Prepainted Galvalume Steel Coil with AZ40-AZ180 Coating for Container Plate in 1220*2440mm Specification
| Thickness | 0.12 - 3.0mm (Galvanized), 0.25 - 3.0mm (Galvalume), 0.12 - 1.2mm (Prepainted) | Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm Or Custom |
|---|---|---|---|
| Length | Custom Length | Coil Weight | 2Ton - 8 Tons |
| Coil Inner Diameter | 508mm Or 610mm | Zinc Coating | Z30 - Z275 (Galvanized) |
| Aluminum-Zinc Coating | AZ40 - AZ180 (Galvalume) | Painting Type | PE, HDP, SMP, PVDF (Prepainted) |
| Coating Thickness | 20-25um/5-10um (Prepainted) | Coating Layers | Above 2 Layer, Bottom 1 Layer (Prepainted) |
| Material Composition | 55% Al, 43% Zn, 2% Si (Galvalume) | Heat Resistance | >300°C (Galvalume) |
| Surface Finish | Regular Spangle, Non-spangle, Patterned (as Requested) | Standard Compliance | AISI, ASTM, BS, DIN, GB, JIS, AS |
| Sheet Dimensions | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | ||
| Highlight | 1220*2440mm Specification Prepainted Galvalume Steel Coil,AZ40-AZ180 Coating Color Coated Steel Coil,Container Plate Application PPGI Steel Coil |
||
| Product Name | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
|---|---|
| Thickness |
Galvanized steel sheet: 0.12 - 3.0mm Galvalume Steel Sheet: 0.25 - 3.0mm Prepainted Galvanized Steel Sheet: 0.12 - 1.2mm |
| Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom requirements |
| Length | Custom length as per customer requirements |
| Coil Weight | 2 - 8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface |
Galvanized steel sheet: Regular spangle / non-spangle Zinc: Z30 - Z275 Galvalume Steel Sheet: AZ40 - AZ180 Prepainted Galvanized Steel Sheet: Painting Type: PE, HDP, SMP, PVDF |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, AS, etc. |
Color coated steel plate manufactured using cold rolled steel plate and galvanized steel plate as base materials. After surface pretreatment including degreasing, cleaning, and chemical conversion treatment, the coating is applied using continuous roller coating method followed by baking and cooling processes.
- Light weight with beautiful appearance
- Excellent anti-corrosion performance
- Direct processing capability
- Applications: Construction industry, shipbuilding, vehicle manufacturing, home appliances, electrical industry
- Benefits: Steel replaces wood, efficient construction, energy saving, pollution prevention
Steel sheet with zinc coating applied to the surface for effective rust prevention. Approximately half of the world's zinc production is used in galvanization processes.
Surface Requirements:
- Surface states: Regular spangle, small spangle, big spangles, etc.
- Good appearance without harmful defects
- Free from plating defects, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, white rust
Alloy composed of 55% aluminum, 43% zinc and 2% silicon solidified at 600°C, forming a dense tetrad junction crystal structure with aluminized iron, silicon and zinc.
- Superior corrosion resistance - 3 times better than pure galvanized sheet
- Beautiful zinc flower surface decoration for building exterior panels
- Excellent heat resistance - withstands temperatures over 300°C
- Applications: Chimney tubes, ovens, illuminators, solar lampshades
| Product | Pattern print prepainted steel sheet |
|---|---|
| Introduction | Color plate printed on galvanized plate, aluminized zinc plate and other substrates using transfer printing or film covering technology |
| Features | Bright colors, wide variety including marble grain, camouflage, wood grain printing color board |
| Size | Thickness: 0.17 - 1.5mm, Width: less than 1.5mm |
| Color & Pattern | Customized as per client requirements |
| Base Material | Galvanized steel sheet / Galvalume steel sheet |
| Coating Thickness | 20-25um/5-10um |
| Coating Type | Above 2 layers, bottom 1 layer |
| Coil ID | Φ510mm/610mm |
| Application | Household appliances, furniture, doors and windows, indoor and outdoor decoration |
| Minimum Order Quantity | 5 Tons |
|---|---|
| Payment Terms | TT or 100% LC at sight |
| Packing | Standard Sea Worthy Package |
| Loading Port | Shanghai Port, Qingdao Port, Tianjin Port |
| Container Loading | 20ft container FCL, LCL |
| Delivery Time | Within 15 days |
Our company is a modern enterprise specializing in high-end coating plate processing, sales, and circulation, registered in Wuxi City. We offer comprehensive solutions for color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.
Strategic Partnerships: We maintain strong cooperative relationships with major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, Jiangyin Zongcheng Steel.
Applications: Our products are widely used in steel structure buildings, metal building materials, steel silos, ventilation pipes, mechanical and electrical housing, home appliance plates, elevators, purification plates, automotive stamping parts, and various engineering projects.
Expert Team: Our employees average over 8 years of industry experience, enabling us to provide customized supply solutions and improve supply chain efficiency for our clients.
We are committed to providing perfect demand solutions and strive to become China's premier high-end coating and plating steel products service provider.
