304 Stainless Steel Strip 1/4H 1/2H 3/4H FH SS Strips HV200 - HV600 Thickness 0.4 - 1.5mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 200Series 300 Series 400 Series C276 904L,Monel 400 K500 |
| Minimum Order Quantity | 2 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.01 - 3.0mm |
|---|---|---|---|
| Width | Within 1500mm | Hardness | 1/4H 1/2H 3/4H FH |
| Grade | 304 | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | HV200 Stainless Steel Strip,304 Stainless Steel Strip,1/2H Stainless Steel Strip |
||
Product Description
304 Stainless Steel Strip 1/4H 1/2H 3/4H FH SS Strips HV200 - HV600 Thickness 0.4 - 1.5mm
Products Specification
| Product Name | Stainless Steel Strip |
|---|---|
| Thickness | 0.01mm-3.0mm or as required |
| Width | 4-1500mm or as required |
| Length | As request |
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Material | 201 301 304 309S 310S 316L 317L 321 409L 410 416 420 430 439 441 444 904L C276.etc |
| Hardness | Soft , 1/4H , 1/2H , 3/4H,FH |
| Surface | 2B, BA, 2D, 6K,NO.1 or special surface as request |
| Packaging | Standard export sea-worthy packing |
| Technique | Hot rolled/Cold rolled |
| Delivery time | 7-15 Days |
| Application range | Foodstuff, gas, matallurgy, biology, electron, chemical, petroleum, boiler, nuclear energy,medical equipment, frillizer, etc |
| Note | The other specifications can be produced as per customers' requirements |
The hardness state of 304 stainless steel strip (such as 1/4H, 1/2H, 3/4H, FH) is achieved by cold rolling, and different hardness states correspond to different mechanical properties and uses. The following are the descriptions, properties, parameters, dimensions and applications of these hardness states:
1. 1/4H (1/4 Hard)
-
Hardness: Medium hardness, between soft and semi-hard.
- Tensile strength: about 700-900 MPa.
- Elongation: about 10-20%.
- Performance: With a certain strength and formability, suitable for medium strength processing.
- Application: It is often used in occasions that require certain strength and formability, such as electronic components, spring pieces, decorative strips, etc.
2. 1/2H (1/2 Hard)
-
Hardness: semi-hard, harder than 1/4H.
- Tensile strength: about 900-1100 MPa.
- Elongation: about 5-15%.
- Performance: high strength, relatively low formability, suitable for high strength occasions.
- Application: Commonly used in springs, gaskets, medical equipment, automotive parts and so on.
3. 3/4H (3/4 Hard)
- Hardness: close to full hard state, high hardness.
- Tensile strength: about 1100-1300 MPa.
- Elongation: about 3-10%.
- Performance: High strength, poor formability, suitable for high strength applications.
- Application: High strength spring, precision parts, industrial equipment, etc.
4. FH (Full Hard)
- Hardness: All hard, the highest hardness.
- Tensile strength: about 1300-1500 MPa.
- Elongation: about 1-5%.
- Performance: Very high strength, almost no formability, suitable for applications requiring very high strength.
- Application: Used for high-load springs, blades, high-strength mechanical parts, etc.
Size range of 304 Stainless Steel Strip
- 304 stainless steel belt thickness and width range is wide, common sizes are as follows:
- Thickness: 0.03mm-3.0mm (depending on hardness state and application requirements).
- Width: 4mm-1500mm (can be customized according to customer needs)
Application field of 304 Stainless Steel Strips
304 stainless steel strip due to its excellent corrosion resistance, strength and processing properties, widely used in the following fields:
- Electronic appliances: spring plate, connector, shield, etc.
- Automotive industry: exhaust pipe, gasket, fastener, etc.
- Medical instruments: surgical instruments, medical tweezers, stents, etc.
- Architectural decoration: decorative strip, elevator panel, etc.
- Industrial equipment: high-load springs, precision parts, etc.
How to Choose the Hardness of stainless steel strip?
- 1/4H: Medium strength, suitable for occasions with medium formability requirements.
- 1/2H: High strength, suitable for springs and mechanical parts.
- 3/4H: High strength, suitable for precision parts and high load applications.
- FH: Very high strength, suitable for high load springs and blades.
The selection needs to be balanced according to the requirements of strength, hardness and formability in the specific application scenario.
