Industrial Grade Monel 400 Round Steel Bar with Corrosion Proof, High Temperature Tolerance, and Smooth Surface Finish

Certification	ISO, ASTM, EN
Quantité de commande min	50 kg

Détails sur le produit

Numéro de modèle.	Monel 400	Forme	Rond
Technique	Laminé à chaud	Traitement de surface	marinage
Traitement thermique	solution solide	Plage de diamètre	4~300mm
Plage d'épaisseur	1.0 à 100 mm	Plage de largeur	1~1500mm
Taille de la barre carrée	44-100100mm	Options de longueur	2m, 5.8m, 6m
Finition de surface	125-250 μin Ra	Résistance à la traction	70 000 à 85 000 psi
Limite d'élasticité	25 000 à 45 000 psi	Élongation	35 à 50%
Dureté	Rockwell B65-85
Mettre en évidence	Corrosion Proof Monel 400 Round Steel Bar , High Temperature Tolerance Nickel Alloy Round Bar , Smooth Surface Finish Monel Alloy Bar

Laisser un message

Description de produit

Industrial Grade Monel 400 Round Steel Bar

Corrosion Proof, High-Temperature Tolerance, Smooth Surface Finish

Ready for Immediate Use

Our industrial-grade Monel 400 round steel represents premium nickel-copper alloy solutions for demanding industrial applications, featuring exceptional corrosion resistance and high-temperature performance with superior surface finish.

Product Specifications

Standard	AISI, ASTM, BS, DIN, GB, JIS
Grade	Monel series: 400 K500 Inconel series: 600 601 625 718 725 Incoloy series: 800 800H 825 925 Hastelloy series: B,B2,B3,C,C-276,C-4,C-22 Pure: Ni200, Ni201
Specifications	Round bar: Diameter: 4~300mm Flat bar: Thickness: 1.0~100mm, Width: 1~1500mm Square bar: Size: 44-100100mm Length: 2m, 5.8m, 6m, or as required Surface: Black, peeled, polishing, bright, sand blast, hair line, etc.
Price Term	Ex-work, FOB, CFR, CIF, etc.
Delivery Time	Standard size is in stock, prompt delivery or as order's quantity
Package	Export standard package, bundled or as required

Key Product Advantages

Immediate Deployment Ready

Precision-turned surface finish (125-250 microinches Ra) reduces machining time and material waste. Thoroughly cleaned, oiled, and protected with VCI packaging.

Exceptional Corrosion Proof Performance

Superior resistance to acidic environments, alkaline solutions, saltwater, marine atmospheres, and chemical processing media. Corrosion rate below 0.001 inches per year in flowing seawater.

High Temperature Tolerance

Continuous service: -200°F to 1000°F (-129°C to 538°C). Short-term exposure up to 1200°F (649°C). Maintains full toughness at cryogenic temperatures.

Technical Specifications

Chemical Composition (ASTM B164 Compliant)

Nickel (Ni + Co): 63.0% minimum
Copper (Cu): 28.0-34.0%
Iron (Fe): 2.5% maximum
Manganese (Mn): 2.0% maximum
Carbon (C): 0.3% maximum
Silicon (Si): 0.5% maximum
Sulfur (S): 0.024% maximum

Mechanical Properties (As-Delivered Condition)

Tensile Strength: 70,000-85,000 psi (483-586 MPa)
Yield Strength (0.2% Offset): 25,000-45,000 psi (172-310 MPa)
Elongation in 2": 35-50%
Hardness: Rockwell B 65-85
Modulus of Elasticity: 26 x 10⁶ psi (179 GPa)

Industry Applications

Chemical Processing

Pump shafts, valve components, mixer shafts, heat exchanger components for acid handling and corrosive service

Marine & Offshore

Propeller shafts, marine fasteners, desalination plant components, offshore platform equipment

Oil & Gas Industry

Downhole tool components, valve trim, pump components for sour service, instrumentation

General Industrial

Fasteners, bushings, bearings, chemical processing equipment, power generation components

Quality Assurance & Certification

Every shipment includes complete documentation and certification:

Mill Test Reports: ASTM B164 compliance
Chemical Analysis: Spectrographic verification
Mechanical Testing: Full compliance certification
Surface Quality: Visual and dimensional inspection
Traceability: Full material history from melt to final product

Certifications & Compliance

ASTM B164 Standard Specification
ASME SB-164 Boiler Code Compliance
NACE MR0175/ISO 15156 Sour Service
ISO 9001:2015 Quality Management
RoHS Compliance

Available Inventory & Sizes

Standard Stock Sizes

Diameters: 1/4" to 8" (6mm to 200mm)
Lengths: 12' random mill lengths, cut lengths upon request
Tolerance: Hot-rolled ±1/64", Cold-drawn ±0.002"
Surface Finish: 125-250 μin Ra turned finish

Ordering Information

Most standard sizes available for immediate shipment. Custom sizes and special processing typically ship within 3-5 business days.

Packaging Options

Standard: Wood crates with VCI protection
Export: Heavy-duty packaging for international shipments
Special: Individual bar protection for critical surfaces
