CuZn37 / C27200 Brass Round Bar Copper Bar Chemical Composition Data
| Place of Origin | CHINA |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | C27200 / CuZn37 |
| Minimum Order Quantity | 400 kgs |
| Price | 7000-7500USD/Ton |
| Packaging Details | wooden box |
| Delivery Time | 7-15 days |
| Payment Terms | T/T |
| Supply Ability | 50 Tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Brass Round Bar | Diameter | 3 - 200mm |
|---|---|---|---|
| Length | Custom Any Length As Request | Standard | GB ASTM EN DIN |
| Loading Port | Shanghai Port | Shape | Round |
| Service | Cutting | Company Type | Factory |
| Other Materialal | Pure Copper | Packing | Wooden Box |
| Highlight | Brass Round Bar,Brass Rod,Brass Cylindrical Bar |
||
Product Description
CuZn37 / C27200 Brass Round Bar Copper Bar Chemical Composition Data
| Product | Brass Bar,Brass Rod,Brass Shaft,Brass Stick. |
| Standard | ASTM,AISI,EN,BS,JIS,GB/T,BSI,AS/NZS,ISO,etc. |
| Material | H96,H90,H85,H80,H70,H68,H65,H63,H62,H60,C21000,C22000, C23000,C24000,C26000,C26800,C27000,C27200,C28000,C35000,etc.Or as required. |
| Surface-mount | mill,polished,bright,oiled,or as required. |
| Density | 8.5g/cm3 |
| Diameters | 1-200mm |
| Hardness | 1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard,soft,etc. |
| Shape | Square,Rectangular,Round . |
| Length | 500-6000mm,or as required. |
| Package | Standard Sea-worthy package , fixed by belt then loaded into fumigated wooden box . |
| Application | ·Widely used in aviation, aerospace, ships |
| ·Electrical and industrial industry. | |
| ·Unusual wear resistance,corrosion resistance. | |
| ·High property levels | |
| ·High yield strength | |
| ·High hardness values. | |
| Container Size | 20Gp - 2.352(width) *2.385 ( Height ) * 5.90 ( Inside length ) Meter |
| 40Gp - 2.352(width) *2.385 ( Height ) * 11.8 ( Inside length ) Meter | |
| 40HQ - 2.352(width) *2.69 ( Width ) * 5.90 ( Inside length ) Meter | |
| Export Region | America , Canada ,Japan , England , Saudi Arab , India , Singapore , Korea , Australia , Brazil , Argentina , Mexico , Russia , Turkey , Greece , France , Germany , Spain |
| Port of shipment | Tianjin Xingang port , Qingdao port , Shanghai port , ningbo port , Guangzhou port ,etc. |
CuZn37 Brass Bar
CUZN37 brass has a homogeneous single-phase structure, although it may still contain traces of phase under certain cooling conditions. As the phase is particularly malleable when cold, this makes strong deformation possible by stamping or rolling, for example. CUZN37 is also a brass often used for stamping. Of all brass types, CU ZN 37 is one of the best for polishing.
The stirring of CUZN37 brass is rather simple, which is not the case for its welding, like most brass (insufficient steam pressure).
Brass standards Cu Zn 37
At the international level, the standards are different and CU ZN37 is designated in several ways:
- France (AFNOR): Cu Zn 37 (or CUZN37)
- Germany (DIN): Cu Zn 37 (or CUZN37)
- Europe (EN): CW508L
- ASTM : C27200
CUZN37 and its applications
With excellent mechanical properties, very good flexural strength and low conductivity, the main fields of application for CUZN37 brass are :
- Watchmaking: dials, hands, ...
- Household appliances: resistance wires, ...
- Automotive: fuel injectors, ...
- The manufacture of musical instrument strings (guitar, ...)
- Heating applications
Chemical Composition of CuZn37 Brass
| Chemical composition in % | Physical characteristics (at 20°C) | ||
| Zn | Remains | Density (kg/dm3) | 8.44 |
| Cu | 63 | Electrical conductivity (%IACS) | 26 |
| Pb | 0.05 max | Electrical resistivity (MS/m) | 6.6 |
| Sn | 0.2 max | Thermal conductivity (W/m.K) | 120 |
| Al | 0.02 max | Modulus of elasticity (Kn/mm²) | 110 |
| Fe | 0.05 max | Coef. of thermal expansion (10-6/K) | 20.2 |
| Ni | 0.3 max | Melting temperature (°C) | 910 - 950 |
| Total other impurities | 0.1 max | Shear modulus (kN/mm²) |
40 |
