2D Finishing SS Strip Coil 436L 0.5-2.0mm JIS G4304 For Auto Exhaust System
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 201 202 301 304 316L 321 310S 410 430 440C |
| Minimum Order Quantity | 2 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.1 - 10.0mm |
|---|---|---|---|
| Width | Within 1500mm | MOQ | 2 Ton |
| Grade | 200 Series 300 Series 300 Series | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | 2D Finishing ss strip coil,ss strip coil 436L,2.0mm ss strips |
||
Product Description
2D Finishing 436L Stainless Steel Strip Thickness 0.5 - 2.0mm SS Strip JIS G4304 for Auto-Exhaust System
SUS 436L Hot-rolled stainless steel plates, sheet and strip
| Category | Type | Grade | Microstructure | Designations |
|---|---|---|---|---|
| Grades | Stainless Steels | SUS 436L | Ferrite | - JIS , G 4304 (2012) - Hot-rolled stainless steel plates, sheet and strip |
Chemical composition(wt.%) of SUS 436L grade: G 4304 (2012)
| Elements | Min.(≥) | Max.(≤) | Similar | Remarks |
|---|---|---|---|---|
| C | - | 0.025 | ||
| Si | - | 1.00 | ||
| Mn | - | 1.00 | ||
| P | - | 0.04 | ||
| S | - | 0.03 | ||
| Cr | 16.00 | 19.00 | ||
| Ni | - | 0.60 | ||
| Mo | 0.75 | 1.50 | ||
| N | - | 0.025 |
Mechanical properties of grade SUS 436L G 4304 (2012)
| Proof strength Rp0.2 (MPa) |
Tensile strength Rm (MPa) |
Impact energy KV (J) |
Elongation at fracture A (%) |
Reduction in cross section on fracture Z (%) |
As-Heat-Treated Condition | Brinell hardness (HBW) |
|---|---|---|---|---|---|---|
| 232 (≥) | 862 (≥) | 33 | 34 | 11 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 322 |
Physical properties of grade SUS 436L G 4304 (2012)
| Property | Density kg/dm3 |
Temperature T °C/F |
Specific heat J / kgK |
Thermal conductivity W/mK |
Electric resistance µΩ·cm |
Modulus of elasticity kN/mm2 |
Expansion rate |
|---|---|---|---|---|---|---|---|
| 896 (≥) | 945 (≥) | 44 | 31 | 21 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 214 | |
| Temp. °C/°F |
Creep strain limit (10000h) (Rp1,0) N/mm2 |
Creep rupture strength (10000h) (Rp1,0) N/mm2 |
|||||
| 427 | 785 | 733 |
SUS 436L - Form of Supply
| Product type | Products | Dimension | Processes | Deliver Status |
|---|---|---|---|---|
| Plates / Sheets | Plates / Sheets | 0.08-200mm(T)*W*L | Forging, hot rolling and cold rolling | Annealed, Solution and Aging, Q+T, ACID-WASHED, Shot Blasting |
| Steel Bar | Round Bar, Flat Bar, Square Bar | Φ8-1200mm*L | Forging, hot rolling and cold rolling, Cast | Black, Rough Turning, Shot Blasting, |
| Coil / Strip | Steel Coil /Steel Strip | 0.03-16.0x1200mm | Cold-Rolled & Hot-Rolled | Annealed, Solution and Aging, Q+T, ACID-WASHED, Shot Blasting |
| Pipes / Tubes | Seamless Pipes/Tubes, Welded Pipes/Tubes | OD:6-219mm x WT:0.5-20.0mm | Hot extrusion, Cold Drawn, Welded | Annealed, Solution and Aging, Q+T, ACID-WASHED |
Cross Reference Table(Equivalent Grade)
| Grade | Standard | Country | Application |
|---|---|---|---|
| SUS 436LTP | JIS | China |
Stainless steel pipes
|
| SUS 436LTB | JIS | China |
Stainless steel boiler and heat exchanger tubes
|
| SUS 436LTP | JIS | China |
Stainless steel pipes
|
| SUS 436L | JIS | China |
Hot-rolled stainless steel plates, sheet and strip
|
| SUS 436L | JIS | China |
Cold-rolled stainless steel plate, sheet and strip
|
