GB Copper Round Bar C10100 C10200 10300 C10400 C10500 C10700 C11000 C11300 C12000
| Place of Origin | CHINA |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | C10100, C10200, C10300, C10400, C10500, C10700, C11000, C11300, C12000, C12200, C14300, C14420, C14530, C19210, C19400 |
| Minimum Order Quantity | 400 kgs |
| Price | 7000-8000 USD/Ton |
| Packaging Details | wooden box |
| Delivery Time | 7-15 days |
| Payment Terms | T/T |
| Supply Ability | 50 Tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Copper Bar | Diameter | 4 - 200mm |
|---|---|---|---|
| Length | Custom Any Length As Request | Standard | GB ASTM EN DIN |
| Loading Port | Shanghai Port | Shape | Round |
| Service | Cutting | Company Type | Factory |
| Other Material | Brass | Packing | Wooden Box |
| Highlight | GB copper round bar,C10100 copper round bar,C10100 copper round rod |
||
Product Description
Copper Round Bar C10100 C10200 10300, C10400, C10500, C10700, C11000, C11300, C12000
| Grades | C10100, C10200, C10300, C10400, C10500, C10700, C11000, C11300, C12000, C12200, C14300, C14420, C14530, C19210, C19400 |
| Dimension Details | 4 mm to 70 mm in diameter, lengths up to 6 m |
| Round Bar Size | 0.3125" ~ 3.000" |
| Specification:- | ASTM B187, GB/T5231-2001.GB/T1527-2006.JISH3100-2006,JISH3250-2006,JISH3300-2006 |
| Standard | EN 13601: 2002 |
| Conductivity | Above 97% IACS min in Half Hard Above 99.95% in annealed |
| Purity | Copper - 99.99% |
| Specifications (OFC) | Copper: 99.99%, O 2: < 10 ppm Copper: 99.95%, O 2: < 100 ppm |
| Type | Square and any Corner Radius, Square Edge, Square Rod, Hex Bar, Hex Rod |
| ETP Copper Round Bars | |
|---|---|
| Dimension Details | 4 mm to 70 mm in diameter, lengths up to 6 m |
| Specifications (ETP) | ASTM B133, ASTM B124, ASTM B187, IS: 191, 613 & 1897 |
| Purity | Copper - 99.9% |
| Oxygen Free Copper Hex Bars | |
| Dimension Details | 4 mm to 75 mm in diameter, lengths up to 6 m |
| Hex Bar Size | 0.375" ~ 3.000" |
| Specification:- | ASTM B133, ASTM B124, ASTM B187 |
| Standard | BS, IS, AMS, DIN & All International Standards |
| DHP / DLP Copper Bars / Flats | |
| Standard | AGB/T5231-2001.GB/T1527-2006.JISH3100-2006,JISH3250-2006,JISH3300-2006, ASTMB152M-06,ASTMB187, ASTMB75M-02, ASTMB42-02, ASTMB152, B187, B133, B301,B196, B441, B465, JISH3250-2006, GB/T4423-2007,etc. |
| Size | 1 mm to 60 mm • With Sharp Edges • With Round Rdges • With full radius |
| Width | 5mm to 350mm |
| Length | Up to 6400 mm (21') |
| Available Grade : | ASTM B42, ASTM B68, ASTM B75, ASTM B88, ASTM B111, ASTM B152, ASTM B280, DIN 2.0090, BS 2870/1/5 C106, BS 2871 C106, BS 2875 C106, ENCW024A. c12200, C12000 |
| Types | Copper Bars, Flats, Rectangular, Rectangle |
| DHP / DLP Copper Square Bars | |
| Dimension Details | 4 mm to 70 mm in diameter, lengths up to 6 m |
| Specifications | ASTM B133, ASTM B124, ASTM B187 |
| Standard | EN 12167: 1998 |
| Square Bar Size | 0.375" ~ 2.500" |
| Purity | Copper - 99.85% |
| Type | square and any corner radius, square Edge, square rod |
| DHP Bar Specifications | Copper: 99.99%, O 2: < 10 ppm |
| DLP Rod Specifications | Copper: 99.95%, O 2: < 100 ppm |
| ETP Copper Square Bars | |
| Dimension Details | 4 mm to 70 mm in diameter, lengths up to 6 m |
| Specifications | ASTM B133, ASTM B124, ASTM B187, IS: 191, 613 & 1897 |
| Square Bar Size | 0.375" ~ 2.500" |
| Commercial Copper Round Bars | |
| Dimension Details | 4 mm to 70 mm in diameter, lengths up to 6 m |
| Specifications | ASTM B133, ASTM B124, ASTM B187, IS: 191, 613 & 1897 |
| Round Bar Size | 0.3125" ~ 3.000" |
| Type | Round Bar, Round Rod |
| Commercial Copper Bars/ Flats / Patta | |
| Item | Commercial Copper Bara / Flats / Patta |
| Types | Copper Bars, Flats, Rectangular, Rectangle |
| ETP Copper Bars / Flats | |
| Standard | ASTM B187 |
| Item | Copper Flats ETP |
| Size | Width up to 152.4mm (6”) width |
| Standard | GB/T5231-2001.GB/T1527-2006. JISH3100-2006, JISH3250-2006, JISH3300-2006, ASTMB152M-06, ASTMB187, ASTMB75M-02, ASTMB42-02, ASTMB152, B187, B133, B301, B196, B441, B465, JISH3250-2006, GB/T4423-2007 etc. |
| Thickness | 1mm to 60mm |
| Width | 5mm to 350mm |
| Length | Up to 6400 mm (21') |
Mainly Products of Copper Bar
|
|
Copper Round Bars Chemical Composition
| Element | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Cu (1,2,3) | Pb | Zn | Fe | P | Ag | As | O | Sb | Te | |
| Min (%) | 99.99 | |||||||||
| Max (%) | 0.0005 | 0.0001 | 0.0010 | 0.0003 | 0.0025 | 0.0005 | 0.0005 | 0.0004 | 0.0002 | |
(1) This is a high conductivity copper which has, in tde annealed condition a minimum conductivity of 100% IACS except for Alloy C10100 which has a minimum conductivity of 101% IACS.
(2) Cu is determined by tde difference between tde impurity total and 100 %. For alloy C10100 tde Cu value is exclusive of Ag.
(3) The following additional impurity maximum limits shall apply: Bi 1ppm (0.0001%); Cd 1ppm (0.0001%); Mn 0.5ppm (0.00005%); Ni 10ppm (0.0010%); Se 3ppm (0.0003%); S 15ppm (0.0015%); Sn 2ppm (0.0002).
