Silicon Micron Polyester GB T 12754 Standard Prepainted Color Steel Coils for Container Plate Application
| Thickness | 0.12 - 3.0mm (Galvanized), 0.25 - 3.0mm (Galvalume), 0.12 - 1.2mm (Prepainted) | Width | 914mm,1000mm,1200mm,1219mm,1220mm,1250mm Or Custom |
|---|---|---|---|
| Length | Custom Length | Coil Weight | 2Ton - 8 Tons |
| Coil Inner Diameter | 508mm Or 610mm | Zinc Coating | Z30 - Z275 (Galvanized) |
| Aluminum-Zinc Coating | AZ40 - AZ180 (Galvalume) | Painting Type | PE, HDP, SMP, PVDF (Prepainted) |
| Coating Thickness | 20-25um/5-10um (Pattern Print) | Coating Layers | Above 2 Layer, Bottom 1 Layer (Pattern Print) |
| Surface Finish | Regular Spangle / Non-spangle (Galvanized) | Alloy Composition | 55% Al, 43% Zn, 2% Si (Galvalume) |
| Heat Resistance | >300°C (Galvalume) | Pattern Thickness | 0.17 - 1.5mm (Pattern Print) |
| Sheet Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | ||
| Highlight | Silicon Micron Polyester PPGI,GB T 12754 Standard Color Coated Steel Coils,Container Plate Application Prepainted Color Steel Coils |
||
High-quality prepainted color steel coils featuring silicon micron polyester coating with primer GB, T 12754 specifications. These coils offer superior corrosion resistance and aesthetic appeal for various industrial applications.
| Product Name | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
|---|---|
| Thickness |
Galvanized steel sheet: 0.12 - 3.0mm Galvalume Steel Sheet: 0.25 - 3.0mm Prepainted Galvanized Steel Sheet: 0.12 - 1.2mm |
| Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom requirements |
| Length | Custom length as per customer requirements |
| Coil Weight | 2 - 8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface |
Galvanized steel sheet: Regular spangle / non-spangle Zinc: Z30 - Z275 Galvalume Steel Sheet: AZ40 - AZ180 Prepainted Galvanized Steel Sheet: Painting Type: PE, HDP, SMP, PVDF |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, AS, etc. |
Also known as color plate, these coated steel plates use cold rolled steel and galvanized steel as base plates. After surface pretreatment including degreasing, cleaning, and chemical conversion treatment, they undergo continuous coating via roller coating method followed by baking and cooling.
- Light weight with beautiful appearance
- Excellent anti-corrosion performance
- Direct processing capability
- Applications: Construction, shipbuilding, vehicle manufacturing, home appliances, electrical industry
- Benefits: Steel replaces wood, efficient construction, energy saving, pollution prevention
Zinc-coated steel sheets providing economical and effective rust prevention. Approximately half of the world's zinc production is used in galvanization processes.
Various surface states available including regular spangle, small spangle, and big spangles. All products feature excellent appearance without harmful defects such as no plating, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, or white rust.
Advanced alloy composition of 55% aluminum, 43% zinc, and 2% silicon solidified at 600°C, forming dense tetrad junction crystal structure.
- Superior corrosion resistance - 3 times better than pure galvanized sheet
- Beautiful zinc flower surface decoration for building exterior panels
- Excellent heat resistance - withstands temperatures over 300°C
- Applications: Chimney tubes, ovens, illuminators, solar lampshades
- Aluminum provides primary protective function
| Product | Pattern Print Prepainted Steel Sheet |
|---|---|
| Introduction | Color plates printed on galvanized or aluminized zinc substrates using transfer printing or film covering technology |
| Features | Bright colors, wide variety including marble grain, camouflage, wood grain patterns |
| Size | Thickness: 0.17 - 1.5mm (Width less than 1.5mm) |
| Color & Pattern | Customized as per client requirements |
| Base Material | Galvanized steel sheet / Galvalume steel sheet |
| Coating Thickness | 20-25um / 5-10um |
| Coating Type | Above 2 layers, bottom 1 layer |
| Coil ID | Φ510mm / 610mm |
| Application | Household appliances, furniture, doors and windows, indoor and outdoor decoration |
| Minimum Order Quantity | 5 Tons |
|---|---|
| Payment Terms | TT or 100% LC at sight |
| Packing | Standard Sea Worthy Package |
| Loading Port | Shanghai Port, Qingdao Port, Tianjin Port |
| Container Loading | 20ft container FCL, LCL |
| Delivery Time | Within 15 days |
Our company is a modern enterprise specializing in high-end coating plate processing, sales, and circulation, registered in Wuxi City. We offer comprehensive solutions for color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.
We maintain excellent cooperative relationships with major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, and Jiangyin Zongcheng Steel.
Applications: Steel structure buildings, metal building materials, steel silos, ventilation pipes, mechanical and electrical housing, home appliance plates, elevators, purification plates, automotive stamping parts, and other industrial fields.
Expertise: Our employees average over 8 years of industry experience, enabling us to provide customized supply solutions and improve supply chain efficiency for our clients.
Since establishment, we have participated in material supply and technical services for numerous medium and large engineering projects domestically and internationally.
Committed to providing perfect demand solutions while guiding China's development as a high-end coating and plating steel products service provider.
