Copper Sheet Plate CU-ETP With EN 10204-3.1 Certificate Thickness 3mm 4mm 5mm 6mm 8mm 10mm
| Place of Origin | CHINA |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | CU-ETP |
| Minimum Order Quantity | 50 kgs |
| Price | 10 - 12.2 USD/Kg |
| Packaging Details | carton box, wooden box |
| Delivery Time | 10 days |
| Payment Terms | T/T, L/C |
| Supply Ability | 5 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Copper Plate Sheet | Material | CU-ETP |
|---|---|---|---|
| Thickness | 0.5 - 60.0mm | Width | 10 - 1500mm |
| Length | Within 6m | MOQ | 50 Kgs |
| Type | Plate, Sheet, Coil , Strip, Bars | Packing | Carton Box, Wooden Box |
| Highlight | 3mm Copper Sheet Plate,4mm Copper Sheet Plate,5mm Copper Sheet Plate |
||
Product Description
Copper Sheet Plate CU-ETP With EN 10204-3.1 Certificate Thickness 3mm 4mm 5mm 6mm 8mm 10mm
Products Specification
|
Copper Sheet,Copper Plate
|
||||
|
Material
|
C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,
C10930,C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300, C12500,C14200,C14420,C14500,C14510,C14520,C14530,C17200,C19200, C21000,C23000,C26000,C27000,C27400,C28000,C33000,C33200,C37000, C44300,C44400,C44500,C60800,C63020,C65500,C68700,C70400,C70600, C70620,C71000,C71500,C71520,C71640,C72200,etc. |
|||
|
Specifications
|
Thickness
|
0.1mm-200mm
|
||
|
Width
|
10mm-2500mm
|
|||
|
Length
|
10mm~12000mm,or as required.
|
|||
|
Price Term
|
Ex-work, FOB, CFR, CIF, etc.
|
|||
|
Payment Term
|
T/T, L/C, Western Union, etc.
|
|||
|
Delivery Time
|
According to order's quantity.
|
|||
|
MOQ
|
100Kgs.
|
|||
|
Export To
|
Singapore,Indonesia,Ukraine,Korea,Thailand, Viet Nam, Saudi Arabia, Brazil,
Spain, Canada, USA, Egypt, India, Kuwait, Dubai, Oman, Kuwait, Peru, Mexico, Iraq,Russia,Malaysia, etc. |
|||
Cu-ETP (Electrolytic Tough Pitch) copper plates are highly sought after for their excellent electrical conductivity, corrosion resistance, and machinability. They are manufactured to meet international standards such as ASTM B152, EN 1652, and IS 1897, ensuring top-notch quality and consistency. These plates are versatile and find applications across industries like construction, electronics, and power generation.
Applications of Cu-ETP Copper Plates
- Electrical Industry: Used in busbars, connectors, and switchgear components.
- Construction Sector:Ideal for roofing, cladding, and architectural designs.
- Electronics Manufacturing:Utilized in circuit boards and heat sinks.
- Power Generation:Suitable for transformer components and electrical conductors.
- Industrial Equipment:Commonly employed in chemical processing and heat exchangers.
Why Choose Solitaire Steel for Cu-ETP Copper Plates?
- Customizable Solutions: Plates are available in various dimensions and finishes to meet diverse industrial needs.
- Unmatched Quality: Manufactured in compliance with international standards.
- Global Reach: A robust supply chain ensures timely delivery across the globe.
- Eco-Conscious Practices: Products are sustainable and recyclable.
- Competitive Pricing: High-quality products at cost-effective rates.
Features of Cu-ETP Copper Plates
- High Electrical Conductivity: Ensures optimal performance in electrical systems.
- Corrosion Resistance: Withstands exposure to harsh environments, enhancing durability.
- Excellent Formability: Easy to machine, fabricate, and install for diverse applications.
- Dimensional Accuracy: Manufactured with precision for consistent performance.
- Eco-Friendly Material: Fully recyclable and sustainable.
- Compliance with Global Standards: Meets ASTM B152, EN 1652, and IS 1897 benchmarks.
Specifications of CU-ETP Copper
| Parameter | Details |
|---|---|
| Standard | ASTM B152, EN 1652, IS 1897 |
| Thickness Range | 0.5 mm to 10 mm |
| Width Range | Up to 1200 mm |
| Length Range | Up to 3000 mm |
| Grades | Cu-ETP (C11000) |
| Finish | Mill, Polished, Brushed, Coated |
Chemical Composition of CU-ETP Copper
| Element | Percentage (%) |
|---|---|
| Copper (Cu) | ≥ 99.90 |
| Oxygen (O) | ≤ 0.04 |
Mechanical Properties of Pure Copper CU-ETP Copper Alloy
| Property | Value |
|---|---|
| Tensile Strength (MPa) | 210 – 300 |
| Yield Strength (MPa) | ≥ 150 |
| Elongation (%) | ≥ 30 |
| Hardness (HB) | 40 – 90 |
