Prepainted Galvanized Steel Coil PPGI with 1220*2440mm Specification Z30-Z275 Zinc Coating for Container Plate
Product Details
| Thickness | 0.12 - 3.0mm (Galvanized), 0.25 - 3.0mm (Galvalume), 0.12 - 1.2mm (Prepainted) | Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm Or Custom |
|---|---|---|---|
| Length | Custom Length | Coil Weight | 2Ton - 8 Tons |
| Coil Inner Diameter | 508mm Or 610mm | Zinc Coating | Z30 - Z275 (Galvanized) |
| Aluminum-Zinc Coating | AZ40 - AZ180 (Galvalume) | Painting Type | PE, HDP, SMP, PVDF (Prepainted) |
| Coating Thickness | 20-25um/5-10um (Pattern Print) | Coating Layers | Above 2 Layer, Bottom 1 Layer (Pattern Print) |
| Heat Resistance | >300°C (Galvalume) | Surface Finish | Regular Spangle, Non-spangle, Or Custom |
| Sheet Dimensions | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Pattern Print Thickness | 0.17 - 1.5mm |
| Pattern Print Width | <1.5mm | ||
| Highlight | 1220*2440mm Specification PPGI Steel Coil,Z30-Z275 Zinc Coating Color Coated Steel Coil,Container Plate Application Prepainted Galvanized Steel Coil |
||
Product Description
CGCC Color Coated PPGI Prepainted Galvanized Steel Coil
High-quality color coated steel coils designed for various industrial applications with excellent corrosion resistance and durability.
Product Specifications
| Products Name | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
|---|---|
| Thickness |
Galvanized steel sheet: 0.12 - 3.0mm Galvalume Steel Sheet: 0.25 - 3.0mm Prepainted Galvanized Steel Sheet: 0.12 - 1.2mm |
| Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom requirements |
| Length | Custom length as per customer requirements |
| Coil Weight | 2 - 8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface |
Galvanized steel sheet: Regular spangle / non-spangle Zinc: Z30 - Z275 Galvalume Steel Sheet: AZ40 - AZ180 Prepainted Galvanized Steel Sheet: Painting Type: PE, HDP, SMP, PVDF |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, AS, etc. |
Product Categories
Prepainted Galvanized Steel Coil (PPGI)
Also known as color plate, PPGI is manufactured using cold rolled steel plate and galvanized steel plate as base materials. After surface pretreatment including degreasing, cleaning, and chemical conversion treatment, the coating is applied continuously using the roller coating method, followed by baking and cooling processes.
Benefits include lightweight construction, attractive appearance, excellent anti-corrosion performance, and direct processing capability. Widely used in construction, shipbuilding, vehicle manufacturing, home appliances, electrical industries, and more, providing efficient steel-for-wood substitution, energy savings, and pollution prevention.
Galvanized Steel Coil
Galvanized sheet features a zinc-coated surface, providing economical and effective rust prevention. Approximately half of the world's zinc production is used in this galvanization process.
Surface specifications include various states such as regular spangle, small spangle, and big spangles. All products maintain excellent appearance standards, free from defects including no plating, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, and white rust.
Galvalume Steel Coil
Galvalume steel sheet consists of an aluminized zinc alloy structure composed of 55% aluminum, 43% zinc, and 2% silicon solidified at 600°C. The structure forms a dense tetrad junction crystal of aluminized iron, silicon, and zinc.
Offers superior corrosion resistance (3 times that of pure galvanized sheet) with decorative zinc flower patterns ideal for building exterior panels. Excellent heat resistance withstands temperatures over 300°C, making it suitable for chimney tubes, ovens, illuminators, and solar lampshades.
Featured Product: Pattern Print Prepainted Steel Sheet
| Product | Pattern Print Prepainted Steel Sheet |
|---|---|
| Description | Color plates printed on galvanized or aluminized zinc substrates using transfer printing or film covering technology |
| Features | Bright colors, wide variety including marble grain, camouflage, and wood grain patterns |
| Size | Thickness: 0.17 - 1.5mm (Width less than 1.5mm) |
| Color & Pattern | Customized as per client requirements |
| Base Material | Galvanized steel sheet / Galvalume steel sheet |
| Coating Thickness | 20-25um / 5-10um |
| Coating Type | Above 2 layers, bottom 1 layer |
| Coil ID | Φ510mm / 610mm |
| Application | Household appliances, furniture, doors and windows, indoor and outdoor decoration |
Trade Information
| MOQ | 5 Tons |
|---|---|
| Payment Term | TT or 100% LC at sight |
| Packing | Standard Sea Worthy Package |
| Loading Port | Shanghai Port, Qingdao Port, Tianjin Port |
| Container Loading | 20ft container FCL, LCL |
| Delivery Time | Within 15 days |
Company Information
Our company is a modern enterprise specializing in high-end coating plate processing, sales, and circulation, registered in Wuxi City. We offer comprehensive solutions including color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.
We maintain strong cooperative relationships with major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, and Jiangyin ZongCheng Steel. Our products serve diverse applications in steel structure building, metal building materials, steel silos, ventilation pipes, mechanical and electrical housing, home appliance plates, elevators, purification plates, and automotive stamping parts.
Our experienced team averages over 8 years in the industry, providing customized supply solutions and technical services for medium and large engineering projects worldwide. We are committed to being your trusted partner in the supply chain.
Guided by our core values of sustainability and excellence, we strive to provide perfect demand solutions and establish ourselves as China's premier high-end coating and plating steel products service provider.
