4 Mm 10 SWG Copper Coil Wires For Electrical Applications
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO 9001 |
| Model Number | Oxygen-free copper |
| Minimum Order Quantity | 50kgs |
| Price | 12 - 15 USD/Kg |
| Delivery Time | 5 - 12 days |
| Payment Terms | L/C, T/T |
| Supply Ability | 2 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Copper Wire Roll | Diameter | 0.1 - 8.0mm |
|---|---|---|---|
| Surface | Bare Copper | Weight | 15kg 20kg 25kg |
| Grade | C10200 CF-CU Copper | Package | Bubble Chamber, Paper Box |
| Standard | ASTM GB EN DIN | Technique | Cold Drawn |
| Highlight | 10 SWG Copper Coil Wires,4 mm Copper Coil Wires |
||
Product Description
4 mm 10 SWG Copper Coil Wires
Products Specification
| Item | Oxygen-free copper wire |
| Standard | ASTM,AISI,EN,BS,JIS,GB/T,BSI,AS/NZS,etc |
| Material | Zero oxygen-free copper: TU0 C1011 — C10100 C110No.1 oxygen-free copper : TU1 C1020 OF-Cu C10200 C103No.2 oxygen-free copper: TU2 C1020 OF-Cu C10200 C103The first copper: T1 C1020 OF-Cu C10200 C103Copper II: T2 C1100 SE-Cu C11000 C101Third copper :T3 C1221 — – –No. 1 phosphorus deoxidized copper : TP1 C1201 SW-Cu C12000No. 2 Phosphorus Deoxidized Copper : TP2 C1220 SF-Cu C12000T1, T2, T3…T8, C1100, C5111, C5101, C5191, C5210, TU1, TP1, TP2, TAg0.08, TAg0.1, C1100, etc. |
| Size | Wire diameter: 0.1mm-30mm, or as required |
| Surface | mill,polished,bright,oiled,or as required. |
| Application | Very good conductivity, many for the production of wires, cables, brushes, etc.; good thermal conductivity, commonly used to produce magnetic instruments to be anti magnetic interference, appearance, such as compass, aviation appearance, etc. |
| Export to | is mainly exported to the following countries : America,Australia,Brazil,Canada,Peru,Iran,Italy,India,United Kingdom,Arab,etc. |
| Package | Standard export package or as required. |
| Price term | EXW,FOB,CIF,CFR,CNF,etc. |
| Payment | L/C,T/T,Western Union,etc. |
| Certificates | TUV&ISO&GL&BV,etc. |
| Diameter |
4 mm
|
| Wire Gauge |
10 SWG
|
| Usage/Application |
Industrial
|
| Country of Origin |
Made in India
|
| Brand |
Welcome Overseas
|
| Material |
Copper
|
| Technique |
Hot Rolled
|
| Color |
Copper
|
| Minimum Order Quantity |
100 Kg
|
Product Description: Copper Coil Wires
Overview
Copper Coil Wires are highly conductive, flexible wires used in various electrical and electronic applications, offering excellent performance, reliability, and durability.
Key Features
- Material: Pure Copper (99.9% Cu)- Temper: Soft, Half-Hard, Hard- Insulation: PVC, XLPE, Teflon, etc.- Gauge/Thickness: 0.1mm to 10mm (AWG 40 to AWG 4)- Length: 10m to 1000m (coils)- Certification: ASTM B3, ASME SB3, IEC 60317, RoHS
Specifications
- Electrical Conductivity: 97% IACS (International Annealed Copper Standard)- Thermal Conductivity: 386 W/m-K- Tensile Strength: 20,000-40,000 psi (138-276 MPa)- Elongation at Break: 20-40%- Temperature Range: -40°C to 150°C
Applications
- Electrical wiring and cabling- Electronics and telecommunications- Automotive and aerospace- Industrial control and automation- Medical devices and equipment- Audio and video systems
Benefits
- High electrical conductivity- Excellent flexibility and bendability- High strength and durability- Low maintenance costs- Easy to solder and connect- Recyclable
Types of Copper Coil Wires
- Solid Copper Wires- Stranded Copper Wires- Tinned Copper Wires- Silver-Plated Copper Wires
Material Properties
- UNS C11000 (Electrolytic Tough Pitch Copper)- ASTM B3- ASME SB3
Insulation Options
- PVC (Polyvinyl Chloride)- XLPE (Cross-Linked Polyethylene)- Teflon (Polytetrafluoroethylene)- Silicone
Certifications and Compliance
- ASTM B3- ASME SB3- IEC 60317- RoHS (Restriction of Hazardous Substances)- Other relevant certifications available upon request
Dimensions and Tolerances
- Gauge/Thickness: ± 0.01mm- Length: ± 1%
Packing and Delivery
- Packed in coils, reels, or spools- Delivered within 7-10 working days- Custom delivery options available
Weight Calculation
- Weight per coil = (Material Density x Volume) / 1000
