Pure Solid Copper Round Bar C10100 Oxygen Free TU0 / C110
| Place of Origin | CHINA |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | C110 / C10100 |
| Minimum Order Quantity | 400 kgs |
| Price | 7000-8000 USD/Ton |
| Packaging Details | wooden box |
| Delivery Time | 7-15 days |
| Payment Terms | T/T |
| Supply Ability | 50 Tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Copper Bar | Diameter | 4 - 200mm |
|---|---|---|---|
| Length | Custom Any Length As Request | Standard | GB ASTM EN DIN |
| Loading Port | Shanghai Port | Shape | Round |
| Service | Cutting | Company Type | Factory |
| Other Material | Brass | Packing | Wooden Box |
| Highlight | C10100 solid copper round bar,Oxygen Free solid copper round bar,C10500 copper round rod |
||
Product Description
C10100 Oxygen Free Copper Bar Round Rod Diameter 4mm - 200mm TU0 / C110 Pure Copper
Specification of our copper products
| Product Name | Copper Bar |
| Material | Copper |
| Standard | ASTM, AISI, JIS, DIN, GB, EN |
| Grade |
C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,C10930, C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,C12500,C14200, C14420,C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,C26000, C27000,C27400,C28000,C33000,C33200,C37000,C44300,C44400,C44500,C60800, C63020,C65500,C68700,C70400, C70620,C71000,C71500,C71520,C71640,C72200
|
| Shape | Flat plate |
| Temper | O-H112; T3-T8; T351-T851 |
| Size | thickness 0.3mm~100mm; Width 50mm~2500mm; Length 1000mm~12000mm |
| Surface | Mill finish, polished, anodizing, brushing, sand blasting, powder coating,etc |
| Payment terms | T/T,L/C,western union, Paypal |
| Price terms | CFR,FOB,CIF,Ex-work,CNF |
| Application | 1)Further making utensil. 2)Solar reflective film 3)The appearance of the building 4)Interior decorating:ceilings,walls,etc. 5)Furniture cabinets 6)Elevator decoraction 7)Signs,nameplate,bags making. 8)Decorated inside and outside the car 9)Household appliances:refrigerators,microwave ovens,audio equipment,etc. 10)The consumer electronics:mobile phones,digital cameras,MP3,U disk,etc. |
| Package | Standard export seaworthy package or as required. |
| Contact | If you have any question,please feel free to contact me. |
C10100 Oxygen Free Electronic Copper (CDA 101)
C10100 Oxygen-Free Electronic Copper, also known as OFE, is a 99.99% pure copper with 0.0005% oxygen content. C101 achieves a minimum 101% IACS conductivity rating. This copper is finished to a final form in a carefully regulated, oxygen-free environment. C10100 OFE has High ductility, high electrical and thermal conductivity and low volatility under high vacuum.
Typical uses for C10100 Oxygen Free Electronic Copper:
AUTOMOTIVE: Automotive Rectifiers
ELECTRICAL: Transistor Component Bases, High Resistance-Ratio Cryogenic Shunts, Bus Conductors, Wave Guides, Hollow Conductors, Anodes for Vacuum Tubes, Coaxial Cable, Coaxial Tube, Klystrons, Microwave Tubes, Bus Bars, Lead-in Wire, Vacuum Seals, Conductors, Glass-to-Metal Seals
Standard Specifications of Copper Products
| End Product | Specification |
| Bar | ASTM F68, B152 |
| Bar, Bus | ASTM B187 |
| Foil, Printed Circuits | ASTM F68, B451 |
| Pipe, Bus | ASTM B188 |
| Plate | ASTM F68, B152 |
| Plate, Clad | ASTM B432 |
| Rod | ASTM F68 |
| Rod, Bus | ASTM B187 |
| Shapes | ASTM F68 |
| Shapes, Bus | ASTM B187 |
| Sheet | ASTM F68, B152 |
| Sheet, Printed Circuits | ASTM F68, B451 |
| Strip | ASTM B272, F68, B152 |
| Strip, Printed Circuits | ASTM B451, F68 |
| Tube, Bus | ASTM B188 |
| Tube, Finned | ASTM B359 |
| Tube, Rectangular Waveguide | ASTM F68, MILITARY MIL-W-85 |
| Tube, Seamless | ASTM F68, B75, B641 |
| Tube, Welded | ASTM B447, B641 |
| Tube, Welded for Air Conditioning and Refrigeration Service | ASTM B640 |
| Wire, Coated With Lead Alloy | ASTM B189 |
| Wire, Coated With Nickel | ASTM B355 |
| Wire, Coated With Silver | ASTM B298 |
| Wire, Coated With Tin | ASTM B33, B246 |
| Wire, Hard Drawn | ASTM B272, F68, B1, FEDERAL QQ-W-343 |
| Wire, Medium-Hard Drawn | ASTM F68, B2 |
| Wire, Soft | AMS 4700, ASTM B48, F68, B3 |
| Wire, Stranded | ASTM B496, B174, B173, B172, B226, B286, B470, B8, FEDERAL QQ-B-575 |
Chemical Composition of C10100 Copper
| SB | AS | CU | O | P | TE | |
| Min/Max | 0.0004 | 0.0005 | 99.99 min | 0.0005 | 0.0003 | 0.0002 |
| Nominals | - | - | - | - | - | - |
