ASTM A240 301 Stainless Steel Strip 1mm 1/4H 1/2H 3/4H FH
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 200Series 300 Series 400 Series C276 904L,Monel 400 K500 |
| Minimum Order Quantity | 2 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.1 - 3.0mm |
|---|---|---|---|
| Width | Within 1500mm | MOQ | 1000 Kgs |
| Grade | 200 Series 300 Series 400 Series , Nickel Alloy | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | thin stainless steel strips,stainless strip,stainless steel metal strips |
||
Product Description
ASTM A240 301 Stainless Steel Strip 1/4H 1/2H 3/4H FH Stainless Steel Coil & Foil Thickness 0.1 - 2.0mm
| ProductName: | AISI 201 202 301 304 310 316 316L Surface 2b, Ba, Hairline, No.4, 8K, Mirror Finish Stainless Steel Cold Rolled Strip for Sale |
| Standard: | ASTM,AISI,DIN,EN,GB,JIS |
| Grade: | 201,304,310S,316,316L,430,409,410 |
| Thickness: | 0.15mm-3.0mm |
| Width: | 15mm-1500mm,or customized |
| Edge: | Slit edge/Mill edge |
| Surface: | 2B,BA,HL,Mirror,2D,NO.1 |
| Packaging: | Standard exporter package or as your requirements |
| Origin: | Foshan, China (Mainland) |
| Supply Ability: | 5000 Tons per Month |
| Price terms: | EX-Work,FOB,CIF,CFR,CNF |
| Payment terms: | T/T,30%advanced payment before production and balance before shipment; OR Irrevocable L/C at sight. |
| MOQ: | FCL, 25 metric tons per 20 GP, can be assorted with different sizes. LCL for trial order is acceptable. |
| Delivery time: | 10-15 days after receiving deposit by T/T or L/C. |
| Sample: | Samples free and express charges bear by you. |
Datasheet & Specification
The following tables and lists give the stainless steel 301 datasheet and specification including chemical composition, physical properties and mechanical properties, heat treatment, welding, etc.
Grade Specification
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN | |
| SS 301 | 1.4571 | S31635 | SUS 301 | Z6CNDT17‐12 | 320S31 | 08Ch17N13M2T | X6CrNiMoTi17-12-2 |
Chemical Composition
SS 301 material chemical composition is listed in the following table.
Datasheet 1, The table below shows AISI 301 stainless steel composition.
| SS 301 Chemical Composition, % | |||||||||||
| ASTM / SAE Type | AISI (UNS) | C, ≤ | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni | Mo, ≤ | Cu, ≤ | N, ≤ |
| ASTM 666; ASTM A959; ASTM A240/A240M; SAE J405 |
301 (UNS S30100) | 0.15 | 1.00 | 2.00 | 0.045 | 0.03 | 16.0-18.0 | 6.0-8.0 | – | – | 0.1 |
| SAE AMS 5517 | 18Cr-8Ni (SAE 30301) | 0.15 | 1.00 | 2.00 | 0.040 | 0.03 | 16.0-18.0 | 6.0-8.0 | 0.75 | 0.75 | – |
Notes:
- ASTM 666: Standard Specification for Annealed or Cold-Worked Austenitic Stainless Steel Sheet, Strip, Plate, and Flat Bar
- ASTM A240/A240M: Chromium and Chromium-Nickel Stainless Steel Plate, Sheet, and Strip for Pressure Vessels and for General Applications
- ASTM A959: Standard Guide for Specifying Harmonized Standard Grade Compositions for Wrought Stainless Steels
- SAE AMS 5517: Steel, Corrosion Resistant, Sheet and Strip
- SAE J405: Chemical Composition of SAE Wrought Stainless Steels
PROPERTIES: ANNEALED CONDITION
Ultimate Tensile Strength: 75 KSI min (930 MPA min) Yield Strength: (0.2% offset): 30 KSI min (205 MPA min) Elongation: 40% Min Hardness: B92 or Equiv. Max
| Temper | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Min Hardness |
| Annealed | 75 KSI min | 30 KSI min / 205 MPA min | 40% Min | B92 or Equiv. Max |
PROPERTIES: TEMPERED
| Temper | Tensile Strength | Yield Strength (0.2% Offset) | Elongation |
| 1/16 Hard | 90 KSI min | 55 KSI min / 380 MPA min | 40% Min |
| 1/8 Hard | 100 KSI min | 55 KSI min / 380 MPA min | 40% Min |
| 1/4 Hard | 125 KSI min | 55 KSI min / 380 MPA min | 25% Min |
| 1/2 Hard | 150 KSI min | 110 KSI min / 760 MPA min | 15% < .015" 18% > .015" |
| 3/4 Hard | 175 KSI min | 135 KSI min / 930 MPA min | 10% < .015" 12% > .015" |
| Full-Hard | 185 KSI min | 140 KSI min / 965 MPA min | 8% < .015" 9% > .015" |
| Super Full-Hard | 270 KSI min | 260 KSI min | Report for all thicknesses |
1/16 Hard
- Ultimate Tensile Strength: 90 KSI min (629 MPA min)
- Yield Strength: (0.2% Offset) 45 KSI min (310 MPA min)
- Elongation: 40% Min
1/8 Hard
- Ultimate Tensile Strength: 100 KSI min (690 MPA)
- Yield Strength: (0.2% Offset) 55 KSI min/380 MPA min
- Elongation: 40% Min
1/4 Hard
Ultimate Tensile Strength: 125 KSI min (860 MPA) Yield Strength: (0.2% Offset) 75 KSI min/930 MPA min Elongation: 25% Min
1/2 Hard
- Ultimate Tensile Strength: 150 KSI min (1035 MPA min)
- Yield Strength: (0.2% Offset) 110 KSI min (760 MPA min)
- Elongation: 15%<.015" 18%>.015"
3/4 Hard
- Ultimate Tensile Strength: 175 KSI min (1205 MPA min)
- Yield Strength: (0.2% Offset) 135 KSI MIN/930 MPA MIN
- Elongation: 10%< .015" 12%> .015"
Full Hard
- Ultimate Tensile Strength: 185 KSI min (1275 MPA min)
- Yield Strength: (0.2% Offset) 140 KSI min (965 MPA min)
- Elongation: 8% < .015" 9% > .015"
Super Full Hard
- Ultimate Tensile Strength: 270 KSI min< .014" (1860 MPA min) 250 KSI min .015" to 017" (1720 MPA min) 225 KSI min .0171" to .019" (1552 MPA min) 205 KSI min .0191 to .021 (1435 MPA min) 185 KSI min >.0211 (1275 MPA min)
