Premium C11000 Copper Round Bar ASTM B187 Standard, Solid Copper Alloy 110 Rod, Stock Ready
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Pure Copper Bar | Diameter | 4 - 200mm |
|---|---|---|---|
| Length | Custom Any Length As Request | Standard | GB ASTM EN DIN |
| Loading Port | Shanghai Port | Shape | Round |
| Service | Cutting | Company Type | Factory |
| Other Material | Brass | Packing | Wooden Box |
| Highlight | C11000 copper round bar,ASTM B187 copper rod,solid copper alloy 110 bar |
||
Product Description
Premium C11000 Copper Round Bar ASTM B187 Standard, Solid Copper Alloy 110 Rod, Stock Ready
Specification of our copper products
| Product Name | Pure Copper Bar |
| Material | Copper |
| Standard | ASTM, AISI, JIS, DIN, GB, EN |
| Grade |
C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,C10930, C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,C12500,C14200, C14420,C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,C26000, C27000,C27400,C28000,C33000,C33200,C37000,C44300,C44400,C44500,C60800, C63020,C65500,C68700,C70400, C70620,C71000,C71500,C71520,C71640,C72200 T1,T2,T3,TU1,TU0,TU2,TP1,TP2,TAg0.1, |
| Shape | Round |
| Temper | O-H112; T3-T8; T351-T851 |
| Diameter | 4 - 300mm |
| Length | custom cutting any length as request |
| Payment terms | T/T,L/C,western union |
| Price terms | CFR,FOB,CIF,Ex-work,CNF |
| Package | Standard export seaworthy package or as required. |
| Contact | If you have any question,please feel free to contact me. |
Premium C11000 Copper Round Bar – ASTM B187 Standard, Solid Copper Alloy 110 Rod, Stock Ready
Product Overview
Our Premium C11000 Copper Round Bar is a high-conductivity, oxygen-containing electrolytic tough pitch (ETP) copper product manufactured to meet the stringent requirements of ASTM B187 and other global standards. With a minimum copper purity of 99.90%, this solid round bar offers exceptional electrical and thermal conductivity, excellent formability, and reliable performance in demanding industrial, electrical, and mechanical applications.
Ideal for manufacturers seeking consistent quality and immediate availability, our C11000 copper rods are stock-ready in a wide range of diameters and lengths—ensuring fast turnaround and reduced lead times without compromising on material integrity.
Chemical Composition (ASTM B187 / UNS C11000)
The chemical composition of C11000 copper is tightly controlled to ensure optimal performance:
| Element | Content (%) | Maximum Limit |
|---|---|---|
| Copper (Cu) + Silver (Ag) | ≥ 99.90% | — |
| Oxygen (O) | 0.02–0.04% | 0.04% |
| Lead (Pb) | — | 0.005% |
| Iron (Fe) | — | 0.005% |
| Sulfur (S) | — | 0.005% |
| Phosphorus (P) | — | 0.002% |
| Other Impurities (each) | — | 0.001% |
| Total Impurities | — | 0.10% |
⚠️ Note: Oxygen content enhances conductivity but limits use in reducing atmospheres or high-temperature hydrogen environments (risk of hydrogen embrittlement).
Mechanical Properties (As-Hot-Rolled Condition)
| Property | Typical Value |
|---|---|
| Tensile Strength | 210–260 MPa |
| Yield Strength (0.2%) | 60–120 MPa |
| Elongation | 40–50% (in 50 mm) |
| Hardness (HV) | 40–60 |
| Electrical Conductivity | ≥100% IACS (at 20°C) |
| Thermal Conductivity | ~398 W/(m·K) |
| Density | 8.94 g/cm³ |
| Melting Point | 1083°C |
Values may vary slightly based on diameter, processing method (hot-rolled vs. annealed), and temper.
Applicable Standards & Specifications
Our C11000 copper round bars comply with multiple international standards:
| Standard System | Designation | Description |
|---|---|---|
| ASTM (USA) | ASTM B187 | Standard Specification for Copper Bus Bar, Rod, and Shapes |
| UNS | C11000 | Unified Numbering System |
| EN (Europe) | CW004A / Cu-ETP | European Norm for ETP Copper |
| JIS (Japan) | C1100 | Japanese Industrial Standard |
| GB (China) | T2 | Chinese National Standard (similar to C11000) |
| DIN (Germany) | E-Cu58 | German Industrial Standard |
Equivalent / Cross Reference Grades
| Region | Grade / Designation |
|---|---|
| USA | C11000, ETP Copper |
| Europe | CW004A, Cu-ETP |
| Japan | C1100 |
| China | T2 |
| Germany | E-Cu58 |
| ISO | Cu-ETP |
✅ All listed grades are functionally equivalent in composition and performance for most industrial uses.
Common Applications
Thanks to its outstanding conductivity and workability, C11000 copper round bar is widely used across industries:
-
Electrical Engineering:
- Busbars, grounding rods, transformer windings
- Switchgear components, circuit breaker parts
-
Power Transmission & Distribution:
- Substation connectors, lightning arresters
- Renewable energy systems (solar inverters, EV charging stations)
-
Industrial Machinery:
- Shafts, spindles, bushings, and wear-resistant parts
-
Construction & Architecture:
- Roofing elements, decorative trim, lightning protection systems
-
Transportation:
- Automotive wiring harness terminals, rail grounding systems
-
Heat Transfer Systems:
- Heat exchanger tubes, condenser components (where corrosion resistance is key)
