ASTM EN DIN GB Standard Galvanized Steel Pipe / ERW Welded Pipe HDG Pipe Tube
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Galvanized steel pipe |
| Minimum Order Quantity | 1 Ton |
| Price | 650 - 750 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union, MoneyGram |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Glavanized Steel Pipe | Diameter | OD10 - 219mm |
|---|---|---|---|
| Coating | Zinc 40- 270g/m2 | Length | 6m Or As Request |
| Type | Seamleess Pipe / Welded Pipe | Application | Water Pipe, Structure |
| Laoding Port | Shanghai Port | MOQ | 1 Ton |
| Highlight | HDG Galvanized Steel Pipe,ERW Welded Galvanized Steel Pipe |
||
Product Description
ASTM EN DIN GB Standard Galvanized Steel Pipe / ERW Welded Pipe HDG Pipe Tube
| Product name | Hot Dipped Galvanized Welded Round Pipe |
| Thickness | 0.3-4.5.0mm |
| Section | Round |
| Length | As requirement |
| Surface Treatment | Zinc Coating |
| Packing | Standard export packing |
| Place of Origin | Hebei China |
| Usage | Construction,Scaffold |
| Standard | GB, ASTM, BS, GB/T 3091-2001, ASTM A106-2006, ASTM A53 |
| Grade: | Q195-Q345, A369, A53(A,B),ST37 |
Galvanized Steel Pipe
1. Standard: ASTM A53, BS1387-85, GB/T3091-08, DIN2440, JIS-G3444, EN10240, EN10255
2. Grade: Q195, Q215, Q235, Q345, S235JR, S275JR, STK400, STK500
3. Type & Zinc Coating:
Hot dip galvanized steel pipe (zinc coating: 60g/m2-275g/m2)
Pre-painted galvanized steel pipe (zinc coating: 80g/m2-275g/m2)
4. Outside diameter:
Round pipe: 17mm-273mm
Square pipe:15mm x 15mm - 400mm x 400mm
Rectangular pipe: 10mm x 20mm -200mm x 400mm
5. Wall thickness:
Round pipe: 0.6mm-12mm
Square pipe:0.6mm-20mm
Rectangular pipe: 0.6mm-20mm
6.Length:2m-5.8m/6m/12m ( We can adjust length according to your request)
Types of galvanized steel pipe
| STANDARDS | PRODUCTS | RANGES |
| IS:1239 (Part-I) | Mild Steel Tubes, Tubulars | 15mm NB – 150mm NB |
| IS:1161 | Mild Steel Tubes for Structural purpose | 15mm NB – 200mm NB |
| IS:3601 | Mild Steel tubes for Mechanical & General Engg. purpose | 20mm x 0.80mm to 165.10 x 7.00 mm |
| IS:3589 | ERW Pipes for water Gas & Sewrage | 168.3 x 4.00 mm to 219.1 x 7.00mm |
| IS:9295 | Steel Tubes for Idlers for Belt conveyors | 63.5 x 4.00 mm to 219.1 x 7.0 mm |
| IS:4270 | Steel Tubes for Water Wells | 114.3 x 5.00mm to 219.1mm x 7.1mm |
| IS:7138 | Steel Tubes for furniture | 20.0 x .60mm to 60.0 x 2.0mm |
| IS:4923 | Hollow Steel sections for structural purpose | 12.5 x 12.5 x 0.80 to 150 x 150 x 6.0mm 10 x 20 x 0.80mm to 150 x 200 x 6.0mm |
| IS:3074 | Steel Tubes for Automobile purpose | 19.7 x 1.00mm to 101.6 x 6.0mm |
| BS:1387 | Screwed & Socketed Steel Tubes & Tubulars | ½”NB to 6″NB 2.00 mm – 5.40 mm wall thick |
| BS:3601 | Steel Pipes & Tubes for pressure purpose | ½”NB to 6″NB 2.00 mm – 7.00 mm wall thickness |
| BS:6323 | Steel tubes for mechanical & general engineering purposes | 21.3″ to 219.1mm OD wall thickness-1.60-7.00 mm |
Production Process of Hot-dip Galvanized Steel Pipe:
Hot-dip galvanized steel pipe (GI Pipe) has strong corrosion resistance, strength and rigidity, and is widely used in gas, heating and water pipelines. The production process flow of hot-dip galvanized seamless steel pipe is:
Black pipe—Alkali cleaning—Water washing—Pickling—Water rinsing—Immersion aid—Drying—Hot dip galvanizing—Outside blowing—Inside blowing—Air cooling—Water cooling—Passivation—Water rinsing— Inspection—Weighing—Storage.
