ASTM A519 Grade 1020 / CK20 / S20C Carbon Steel Pipe Seamless Tubing in Heavy Wall
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Carbon Steel , Alloy Steel |
| Minimum Order Quantity | 4 Tons |
| Price | 610 - 820 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 10 days based on the quantity |
| Payment Terms | L/C, Western Union, T/T |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Seamless Steel Pipe | Diameter | DN10 - DN600 |
|---|---|---|---|
| Thickness | 1.0 - 50.0mm | Length | 6-10m Or Cutting As Request |
| Standard | ASTM EN GB DIN | Technique | Hot Rolled |
| Service | Cutting Any Length As Request | MOQ | 2 Ton |
| Highlight | Seamless Tubing Carbon Steel Pipe,Heavy Wall Carbon Steel Pipe,ASTM A519 carbon seamless steel pipe |
||
Product Description
ASTM A519 Grade 1020 / CK20 / S20C Carbon Steel Pipe Seamless Tubing in Heavy Wall
AISI 1020 Tube Specifications and Thickness
| Name | SAE1020 Hot Rolled Seamless Steel Pipe |
| Surface | Bare,oiled |
| Material | ASTM A106B, ASTM A53B, API 5L Gr.B, ST52, ST37, ST44 SAE1010/1020/1045,S45C/CK45,SCM435,AISI4130/4140 |
| MOQ | 5 tons for normal size and material |
| WT | As customer's requests |
| Payment terms | TT deposit + the balanced against BL copy / LC or 100% LC at sight |
| Trade terms | FOB,C&F,CIF,EXW |
| Length | fixed or random,as customer request. |
| End Treatment | Plain(can be beveled, threaded,punch,shrink,extension... ) |
| Lead time | within 7 days from stock with 6m length (stock pipe with our factory name in Chinese),20-25 days for customized pipe according to the qty |
ASTM A519 Grade 1020 Specification
ASTM A519 Grade 1020 Carbon Steel Seamless Tubings are Low Carbon Steel Tubings with 0.18-0.23 % carbon content with combination of 0.30-0.60 % manganese. These Tubings are also known as mild steel pipes and tubes. ASTM A519 Grade 1020 Tubings are low-cost Tubings easy to form and shape. These pipes are manufactured as per ASTM Specification and commercially referred as cs pipes or ms pipes. Low Carbon Steel Pipes are not as hard as hig carbon steel pipes,Though carburizing can increase its surface hardness.
ASTM A519 Grade 1020 Properties
| Chemical Properties | |||||||||
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
| 0.18-0.23 | – | 0.30-0.60 | 0.04 | 0.05 | – | – | – | – | – |
| Mechanical Properties | |||||
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 345 | – | 50 | 25 | ||
| Equivalent Designation | |||||
| DIN | EN | BS | NFA | ASTM | ASME |
| DIN 23912) Grade St 45 | – | – | ASTM A519 Grade 1020 | ASME SA 519 Grade 1020 | |
ASTM A519 Grade 1020 specification covers several grades of carbon and alloy steel seamless mechanical tubing. When welding is used for joining the weld able mechanical tube grades, the welding procedure shall be suitable for the grade, the condition of the components, and the intended service. Recommended pipe size will be developed by FerroPipe upon receipt of your inquiry. A print or sketch of the part to be produced should be included. Grade, chemical analysis and surface condition are carefully considered, and production processes are tailored to achieve the best tubing for the end use.
ASTM A519 Grade 1020 Carbon Steel Seamless Tubings stockist in Mumbai, India.Ferropipe stocks a complete range of IBR Certified ASTM A519 Grade 1020 Carbon Steel Seamless Tubings in outer diameter tube sizes ½”-24” and Nominal bore NB sizes 15NB-600NB in China. Exporting Carbon Steel Pipes and Alloy Steel Pipes to countries worldwide including IRAN, IRAQ, KUWAIT, QATAR, South Africa, Nigeria, Saudi Arabia, Australia, Canada & Mexico.
Delivery Executions of ASTM A519 Grade 1020 Carbon Steel Seamless Tubings
Tube Ends
All tubes are supplied with clean, square cut ends.Deburring and/or chamfering can be carried out on request.
Tube surface
Tubes are supplied normally without anti-corrosive treatment, but anti-corrosive treatment is available and is carried out on request.
Protection
- Black and Bare
- External Varnished with Black or Clear LAcquer
Mill test certificate
- MTC is issued in accordance with EN 10204.
Packaging
ASTM A519 Grade 1020 Carbon Steel Seamless Tubings are bundled as standard, with steel straps into hexagonal bundles with one end flush.Length sorting can be carried out on request. Tubes can also be bundled in multiples. Bundle weights are adjusted as requested by the customer. Each bundle contains tubes from a single cast/heat only.
Marking
ASTM A519 Grade 1020 Carbon Steel Seamless Tubings is marked with tube type, heat number, steel grade and size. Information is repeated along the whole length of the tube. Other markings, such as stamping, can be made on request. Bundles are also labeled with a tag having info both alphanumeric and by bar code.
Labelling
ASTM A519 Grade 1020 Carbon Steel Seamless Tubings delivered direct from our mill is labeled in accordance with automotive standard, ie with both alphanumeric and bar code information. Customer specific data can be added on request.
