Cold Drawn 316L Stainless Steel Round Bar with Bright Surface and Diameter 4-300mm
Product Details
| Model NO. | 316L | Shape | Round |
|---|---|---|---|
| Technique | Cold Rolled | Surface Treatment | Bright |
| Diameter Range | 4 - 300mm | Length | 6m/pcs |
| Carbon Content | 0.03% Max | Manganese Content | 2.0% Max |
| Silicon Content | 0.75% Max | Chromium Content | 16.0 - 18.0% |
| Molybdenum Content | 2.00 - 3.00% | Nickel Content | 10.0 - 14.0% |
| Tensile Strength | 485 MPa Min | Yield Strength | 170 MPa Min |
| Elongation | 40% Min | ||
| Highlight | Cold Drawn Stainless Steel Round Bar,Bright Surface 316L Stainless Steel Bar,Diameter 4-300mm AISI 316L Round Bar |
||
Product Description
Cold Drawn Stainless Steel Round Bar Grade 316L / 1.4404
Diameter range: 4 - 300mm
Product Specifications
| Products | Stainless Steel Round Bar |
| Grade | 316L / 1.4404 / AISI316L |
| Standard | ASTM A276/276M |
| Diameter | 8 - 300mm |
| Length | 6m/pcs or custom cutting available |
| Surface | Black, bright |
| Other Grades Available | 304, 310S, 316L, 317L, 321, 410, 420, 431, 440A/B/C, 2205, 2507, 630, 631, 904L, etc. |
| Additional Services | Cutting, polishing, heat treatment |
Available Stainless Steel Bar Products
| Product Name | Size Range | Main Grades |
|---|---|---|
| Stainless Steel Round Bar (hot rolled black surface) | 8 - 300mm | 304, 304L, 309S, 310S, 316L, 316Ti, 317L, 321, 347, 410, 420, 431, 440A/B/C, 2205, 2507, 904L, 254SMO, 17-4PH, 17-7PH, etc. |
| Stainless Steel Round Bar (bright polished) | 3 - 50mm | 201, 304, 316L, 310S, 2205, 630, etc. |
| Stainless Steel Square Bar | 4×4 - 50×50mm | 201, 304, 316L, 310S, 410, 420, etc. |
| Stainless Steel Hexagon Bar | S4-S70 | 201, 304, 316L, 310S, 410, 420, etc. |
| Stainless Steel Flat Bar | 10×3 - 100×40mm | 304, 304L, 309S, 310S, 316L, 316Ti, 317L, 321, 347, 410, 420, 431, 440A/B/C, 2205, 2507, 904L, 254SMO, 17-4PH, 17-7PH, etc. |
| Stainless Steel Angle Bar | 30×30 - 200×200mm | 201, 304, 316L, 310S, 2205, etc. |
| Stainless Steel Channel Bar | 50×25 - 200×100mm | 201, 304, 316L, 310S, 2205, etc. |
About 316L Stainless Steel
Grade 316 is the standard molybdenum-bearing austenitic stainless steel, second in importance to 304. The molybdenum content provides 316 with superior corrosion resistance compared to Grade 304, particularly higher resistance to pitting and crevice corrosion in chloride environments.
Grade 316L is the low carbon version of 316, immune from sensitization (grain boundary carbide precipitation). This makes it extensively used in heavy gauge welded components (over about 6mm). There is typically no significant price difference between 316 and 316L stainless steel.
The austenitic structure provides excellent toughness, even at cryogenic temperatures.
Chemical Composition of 316L Stainless Steel
| Element | Minimum | Maximum |
|---|---|---|
| C | - | 0.03 |
| Mn | - | 2.0 |
| Si | - | 0.75 |
| P | - | 0.045 |
| S | - | 0.03 |
| Cr | 16.0 | 18.0 |
| Mo | 2.00 | 3.00 |
| Ni | 10.0 | 14.0 |
| N | - | 0.10 |
Mechanical Properties of 316L Stainless Steel
| Property | Value |
|---|---|
| Tensile Strength (MPa) min | 485 |
| Yield Strength 0.2% Proof (MPa) min | 170 |
| Elongation (% in 50mm) min | 40 |
| Rockwell B (HR B) max | 95 |
| Brinell (HB) max | 217 |
Grade Specification Comparison
| Standard | Designation |
|---|---|
| UNS No | S31603 |
| Old British BS | 316S11 |
| Euronorm No | 1.4404 |
| Euronorm Name | X2CrNiMo17-12-2 |
| Swedish SS | 2348 |
| Japanese JIS | SUS 316L |
Corrosion Resistance
Excellent performance in various atmospheric environments and corrosive media - generally more resistant than 304. Subject to pitting and crevice corrosion in warm chloride environments, and stress corrosion cracking above approximately 60°C.
Resistant to potable water with up to about 1000 mg/L chlorides at ambient temperatures, reducing to about 500 mg/L at 60°C.
316 is typically considered the standard "marine grade stainless steel," though it is not resistant to warm seawater. In many marine environments, 316 may exhibit surface corrosion, visible as brown staining, particularly in crevices and rough surface finishes.
Heat Resistance
Good oxidation resistance in intermittent service to 870°C and continuous service to 925°C. Continuous use in the 425-860°C range is not recommended if subsequent aqueous corrosion resistance is important.
Grade 316L is more resistant to carbide precipitation and can be used within the above temperature range. Grade 316H offers higher strength at elevated temperatures and is sometimes used for structural and pressure-containing applications above approximately 500°C.
Heat Treatment
Solution Treatment (Annealing) - Heat to 1010-1120°C and cool rapidly. These grades cannot be hardened by thermal treatment.
Welding
Excellent weldability using all standard fusion and resistance methods, with or without filler metals. Heavy welded sections in Grade 316 require post-weld annealing for maximum corrosion resistance - not required for 316L.
316L stainless steel is not generally weldable using oxyacetylene welding methods.
Machining
316L stainless steel tends to work harden if machined too quickly. Low speeds and constant feed rates are recommended for optimal results.
316L stainless steel is easier to machine compared to 316 stainless steel due to its lower carbon content.
Hot and Cold Working
316L stainless steel can be hot worked using common techniques. Optimal hot working temperatures: 1150-1260°C (minimum 930°C). Post-work annealing should be performed to maximize corrosion resistance.
Most cold working operations (shearing, drawing, stamping) can be performed. Post-work annealing is recommended to remove internal stresses.
Hardening and Work Hardening
316L stainless steel does not harden through heat treatments. It can be hardened by cold working, which may also increase strength.
Applications
- Food preparation equipment in chloride environments
- Pharmaceutical equipment
- Marine applications
- Architectural applications
- Medical implants (pins, screws, orthopedic implants)
- Total hip and knee replacements
- Fasteners
