Monel K500 Nickel Alloy Strip Roll 0.1 - 3.0mm Thickness Cold Rolled 2B Finish in Small Tolerance
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 200Series 300 Series 400 Series C276 904L,Monel 400 K500 |
| Minimum Order Quantity | 2 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.1 - 3.0mm |
|---|---|---|---|
| Width | Within 1500mm | MOQ | 200 Kgs |
| Grade | 200 Series 300 Series 400 Series , Nickel Alloy | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | thin stainless steel strips,stainless strip,stainless steel metal strips |
||
Product Description
Cold Rolled Bright Stainless Steel Strip SS Strip Band 0.1 - 2.0mm Thickness Width 3 - 600mm
| Material | Nickel Alloy 800H,825,600,625,690,718 Hastelloy Alloy C276,C22 ,C2000, B2, B3, G30,Monel 400 K500 |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc |
| Technique | Hot rolled / Cold rolled |
| Thickness | 0.1mm-3.0mm or as required |
| Width | 5 - 1000mm as required |
| Type | Precisiion Strip |
| Surface Treatment | Bright annealiing , Cold Rolled 2B |
| Application | High temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks,machine manufacturing |
| MOQ | 1000KG |
| Delivery time | 10-15 days |
| Export Packing | Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required |
Monel K500 Plate is made up of a nickel copper alloy that has 63% nickel and 28% copper minimum with carbon, manganese, silicon, sulfur and iron in the composition. We are a leading manufacturer and supplier of the Monel K500 Plate products in different dimensions and types. There are thicker plates and thinner sheets along with coils and strips. The material has very high melting point of 1350 degrees Celsius which makes it applicable in high temperature applications. The Monel K500 Sheet also has a higher tensile strength and yield strength with high density.
The specification of these plates and sheets is ASTM B127. There are K500 Monel Hot Rolled Plates and cold rolled plates as different finishes to the same material. The sheets and plates also range in thickness from 0.3mm to 20mm, width of 1000mm to 2000mm and a length range of 2000mm to 6000mm. The ASME SB 127 Monel Cold Rolled Plates support grinding, polishing and cutting operations. The material is highly machinable and workable. The material is highly resistant to oxidation, stress cracking, pitting and crevice corrosion attacks. Please contact us for more information on the products such as the K500 Monel Alloy Flat Plates, their prices and other variations of them.
Common Specification Of Alloy K500 Plates
| Standard | ASME SB127/ ASTM B127 |
| Hardness Available | Half Hard, Quarter Hard, Spring Hard, Hard, Soft etc |
| Manufacturing sizes | Width 5 - 1219mm |
| Available Thickness | 0.1 to 12 mm Thk |
| Types of finish | Cold rolled sheet (CR), BA NO(8), 2B, Hot rolled plates (HR), 2D, SATIN |
| Most Used Form | Rolls, Coils, Blank (Circle), Shim Sheet, Flats, Foils, Strip, Ring (Flange), Plain Sheet |
UNS N05500 Strip Features
- Excellent resistance to high velocity sea water
- Excellent mechanical properties from sub-zero temperatures up to about 480C
- Non-magnetic alloy
- Resistant to a sour-gas environment
- Corrosion resistance in an extensive range of chemical and marine environments
ASME SB 127 DIN 2.4375 Plate Chemical Composition
| Grade | Ni | Mn | C | Si | Cu | S | Fe |
| Monel K500 | 63.00 min | 1.5 max | 0.25 max | 0.5 max | 27.00 – 33.00 | 0.010 max | 0.5 – 2 |
Alloy K500 Perforated Sheet Mechanical Properties
| Element | Tensile Strength | Elongation | Melting range | Density | (0.2%Offset) Yield Strength |
| Monel K500 | MPa – 1100, Psi – 160000 | 20 % | (2460 °F) 1350 °C | 8.44 g/cm3 | MPa – 790, Psi – 115000 |
Monel K500 Sheet Equivalent Material
| STANDARD | WERKSTOFF NR. | UNS |
| Monel K500 | 2.4375 | N05500 |
ASTM B127 UNS N05500 Strip Application
- Sour-gas service applications
- Oil and gas production ety lifts and valves
- cables, Chains, valve trim, springs, fasteners for marine service
- Oil well industry
- Doctor blades and scrapers
- Oil-well tools and instruments like drill collars
- Pump shafts and impellers in marine service
