Z100 Zero Spangle Skin Passed Painting Zinc Plated Metal Sheet SGCC with 1220*2440mm Specification
Product Details
| Thickness | 0.12 - 3.0mm | Width | 914mm,1000mm,1200mm,1219mm,1220mm,1250mm |
|---|---|---|---|
| Length | Custom Length | Coil Weight | 2Ton - 8 Tons |
| Coil Inner Diameter | 508mm Or 610mm | Zinc Coating | Z30 - Z275 |
| Aluminum Zinc Coating | AZ40 - AZ180 | Painting Type | PE,HDP,SMP,PVDF |
| Sheet Dimensions | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Coating Thickness | 20-25um/5-10um |
| Coating Layers | Above 2 Layer, Bottom 1 Layer | Pattern Print Thickness | 0.17 - 1.5mm |
| Pattern Print Width | Less Than 1.5mm | Surface Treatment | Regular Spangle / Non-spangle |
| Heat Resistance | >300°C | ||
| Highlight | Z100 Zero Spangle Galvanized Steel Sheet,Skin Passed Painting Zinc Plated Metal Sheet,1220*2440mm Specification SGCC Steel Sheet |
||
Product Description
Z100 Zero Spangle Skin Passed Painting Zinc Plated Metal Sheet SGCC
High-quality galvanized steel sheet featuring zero spangle surface with skin passing and painting treatment, designed for superior corrosion resistance and excellent paint adhesion.
Product Specifications
Available Products
| Product Type | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
|---|
Technical Specifications
| Thickness | Galvanized steel sheet: 0.12 - 3.0mm Galvalume Steel Sheet: 0.25 - 3.0mm Prepainted Galvanized Steel Sheet: 0.12 - 1.2mm |
|---|---|
| Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom requirements |
| Length | Custom length as per customer requirements |
| Coil Weight | 2 - 8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface Treatment | Galvanized: Regular spangle / non-spangle Zinc (Z30 - Z275) Galvalume: AZ40 - AZ180 Prepainted: PE, HDP, SMP, PVDF coatings |
| Standards | AISI, ASTM, BS, DIN, GB, JIS, AS, etc. |
Product Categories
Prepainted Galvanized Steel Coil (PPGI)
Color coated steel plate manufactured using cold rolled steel and galvanized steel as base plates. Features surface pretreatment including degreasing, cleaning, and chemical conversion treatment, followed by continuous roller coating method with baking and cooling processes.
- Light weight with attractive appearance
- Excellent anti-corrosion performance
- Direct processing capability
- Applications: Construction, shipbuilding, vehicle manufacturing, home appliances, electrical industry
- Benefits: Steel-for-wood replacement, efficient construction, energy saving, pollution prevention
Galvanized Steel Coil
Zinc-coated steel sheet providing economical and effective rust prevention. Approximately half of global zinc production is utilized for galvanization processes.
Surface Requirements:
Available in various surface states including regular spangle, small spangle, and big spangles. Products feature excellent appearance free from defects such as no plating, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, or white rust.
Available in various surface states including regular spangle, small spangle, and big spangles. Products feature excellent appearance free from defects such as no plating, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, or white rust.
Galvalume Steel Coil
Advanced alloy composition of 55% aluminum, 43% zinc, and 2% silicon solidified at 600°C, forming dense tetrad junction crystal structure.
- Superior corrosion resistance - 3 times better than pure galvanized sheet
- Attractive zinc flower surface decoration for building exterior panels
- Excellent heat resistance - withstands temperatures exceeding 300°C
- Applications: Chimney tubes, ovens, illuminators, solar lampshades
Featured Product: Pattern Print Prepainted Steel Sheet
| Product | Pattern Print Prepainted Steel Sheet |
|---|---|
| Description | Color plates printed on galvanized or aluminized zinc substrates using transfer printing or film covering technology |
| Features | Bright colors, wide variety including marble grain, camouflage, wood grain patterns |
| Size | Thickness: 0.17 - 1.5mm (Width less than 1.5mm) |
| Color & Pattern | Customized as per client requirements |
| Base Material | Galvanized steel sheet / Galvalume steel sheet |
| Coating Thickness | 20-25μm / 5-10μm |
| Coating Type | Above 2 layers, bottom 1 layer |
| Coil ID | Φ510mm / 610mm |
| Applications | Household appliances, furniture, doors and windows, indoor and outdoor decoration |
Trade Information
| Minimum Order Quantity | 5 Tons |
|---|---|
| Payment Terms | TT or 100% LC at sight |
| Packing | Standard Sea Worthy Package |
| Loading Port | Shanghai Port, Qingdao Port, Tianjin Port |
| Container Loading | 20ft container FCL, LCL |
| Delivery Time | Within 15 days |
Company Profile
Our company is a modern enterprise specializing in high-end coating plate processing, sales, and distribution, registered in Wuxi City. We offer comprehensive product range including color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.
Strategic Partnerships
We maintain strong cooperative relationships with major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, and Jiangyin ZongCheng Steel.
Applications
Our products are extensively used in steel structure buildings, metal building materials, steel silos, ventilation pipes, mechanical and electrical housing, home appliance plates, elevators, purification plates, automotive stamping parts, and various other fields.
Expertise & Service
Our team averages over 8 years of industry experience, enabling us to provide customized supply solutions and improve supply chain efficiency. We have participated in material supply and technical services for numerous medium and large engineering projects domestically and internationally.
Our Commitment: We adhere to the value concept of "not for a long time, not to be able to recover," committed to providing customers with perfect demand solutions. We strive to become China's premier high-end coating and plating steel products service provider.
