Cold Rolled Inconel 625 Round Bar with Bright Surface and 1220*2440mm Specification
Product Details
| Model NO. | Inconel625 | Shape | Flat |
|---|---|---|---|
| Technique | Cold Rolled | Surface Treatment | Bright |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Production Capacity | 50000kgs |
| Thickness Range | 4.5MM To 200MM | Width Range | Up To 3000 Wide |
| Strip Thickness | 0.05MM To 3MM | Surface Finish | 2B / 2D / BA |
| Hardness Options | 1/4 Hard, 1/2 Hard, 3/4 Hard, Full Hard, Spring Hard, Annealed, Pickled Soft | Density | 8.4 G/cm3 |
| Melting Point | 1370-1425 °C | Tensile Strength | 550 N/mm2 |
| Yield Strength | 240 N/mm2 | ||
| Highlight | Cold Rolled Inconel Round Bar,Bright Surface Nickel Alloy Round Rod,1220*2440mm Inconel 625 Round Bar |
||
Product Description
Inconel 600 / 601 / 625 / 718 / 750 Nickel Alloy Round Bars & Rods
We are a professional manufacturer of Inconel 600 plates, sheets, strips, and coils (UNS N06600, 2.4816, Alloy 600). Our production capabilities include a comprehensive range of sizes and specifications to meet diverse industrial requirements.
Product Specifications
Available Forms & Dimensions
- Plates & Sheets: 4.5mm to 200mm thickness, up to 3000mm width
- Strips & Coils: 0.05mm to 3mm thickness
- Surface Finishes: 2B, 2D, BA
- Hardness Options: 1/4 Hard, 1/2 Hard, 3/4 Hard, Full Hard, Spring Hard, Annealed, Pickled Soft
Custom Processing Services
We offer multiple processing options to produce Inconel 600 plates to exact customer specifications, reducing material costs, production time, scrap, and internal handling. All stainless steel plate grades can be precision cut.
Surface Polishing
We can polish Inconel 600 plates, sheets, coils, and strips to #4, #6, #7, or #8 mirror finishes. Polishing available on one or both sides according to customer requirements.
Quality Assurance
Each plate, sheet, coil, and strip undergoes rigorous quality control. Test pieces are analyzed in our Metallurgical Laboratory using computerized certification systems. Chemical content is verified via optical emission spectrometry, while microstructure is examined for strength, ductility, and corrosion resistance. All scrap is separated by grade and recycled.
Inconel 600 Technical Specifications
Material Designations
| UNS | Trademark | JIS | W.Nr |
|---|---|---|---|
| N06600 | Inconel600 | NCF600 | 2.4816 |
Chemical Composition
| Element | Min (%) | Max (%) |
|---|---|---|
| Ni | 72 | - |
| Cr | 14 | 17 |
| Fe | 6 | 10 |
| C | - | 0.15 |
| Mn | - | 1 |
| Si | - | 0.5 |
| Cu | - | 0.5 |
| P | - | 0.015 |
| S | - | 0.015 |
Physical Properties
| Density | 8.4 g/cm³ |
| Melting Point | 1370-1425 °C |
Mechanical Properties
| Alloy Status | Tensile Strength (N/mm²) | Yield Strength (N/mm²) | Elongation A5 (%) | Brinell Hardness (HB) |
|---|---|---|---|---|
| Annealing Treatment | 550 | 240 | 30 | 95 |
| Solution Treatment | 500 | 180 | 35 | 85 |
Material Characteristics
- Excellent corrosion resistance in reduction, oxidation, nitric, and other media
- Superior stress corrosion cracking resistance at both room and high temperatures
- Outstanding corrosion resistance to dry chlorine and chlorine hydride
- Excellent mechanical properties from sub-zero to high temperatures
- Good anti-creep rupture strength, recommended for 700°C+ working environments
Metallurgical Structure
Face-centered cubic lattice structure
Application Fields
- Erosion thermocouple sheath in atmospheric conditions
- Vinyl chloride monomer production: resistant to chlorine, hydrogen chloride, oxidation, and carbonation
Industry Applications
- Automotive: Trim, molding, exhaust-system components, tubular manifolds, mufflers, catalytic converter shells, clamps
- Construction: Gutters, downspouts, roofing, siding
- Kitchenware: Cooking utensils, dishwashers, ovens, range hoods, refrigerators, skewers
- Chemical Processing: Oil refinery equipment, oil burner and heater parts
- Appliances: Hot water tanks, residential furnaces
- Power Generation: Heat exchanger tubing
- Farming: Dry fertilizer spreaders, farm animal pens
Ordering Information
Required Information for Ordering:
- Grade, Surface, Thickness, Size, Tolerance, Special Requirements
- Quantity
- Price Terms
- Contact Information
