JIS G3312 Standard DX51D + Z LFQ Prepainted Color Steel Coil for Container Plate Application
Product Details
| Thickness | 0.12 - 3.0mm (Galvanized), 0.25 - 3.0mm (Galvalume), 0.12 - 1.2mm (Prepainted) | Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm Or Custom |
|---|---|---|---|
| Length | Custom Length | Coil Weight | 2Ton - 8 Tons |
| Coil Inner Diameter | 508mm Or 610mm | Zinc Coating | Z30 - Z275 |
| Aluminum Coating | AZ40 - AZ180 | Painting Type | PE, HDP, SMP, PVDF |
| Surface Finish | Regular Spangle, Non-spangle, Small Spangle, Big Spangles | Coating Thickness | 20-25um/5-10um |
| Coating Layers | Above 2 Layer, Bottom 1 Layer | Pattern Thickness | 0.17 - 1.5mm |
| Heat Resistance | >300°C | Alloy Composition | 55% Al, 43% Zn, 2% Si |
| Edge Type | Slit Edge | ||
| Highlight | JIS G3312 Standard PPGI,DX51D + Z LFQ Color Coated Steel Coil,Container Plate Application Prepainted Color Steel Coil |
||
Product Description
JIS G3312 / 94 CGCC / GB, T 12754 / DX51D + Z LFQ Prepainted Color Steel Coils
High-quality prepainted color steel coils manufactured to international standards including JIS G3312, 94 CGCC, GB T12754, and DX51D + Z LFQ specifications.
Product Specifications
| Product Name | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
|---|---|
| Thickness | Galvanized: 0.12-3.0mm | Galvalume: 0.25-3.0mm | Prepainted: 0.12-1.2mm |
| Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom requirements |
| Length | Custom length as per customer requirements |
| Coil Weight | 2-8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface | Galvanized: Regular spangle/non-spangle (Z30-Z275) | Galvalume: AZ40-AZ180 | Prepainted: PE, HDP, SMP, PVDF coatings |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, AS |
Products Center
Prepainted Galvanized Steel Coil (PPGI)
Color coated steel plates using cold rolled steel and galvanized steel as base plates. After surface pretreatment including degreasing, cleaning, and chemical conversion treatment, continuous coating (roller coating method) is applied followed by baking and cooling.
Features lightweight construction, attractive appearance, and excellent anti-corrosion performance. Suitable for direct processing in construction, shipbuilding, vehicle manufacturing, home appliances, and electrical industries. Effectively replaces wood while enabling efficient construction, energy savings, and pollution prevention.
Galvanized Steel Coil
Zinc-coated steel sheets providing economical and effective rust prevention. Approximately half of the world's zinc production is used for galvanizing processes.
Surface requirements include various treatments producing regular spangle, small spangle, or big spangles. Products feature excellent appearance free from defects such as no plating, holes, cracks, scum, excessive plating thickness, abrasion, chromic acid dirt, or white rust.
Galvalume Steel Coil
Alloy composition of 55% aluminum, 43% zinc, and 2% silicon solidified at 600°C. Structure consists of aluminized iron, silicon, and zinc forming dense tetrad junction crystals.
Offers superior corrosion resistance (3x better than pure galvanized sheet) with decorative zinc flower patterns ideal for building exterior panels. Excellent heat resistance withstands temperatures over 300°C, suitable for chimney tubes, ovens, illuminators, and solar lampshades.
Featured Product: Pattern Print Prepainted Steel Sheet
| Product | Pattern Print Prepainted Steel Sheet |
|---|---|
| Introduction | Color plates printed on galvanized or aluminized zinc substrates using transfer printing or film covering technology |
| Features | Bright colors, variety of patterns including marble grain, camouflage, and wood grain printing |
| Size | Thickness: 0.17-1.5mm | Width: less than 1.5mm |
| Color & Pattern | Customizable to client requirements |
| Base Material | Galvanized steel sheet / Galvalume steel sheet |
| Coating Thickness | 20-25μm/5-10μm |
| Coating Type | Above 2 layers, bottom 1 layer |
| Coil ID | Φ510mm/610mm |
| Application | Household appliances, furniture, doors, windows, indoor and outdoor decoration |
Trade Information
| Minimum Order Quantity | 5 Tons |
|---|---|
| Payment Terms | TT or 100% LC at sight |
| Packing | Standard Sea Worthy Package |
| Loading Port | Shanghai Port, Qingdao Port, Tianjin Port |
| Container Loading | 20ft container FCL, LCL |
| Delivery Time | Within 15 days |
Company Information
Our company is a modern enterprise specializing in high-end coating plate processing, sales, and circulation, registered in Wuxi City. We offer comprehensive solutions including color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.
We maintain strong cooperative relationships with major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, and Jiangyin Zongcheng Steel. Our products are widely used in steel structure buildings, metal building materials, steel silos, ventilation pipes, mechanical and electrical housing, home appliance plates, elevators, purification plates, and automotive stamping parts.
Our experienced team (average 8+ years industry experience) provides customized supply solutions to improve supply chain efficiency. We have participated in material supply and technical services for numerous medium and large engineering projects domestically and internationally.
Committed to our value concept of sustainable development, we strive to provide perfect demand solutions and establish ourselves as China's premier high-end coating and plating steel products service provider.
