DX51D Prepainted PPGI Steel Coil 1220*2440mm Galvanized Color Coated Steel Coil with Wooden Pallet

Minimum Order Quantity	1 Ton
Price	US $975-1,122 / Ton

Product Details

Thickness	0.12 - 3.0mm (Galvanized), 0.25 - 3.0mm (Galvalume), 0.12 - 1.2mm (Prepainted)	Width	914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm Or Custom
Length	Custom Length	Coil Weight	2Ton - 8 Tons
Coil Inner Diameter	508mm Or 610mm	Zinc Coating	Z30 - Z275
Aluminum-Zinc Coating	AZ40 - AZ180	Painting Type	PE, HDP, SMP, PVDF
Surface Finish	Regular Spangle, Non-spangle, Or Custom	Coating Thickness	20-25um/5-10um
Coating Layers	Above 2 Layer, Bottom 1 Layer	Heat Resistance	>300°C (Galvalume)
Pattern Thickness	0.17 - 1.5mm (Pattern Print)	Base Material	Galvanized/Galvalume Steel
Sheet Specification	12202440, 15003000, 15006000, 20006000mm
Highlight	DX51D Prepainted PPGI Steel Coil , 1220*2440mm Color Coated Steel Coil , Wooden Pallet Galvanized Steel Coil

Leave a Message

Product Description

DX51D SGCC Prepainted PPGI Steel Coil Material

Galvanized color coated steel sheet coil designed for superior corrosion resistance and aesthetic appeal.

Product Specifications

Products Name	Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet
Thickness	Galvanized steel sheet: 0.12 - 3.0mm Galvalume Steel Sheet: 0.25 - 3.0mm Prepainted Galvanized Steel Sheet: 0.12 - 1.2mm
Width	914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom requirements
Length	Custom length as per customer requirements
Coil Weight	2 - 8 Tons
Coil Inner Diameter	508mm or 610mm
Surface	Galvanized: Regular spangle/non-spangle Zinc (Z30-Z275) Galvalume: AZ40-AZ180 Prepainted: PE, HDP, SMP, PVDF coatings
Standard	AISI, ASTM, BS, DIN, GB, JIS, AS

Prepainted Galvanized Steel Coil (PPGI)

Color coated steel plate manufactured using cold rolled steel and galvanized steel as base plates. Features surface pretreatment, continuous coating application, baking, and cooling processes. Offers lightweight construction, attractive appearance, and excellent anti-corrosion performance.

Galvanized Steel Coil

Zinc-coated steel sheet providing economical and effective rust prevention. Surface options include regular spangle, small spangle, and big spangles with strict quality control for optimal performance.

Galvalume Steel Coil

Alloy composition of 55% aluminum, 43% zinc, and 2% silicon solidified at 600°C. Features excellent corrosion resistance (3x pure galvanized sheet), heat resistance up to 300°C, and decorative zinc flower surface patterns.

Pattern Print Prepainted Steel Sheet

Products	Pattern print prepainted steel sheet
Introduction	Color plate printed on galvanized or aluminized zinc substrates using transfer printing or film covering technology
Features	Bright colors, variety of patterns including marble grain, camouflage, and wood grain
Size	Thickness: 0.17 - 1.5mm, Width: less than 1.5mm
Color and Pattern	Customizable as per client requirements
Base Material	Galvanized steel sheet / Galvalume steel sheet
Coating Thickness	20-25um/5-10um
Coating Type	Above 2 layers, bottom 1 layer
Coil ID	Φ510mm/610mm
Application	Household appliances, furniture, doors, windows, indoor and outdoor decoration

Trade Information

MOQ	5 Tons
Payment Term	TT or 100% LC at sight
Packing	Standard Sea Worthy Package
Loading Port	Shanghai Port, Qingdao Port, Tianjin Port
Container Loading	20ft container FCL, LCL
Delivery Time	Within 15 days
