ASTM B135 C12200 C11000 Copper Tube with OD 6-630mm for Air Conditioner Applications
Product Details
| Model NO. | C12200 C11000 | Shape | Round |
|---|---|---|---|
| Alloy | Alloy | Color | Red |
| Standard | ASTM | Outer Diameter | 6-630mm |
| Production Capacity | 500000kgs | Copper Composition | 99.9% |
| Phosphorus Content | 0.015-0.040% | Oxygen Content | Less Than 0.002% |
| Container Length | 5898mm, 12032mm | Container Width | 2352mm |
| Container Height | 2393mm, 2698mm | Max Load Weight | 25tons |
| Max Load Length | 5.8m, 11.8m | ||
| Highlight | ASTM B135 Copper Tube,C12200 C11000 Copper Pipe,OD 6-630mm Copper Alloy Tube |
||
Product Description
ASTM B135 C12200 C11000 Copper Tube for Air Conditioning Systems
High-quality ASTM B135 C12200 and C11000 copper tubes designed specifically for air conditioning applications. Our straight copper tubes are available in various grades including customized copper alloy tubes such as 1/2 inch x 50 ft copper pipes.
Product Specifications
We manufacture copper pipes in both welded and seamless varieties, available in round and square pipe configurations. These copper tubes are widely utilized across multiple industries including:
- Aviation and Aerospace
- Shipbuilding and Military
- Metallurgy and Electronics
- Electrical and Mechanical Engineering
- Transportation and Construction
International Standards Comparison
| GB Standard | ISO Standard | ASTM Standard | JIS Standard |
|---|---|---|---|
| TU1 | Cu-OF | C10200 | C1020 |
| T2 | Cu-ETP | C11000 | C1100 |
| TP1 | Cu-DLP | C12000 | C1201 |
| TP2 | Cu-DHP | C12200 | C1220 |
Chemical Composition - GB Standards
| Grade | Cu (%) | P (%) | O (%) | Other (%) |
|---|---|---|---|---|
| TU1 | 99.97 | 0.002 | < 0.002 | Balance |
| T2 | 99.9 | - | - | Balance |
| TP1 | 99.9 | 0.004-0.012 | - | Balance |
| TP2 | 99.9 | 0.015-0.040 | - | Balance |
Chemical Composition - ASTM Standards
| Grade | Cu+Ag (%) | P (%) | O (%) | Other (%) |
|---|---|---|---|---|
| C10200 | 99.95 | 0.001-0.005 | - | Balance |
| C11000 | 99.9 | - | - | Balance |
| C12000 | 99.9 | 0.004-0.012 | - | Balance |
| C12200 | 99.9 | 0.015-0.040 | - | Balance |
Product Gallery
Shipping and Packaging
We support all modes of transportation with sea transport being our primary method. Our standard container specifications:
- 20ft GP Container: 5898mm (Length) × 2352mm (Width) × 2393mm (Height)
- 40ft GP Container: 12032mm (Length) × 2352mm (Width) × 2393mm (Height)
- 40ft HC Container: 12032mm (Length) × 2352mm (Width) × 2698mm (Height)
Loading capacity:
- 20ft container: 25 tons of coils with length under 5.8m
- 40ft container: 25 tons of coils with length under 11.8m
Packaging: Standard sea packaging, with custom packaging available according to your specific requirements.
