Bright Annealing Alloy 400 Strip 0.1mm - 0.5mm Monel400 Strip Foil Width 5 - 500mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 200Series 300 Series 400 Series C276 904L,Monel 400 |
| Minimum Order Quantity | 2 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.1 - 3.0mm |
|---|---|---|---|
| Width | Within 1500mm | MOQ | 200 Kgs |
| Grade | 200 Series 300 Series 400 Series , Nickel Alloy | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | thin stainless steel strips,stainless strip,stainless steel metal strips |
||
Product Description
Bright Annealing Alloy 400 Strip 0.1mm - 0.5mm Monel400 Strip Foil Width 5 - 500mm
| Material | Nickel Alloy 800H,825,600,625,690,718 Hastelloy Alloy C276,C22 ,C2000, B2, B3, G30,Monel 400 K500 |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc |
| Technique | Hot rolled / Cold rolled |
| Thickness | 0.1mm-3.0mm or as required |
| Width | 5 - 1000mm as required |
| Type | Precisiion Strip |
| Surface Treatment | Bright annealiing , Cold Rolled 2B |
| Application | High temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks,machine manufacturing |
| MOQ | 1000KG |
| Delivery time | 10-15 days |
| Export Packing | Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required |
Monel 2.4360 Strip Exporter, 400 Stainless Coils, Strip, Foils Manufacturer, ASTM B127 Monel Foils Supplier, 400 Monel Foil, Monel Shim Foil, Monel Foil Manufacturer, 400 Monel Shim Foils Exporter
We manufacture Alloy 400 Strips, Coils in such a way that they can be easily welded, soldered and brazed which in addition we have included marvellous mechanical properties at subzero temperatures. Our Alloy 400 Slatting Coils’s increased strength and hardness maintains with only slight weakness of ductility or impact resistance. Our Alloy 400 Perforated Coils does not undergo a ductile-to-brittle phase even when cooled to the temperature of liquid hydrogen.
Monel 400 Strips, Coils, Foils Specification
- Specifications : ASTM / ASME SB 127
- Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
- Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange).
- Grade : Monel Alloy 400 (UNS No. N04400) Coils & Strips
- Hardness : Soft, Hard, Half Hard, Spring Hard, etc.
- Finish : Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated)
- Other services : Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc.
Specialized In Following Monel 400 Strip, Foils, Coils
400 Monel Strip, Coils Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | EN | JIS | BS | GOST |
| Monel 400 | 2.4360 | N04400 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Chemical Composition of Monel 400 Strip, Coil, Foils
| Grade | Cu | Fe | Ni | C | Mn | Si | S |
| Monel 400 | 28.00 – 34.00 | 2.50 max | 63.00 min | 0.30 max | 2.00 max | 0.50 max | 0.024 max |
Mechanical Property of Monel UNS N04400 Coils, Foils
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Monel 400 NR. 2.4360 Strip, Coils Packaging and Advantages
Types of Packaging:
– Bundles (hexagonal)
– Wooden Boxes
– Crates (steel/wooden)
– Special crates for Coils Strips Foils with each radius separated
– Packaging for Monel 400 Coils Strips Foils as per customer’s requirements
Advantages :
– High Strength
– Resistant High Mechanical Stresses
– Resistant to High Pressure
– Resistant to High Temperature
– Good Formality
– Reusable
