 0 |
| 600-1200 | + 3.0/- 0 | + 4.0/- 0 |
| 1200-5000 | + 5.0/- 0 | + 6.0/- 0 |
Get Free sample of S355J2 Seamless Pipe, Refer Steel Grade S355J2+N Pipe and EN 10210 S355J2+N Carbon Steel Seamless Pipe Sizing Chart.
EN 1.0577 Hot Finished Structural Hollow Sections Standard Sizes
| Size mm | kg/m | Size mm | kg/m |
| 40 x 20 x 2.0 | 1.68 | 40 x 20 x 2.5 | 2.03 |
| 40 x 20 x 3.0 | 2.36 | 40 x 25 x 1.5 | 1.44 |
| 40 x 25 x 2.0 | 1.89 | 40 x 25 x 2.5 | 2.23 |
| 50 x 25 x 2.0 | 2.21 | 50 x 25 x 2.5 | 2.72 |
| 50 x 25 x 3.0 | 3.22 | 50 x 30 x 2.5 | 2.92 |
| 50 x 30 x 3.0 | 3.45 | 50 x 30 x 4.0 | 4.46 |
| 50 x 40 x 3.0 | 3.77 | 60 x 40 x 2.0 | 2.93 |
| 60 x 40 x 2.5 | 3.71 | 60 x 40 x 3.0 | 4.39 |
| 60 x 40 x 4.0 | 5.72 | 70 x 50 x 2 | 3.56 |
| 70 x 50 x 2.5 | 4.39 | 70 x 50 x 3.0 | 5.19 |
| 70 x 50 x 4.0 | 6.71 | 80 x 40 x 2.5 | 4.26 |
| 80 x 40 x 3.0 | 5.34 | 80 x 40 x 4.0 | 6.97 |
| 80 x 40 x 5.0 | 8.54 | 80 x 50 x 3.0 | 5.66 |
| 80 x 50 x 4.0 | 7.34 | 90 x 50 x 3.0 | 6.28 |
| 90 x 50 x 3.6 | 7.46 | 90 x 50 x 5.0 | 10.11 |
| 100 x 50 x 2.5 | 5.63 | 100 x 50 x 3.0 | 6.75 |
| 100 x 50 x 4.0 | 8.86 | 100 x 50 x 5.0 | 10.90 |
| 100 x 60 x 3.0 | 7.22 | 100 x 60 x 3.6 | 8.59 |
| 100 x 60 x 5.0 | 11.70 | 120 x 80 x 2.5 | 7.65 |
| 120 x 80 x 3.0 | 9.03 | 120 x 80 x 4.0 | 12.00 |
| 120 x 80 x 5.0 | 14.80 | 120 x 80 x 6.0 | 17.60 |
| 120 x 80 x 8.0 | 22.9 | 150 x 100 x 5.0 | 18.70 |
| 150 x 100 x 6.0 | 22.30 | 150 x 100 x 8.0 | 29.10 |
| 150 x 100 x 10.0 | 35.70 | 160 x 80 x 5.0 | 18.00 |
| 160 x 80 x 6.0 | 21.30 | 160 x 80 x 8.0 | 27.90 |
| 200 x 100 x 5.0 | 22.70 | 200 x 100 x 6.0 | 27.00 |
| 200 x 100 x 8.0 | 35.4 | 200 x 100 x 10.0 | 43.60 |
| 250 x 150 x 5.0 | 30.5 | 250 x 150 x 6.0 | 38.2 |
| 250 x 150 x 8.0 | 48.0 | 250 x 150 x 10 | 59.3 |
| 300 x 200 x 6.0 | 48.10 | 300 x 200 x 8.0 | 60.50 |
| 300 x 200 x 10.0 | 75.00 | 400 x 200 x 8.0 | 73.10 |
| 400 x 200 x 10.0 | 90.70 | 400 x 200 x 16 | 142.00 |
Various Types of S355J2 Seamless Pipe Test
- Radiographic Test
- Charpy Impact Test
- Ultrasonic Test
- Pitting Corrosion Test
- Positive Material Recognition
- Hydrostatic Test
Call us for discount on DIN EN 10025-2 S355J2 Hollow Section, Find out S355j2 Pipe Heat treatment, Check Carbon Steel s355j2 Tube mechanical property.
EN 10025 S355J2+N Square Tube Heat treatment
| Hot Forming | Heat Treatment | |||
|---|---|---|---|---|
| Temperature°C | Cooling Type | Normalizing 1″ | Stress relieving anneal 2″ | Cooling Type |
| 700-750 | Air | 850-950°C | 580-630°C | Air |
S355J2+N Steel Line Pipe Processing
- Hot rolled
- Cold rolled
- Cutting
- Forming Machining/ Drilling
- Grinding
- Testing
S355J2 Pipe Mechanical Strength
| Specification | EN10210 S355J2H |
|---|---|
| Tensile Strength Rm N/mm2: 3 ≤ T ≤ 100mm | 470 – 630 |
| Yield Strength ReH Min, N/mm2: T ≤ 16mm | 355 |
| Min Elongation % T ≤ 40mm on gauge length 5.65. √S0 | 22 |
| Impact properties Minimum Ave energy (J) at -20°C | 27 |
