99.9% Pure Copper Solid Bar C11000 ASTM EN DIN Standard 4 - 250mm Diameter
| Place of Origin | CHINA |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | C11000 |
| Minimum Order Quantity | 400 kgs |
| Price | 7000-8000 USD/Ton |
| Packaging Details | wooden box |
| Delivery Time | 7-15 days |
| Payment Terms | T/T |
| Supply Ability | 50 Tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Copper Bar | Diameter | 4 - 200mm |
|---|---|---|---|
| Length | Custom Any Length As Request | Standard | GB ASTM EN DIN |
| Loading Port | Shanghai Port | Shape | Round |
| Service | Cutting | Company Type | Factory |
| Other Material | Brass | Packing | Wooden Box |
| Highlight | 99.9% Pure copper solid bar,250mm copper solid bar,DIN copper round rod |
||
Product Description
99.9% Pure Copper C11000 Round Copper Bar ASTM EN DIN Standard 4 - 250mm Diameter
Products Specification of Copper Bars
|
Product Name
|
Copper Rod
|
|
Shape
|
Round/Square/Rectangular/Flat, etc
|
|
Size
|
Regular size 600x1500mm or Customized
|
|
Grade
|
Pure Copper:C10100/C10200/C11000/C12000/C12200
Copper Alloy:C14500/C17200/C17300/C17510/C18150/C19200/C19210/C19400 Brass:C22000/C23000/C24000/26000/26800/27000 Lead Brass:C33000/CuZn36Pb3/C35000/C35300/C36010/C37000/37700/C38000 /C38500/CuZn39Pb3/CuZn40Pb2
Tin Brass:C44300/C44500/C46400/HSn90-1 Aluminum Brass:C68700/HAl77-2/HAl66-6-3-2/HAl64-3-1 Tin Bronze:C51000/C51100/C51900/C52100/C54400/CuSn4/CuSn5/CuSn5Pb1/CuSn6/CuSn8 Aluminum Bronze:C60800/C61300/C61900/C62300/C63000 Copper Nickel Alloy:C70400/C71500/C70600/C70620/C73500/75200/76200/C77000 |
|
Temper
|
H,1/2H,3/4H,1/4H,EH,SH,O60, etc.
|
|
Surface
|
Mill,Polished,bright or customized.
|
|
MOQ
|
1 ton
|
|
Delivery Time
|
5-10 days after the payment received
|
|
Payment Item
|
30% TT deposit+70% TT balance before delivery
|
About C11000 Copper Bar
C11000 copper bar has good electrical and thermal conductivity, corrosion resistance and processing properties, it can be welded and brazed. Impurities containing low electrical and thermal conductivity are small, and trace oxygen has little effect on electrical conductivity, thermal conductivity and processing properties, but it is easy to cause "hydrogen disease" and is not easy to process (annealing, welding, etc.) in high temperature (>370℃) reducing
Specification of C11000 Copper
| Grade | Composition | |||
| Cu | Pb | Fe | Zn | |
| C11000 | ≥99.90 | - | - | - |
| Type | Grade | Shape | Temper | Dimension | |
| O.D. | Length (mm) | ||||
| Extruded | C11000 | Round | O | 16-＜30 | L500-5000 |
| 30-300 | OD≤50 L1000-5000 | ||||
| OD:50-75 L500-5000 | |||||
| Rectangle | 20-120 | OD＞75-120 L500-4000 | |||
| Square, hexagonal | 20-120 | OD＞120 L300-4000 | |||
| Drwaing | C11000 | Round | O | 6-80 | OD≤50 L1000～500 |
| Square, hexagonal | H | 8-60 | OD＞50-80 L500～5000 | ||
| Square | 8-60 | ||||
Standard Size of C11000 Copper Round Bar in Stock
|
Standard Size in Stock |
4mm 5mm 6mm 7mm 8mm 9mm 10mm 12mm 14mm 15mm 16mm 18mm 19mm 20mm 22mm 24mm 25mm 27mm 28mm 30mm 32mm 35mm 38mm 40mm 42mm 45mm 48mm 50mm 55mm 60mm 65mm 70mm 75mm 80mm 85mm 90mm 95mm 100mm 105mm 110mm 115mm 120mm 125mm 130mm 140mm 150mm 160mm 180mm 190mm 200mm 210mm 220mm 230mm 240mm 250mm |
Packing &Shipping Informations
Export standard package, bundled or be required.
The inner size of container is below:
20ft GP: 5.9m(length) x 2.13m(width) x 2.18m(high)about 24-26CBM
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CB
