ASTM A666 301 Stainless Steel Strips 0.15-2.0mm Burr-Free Slit Cut
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 301 |
| Minimum Order Quantity | 2 Ton |
| Price | 2000-3000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.15 - 2.0mm |
|---|---|---|---|
| Width | Within 1219mm | MOQ | 500 Kgs |
| Grade | 200 Series 300 Series 300 Series | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | ASTM A666 stainless steel strips,301 stainless steel slit cut strips,burr-free stainless steel strips |
||
Product Description
ASTM A666 301 Stainless Steel Strips / SS Coils Thickness 0.15 - 2.0mm Slit Cutting Without Burr
Product Attributes
| Attribute | Value |
| Products | 301 stainless steel strip |
| Thickness | 0.15-2.0mm |
| Width | within 1219mm |
| MOQ | 500 kgs |
| Other | 201 301 304 304L 309S 310S 316L 316Ti 410 420 430 436 439 441 444 440A/B/C,2205,2507,904L,C276,400,600,625,926,825.etc |
| Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS |
| Packing | wooden frame and water proof paper |
Introduction
301 stainless steel is a widely used austenitic stainless steel grade, known for its excellent combination of corrosion resistance, high strength, and good formability. Conforming to ASTM A666 standards, 301 stainless steel strips and coils are particularly valued for their high tensile strength and work-hardening properties, making them ideal for applications requiring both durability and flexibility. The strips/coils offered here feature a thickness range of 0.15 - 2.0mm and undergo precise slit cutting to ensure burr-free edges, enhancing their suitability for automated manufacturing processes and high-precision assemblies.
Chemical Composition (Typical, % by Weight)
The chemical composition of 301 stainless steel, as specified in ASTM A666, is as follows:
- Carbon (C): ≤ 0.15
- Chromium (Cr): 16.0 - 18.0
- Nickel (Ni): 6.0 - 8.0
- Manganese (Mn): ≤ 2.0
- Silicon (Si): ≤ 1.0
- Phosphorus (P): ≤ 0.045
- Sulfur (S): ≤ 0.030
- Nitrogen (N): ≤ 0.10
This composition balances chromium and nickel to provide corrosion resistance, while controlled carbon content helps maintain formability.
Mechanical Properties
301 stainless steel exhibits impressive mechanical properties, especially after cold working, which significantly increases its strength. Typical values (for annealed and cold-rolled conditions) include:
- Tensile Strength: 515 - 1379 MPa (varies with cold work; higher for fully hard conditions)
- Yield Strength: 207 - 1172 MPa (increases with cold working)
- Elongation: 40 - 10% (decreases with cold work)
- Hardness: 80 - 300 HB (Brinell) or 20 - 45 HRC (Rockwell), depending on the degree of cold rolling
These properties make 301 stainless steel strips/coils suitable for applications demanding high strength and resistance to deformation.
Specifications
- Product Form: Strips and coils
- Thickness: 0.15mm - 2.0mm
- Width: Customizable (based on slit cutting requirements, typically 10mm - 1250mm)
- Length: Coils (continuous length, usually 50 - 300 meters) or cut-to-length strips (as per customer request)
- Surface Finish: 2B (cold-rolled, matte), BA (bright annealed), or No. 4 (brushed)
- Edge Condition: Slit-cut with burr-free edges (≤ 0.01mm burr height)
- Temper: Annealed (A), 1/4 Hard (H12), 1/2 Hard (H14), 3/4 Hard (H16), Full Hard (H18)
Standards
- Primary Standard: ASTM A666 (Standard Specification for Austenitic Stainless Steel Sheet, Strip, Plate, and Flat Bar)
- Additional compliance may include:
- EN 10088-2 (European standard for stainless steel sheet/strip)
- JIS G4305 (Japanese industrial standard for stainless steel cold-rolled strips)
Equivalent Grades
301 stainless steel has counterparts in other international standards, including:
- UNS S30100
- EN 1.4310
- JIS SUS301
- GB 12Cr17Ni7 (Chinese standard)
Applications
Due to its high strength, formability, and moderate corrosion resistance, 301 stainless steel strips/coils are used in various industries:
- Automotive: Springs, clips, fuel line components, and decorative trims.
- Aerospace: Fasteners, structural components, and flexible joints.
- Electronics: Battery contacts, connectors, and precision parts in devices.
- Construction: Architectural trim, door hardware, and tension springs.
- Medical Devices: Small components requiring strength and corrosion resistance.
- Industrial: Washers, gaskets, and machinery parts subject to repeated stress.
Packaging
To ensure product integrity during transportation and storage, the strips/coils are packaged as follows:
- Each coil is wrapped in moisture-resistant plastic film to prevent rust.
- Inner layer: VCI (Volatile Corrosion Inhibitor) paper for additional corrosion protection.
- Coils are secured on wooden pallets or steel reels to avoid deformation.
- Outer packaging: Heavy-duty cardboard boxes or steel crates for bulk shipments.
- Custom packaging options (e.g., labeled with batch numbers, specifications) are available upon request.
