AISI1045 /S45C Steel Pipe / Seamless Pipe Tube DN10 - DN300 SCH40S SCH80S SCH160
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Carbon Steel , Alloy Steel |
| Minimum Order Quantity | 4 Tons |
| Price | 610 - 820 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 10 days based on the quantity |
| Payment Terms | L/C, Western Union, T/T |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Seamless Steel Pipe | Diameter | DN10 - DN600 |
|---|---|---|---|
| Thickness | 1.0 - 50.0mm | Length | 6-10m Or Cutting As Request |
| Standard | ASTM EN GB DIN | Technique | Hot Rolled |
| Service | Cutting Any Length As Request | MOQ | 2 Ton |
| Highlight | Tube Seamless Steel Pipe,SCH160 Seamless Steel Pipe,SCH40S Seamless Steel Pipe |
||
Product Description
AISI1045 /S45C Steel Pipe / Seamless Pipe Tube DN10 - DN300 SCH40S SCH80S SCH160
AISI 1045 Tube Specifications and Thickness
| Name | SAE1045 Hot Rolled Seamless Steel Pipe |
| Surface | Bare,oiled |
| Material | ASTM A106B, ASTM A53B, API 5L Gr.B, ST52, ST37, ST44 SAE1010/1020/1045,S45C/CK45,SCM435,AISI4130/4140 |
| MOQ | 5 tons for normal size and material |
| WT | As customer's requests |
| Payment terms | TT deposit + the balanced against BL copy / LC or 100% LC at sight |
| Trade terms | FOB,C&F,CIF,EXW |
| Length | fixed or random,as customer request. |
| End Treatment | Plain(can be beveled, threaded,punch,shrink,extension... ) |
| Lead time | within 7 days from stock with 6m length (stock pipe with our factory name in Chinese),20-25 days for customized pipe according to the qty |
SAE AISI 1045 Steel
ASTM SAE AISI 1045 steel is one of the commonly used medium carbon steels with an average carbon content of 0.45%, medium tensile properties, good strength, toughness and wear resistance. It can be treated by annealing, flame treatment or induction hardening.
C1045 is also known as 1045 cold rolled steel (cold worked), and 1045 hot rolled steel is known as 1045 HR.
Chemical Composition of AISI1045 Steel Pipe
| AISI ASTM 1045 Chemical Composition (%) | ||||
| Steel Grade (UNS) | C | Mn | P (≤) | S (≤) |
| 1045 (G10450) | 0.43-0.50 | 0.60-0.90 | 0.040 | 0.050 |
Mechanical Properties
1045 material mechanical properties are listed in the following table including tensile strength, yield strength, elongation, reduction and hardness, etc.
| 1045 carbon steel mechanical properties (sizes ranging: 19-32 mm) | ||||||
| Steel (UNS) | Tensile strength (Mpa) ≥ | Yield strength (Mpa) ≥ | Elongation in 50 mm, % ≥ | Reduction in area, % ≥ | Hardness (HB) | Processing, condition or treatment |
| AISI SAE 1045 (G10450) | 565 | 310 | 16 | 40 | 163 | Hot rolled |
| 625 | 530 | 12 | 35 | 179 | Cold drawn | |
| 585 | 505 | 12 | 45 | 170 | Annealed, cold drawn | |
Normalizing
1045 normalizing temperature range is 830-900 °C and the typical normalizing temperature is 860 °C.
Austenitizing
The austenitizing temperature for SAE 1045 induction hardening carbon steel is 800-845 °C.
Full Annealing
The annealing temperature for AISI 1045 carbon steel is from 790-870 °C, cooling cycle from 790 to 650 °C at a rate of 28 °C/h in furnace, and can get the HBW hardness range from 156 to 217. (Suitable for forgings with a section thickness of up to 75 mm. For the section up to 25 mm thick, the temperature time is usually at least 1 hour; for each 25 mm thick increase, 0.5 h is added.)
Hardening
The austenitizing heating at 845 °C, the quenching medium is water or brine, and the workpiece with wall thickness ≤6.35 mm is oil quenched, and the hardness should be no less than 55 HRC.
Welding
For the thickness of the weldment is ≤13mm, the preheating and interpass temperature is at least 150 °C under low hydrogen condition, other than low hydrogen, the temperature is minimum 177 °C, heat treatment is required after welding and the temperature range is 590-675 °C.
For the weldment thickness (t) 13<t≤100mm, the preheating and interpass temperature is ≥205 °C (under low hydrogen condition), ≥230 °C (except low hydrogen), and the postweld heat treatment temperature is 590-675 °C.
1045 Steel Equivalent Grade
ASTM AISI SAE 1045 carbon steel equivalent to European EN (Germany DIN EN, British BSI, French NF…), Chinese GB and Japanese JIS standard.
| AISI 1045 equivalent | |||||||
| US | Germany | China | Japan | ||||
| Standard | Grade (UNS) | Standard | Steel name (Steel number) | Standard | Grade | Standard | Grade |
| AISI SAE; ASTM A29/A29M |
1045 (G10450) | EN 10083-2 | C45 (1.0503) | GB/T 699 | 45 Steel | JIS G 4051 | S45C |
Applications
AISI SAE 1045 material is widely used in industrial applications where higher wear resistance and strength are required, typical applications including: Light gears, shafts, axles, spindles, pins, guide rods, connecting rods, bolts, worms, crankshafts, machine components, etc.
FAQ
1.Are you a manufacturer?
Yes, we are manufacturer.
2.Where is your Factory?
In Wuxi City, nearest Shanghai Port
3.Do you have Certificates?
Yes, we have ISO and API Certificates.
4.What is your annual output?
400,000 metric ton per year.
5.What is your capacity of dimension?
OD 12-610MM, WT 2-100MM
6.What is your delivery time?
5-30 days, according to stock or new production.
7.What is your Material?
Carbon and alloy steel pipe, Gr.b, 20#, CK45, ST52, AISI4140, 40Cr, 42Crmo etc.
8.What is your standard?
ISO, API, ASTM, JIS, DIN GB etc.
