0.12mm-4.5mm Thickness JIS G550 G40 G60 Z275 Galvanized Steel Coil for Container Plate Application

最小注文数量	1トン
価格	US $813-879 / Ton

商品の詳細

厚さの範囲	0.12mm～4.5mm	幅オプション	914mm、1000mm、1200mm、1219mm、1220mm、1250mm
カスタム長	はい	コイル重量	2トン～8トン
コイルの内径	508mmまたは610mm	亜鉛メッキ	Z30 - Z275
アルミニウム亜鉛コーティング	AZ40～AZ180	塗装前の厚さ	0.12～1.2mm
膜厚	20～25μm/5～10μm	コーティング層	上2層、下1層
表面の種類	通常のスパンコール / 非スパンコール	耐熱性	> 300°C
標準サイズ	12202440,15003000,15006000,20006000mm	パターン印刷の厚さ	0.17～1.5mm
基材	亜鉛メッキ鋼板・ガルバリウム鋼板
ハイライト	0.12mm-4.5mm Thickness Galvanized Steel Coil , JIS G550 G40 G60 Z275 Galvanized Steel Sheet , Container Plate Application Hot Dipped Galvanized Steel

メッセージ

製品の説明

Product Specifications

Product Name	Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet
Thickness	Galvanized: 0.12-3.0mm Galvalume: 0.25-3.0mm Prepainted: 0.12-1.2mm
Width	914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom
Length	Custom length as required
Coil Weight	2-8 Tons
Coil Inner Diameter	508mm or 610mm
Surface	Galvanized: Regular spangle/non-spangle (Z30-Z275) Galvalume: AZ40-AZ180 Prepainted: PE, HDP, SMP, PVDF coatings
Standard	AISI, ASTM, BS, DIN, GB, JIS, AS, etc.

Products Center

Prepainted Galvanized Steel Coil (PPGI)

Prepainted galvanized steel coil, also known as PPGI or color plate, is manufactured using cold rolled steel or galvanized steel as the base plate. After surface pretreatment including degreasing, cleaning, and chemical conversion treatment, the coating is applied continuously using the roller coating method, followed by baking and cooling.

This coated steel plate offers lightweight construction, attractive appearance, and excellent anti-corrosion performance. It can be directly processed and serves as an innovative raw material for construction, shipbuilding, vehicle manufacturing, home appliances, and electrical industries, effectively replacing wood while enabling efficient construction, energy savings, and pollution prevention.

Galvanized Steel Coil

Galvanized sheet refers to steel plate with a zinc-coated surface. Galvanizing is an economical and effective rust prevention method, with approximately half of the world's zinc production used for this process.

Surface Requirements:

Surface states vary based on coating process: regular spangle, small spangle, big spangles, etc.
Must have good appearance without defects affecting product use
Free from plating defects, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, or white rust

Galvalume Steel Coil

Galvalume steel sheet is an alloy composed of 55% aluminum, 43% zinc, and 2% silicon solidified at 600°C. The structure forms a dense tetrad junction crystal of aluminized iron, silicon, and zinc.

Excellent corrosion resistance - 3 times better than pure galvanized sheet
Attractive zinc flower surface decoration suitable for building exterior panels
Superior heat resistance - withstands temperatures over 300°C
Commonly used in chimney tubes, ovens, illuminators, and solar lampshades

Featured Products: Pattern Print Prepainted Steel Sheet

Product	Pattern Print Prepainted Steel Sheet
Introduction	Color plate printed on galvanized or aluminized zinc substrates using transfer printing or film covering technology
Features	Bright colors, wide variety including marble grain, camouflage, and wood grain patterns
Size	Thickness: 0.17-1.5mm, Width: less than 1.5mm
Color & Pattern	Customized as per client requirements
Base Material	Galvanized steel sheet / Galvalume steel sheet
Coating Thickness	20-25μm/5-10μm
Coating Type	Above 2 layers, bottom 1 layer
Coil ID	Φ510mm/610mm
Application	Household appliances, furniture, doors, windows, indoor and outdoor decoration

Trade Information

MOQ	5 Tons
Payment Term	TT or 100% LC at sight
Packing	Standard Sea Worthy Package
Loading Port	Shanghai Port, Qingdao Port, Tianjin Port
Container Loading	20ft container FCL, LCL
Delivery Time	Within 15 days

Company Information

Our company is a modern enterprise specializing in high-end coating plate processing, sales, and circulation, registered in Wuxi City. We offer comprehensive solutions for color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.

We maintain strong cooperative relationships with major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, and Jiangyin Zongcheng Steel. Our products are widely used in steel structure buildings, metal building materials, steel silos, ventilation pipes, mechanical and electrical housing, home appliance plates, elevators, purification plates, and automotive stamping parts.

With an average employee experience exceeding 8 years, our team provides customized supply solutions and technical services for medium and large engineering projects worldwide. We are committed to being your best partner in supply chain efficiency.

Guided by our value concept of sustainable development, we strive to provide perfect demand solutions and establish ourselves as China's premier high-end coating and plating steel products service provider.
