EN 1.4462 & 1.4410 Duplex Stainless Steel Plate Laser Cutting Thickness 2.0 - 80.0mm With Smooth Edge
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 2205 2507 |
| Minimum Order Quantity | 500 kgs |
| Price | 3200 - 3600 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 2205 2507 |
|---|---|---|---|
| Standard Size | 1500*6000mm | Thickness | 2.0 - 40.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 500 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | Duplex stainless steel plate laser cutting,EN 1.4462 stainless steel plate,1.4410 duplex steel smooth edge |
||
Product Description
EN 1.4462 & 1.4410 Duplex Stainless Steel Plate Laser Cutting Thickness 2.0 - 80.0mm With Smooth Edge
Products Specification
| Products | Duplex Stainless Steel Plate |
| Thickness | 1.0- 40.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
EN 1.4462 & 1.4410 Duplex Stainless Steel Plate – Precision Laser Cutting, Thickness 2.0–80.0 mm, Smooth Edge Guaranteed
High-Performance Duplex Plates, Expertly Cut for Demanding Applications
We specialize in CNC laser cutting of EN 1.4462 (Duplex 2205) and EN 1.4410 (Super Duplex 2507) stainless steel plates in thicknesses ranging from 2.0 mm to 80.0 mm, delivering smooth, burr-free edges with tight dimensional tolerances. Whether you require simple blanks or complex components for oil & gas, marine, chemical processing, or desalination systems, our advanced cutting technology ensures your parts are fabrication-ready—often without secondary finishing.
Backed by full material traceability and compliance with EN 10088-2, ASTM A240, NORSOK M-650 (for 1.4410), and other global standards, our service combines metallurgical integrity with precision engineering.
Material Overview: EN 1.4462 vs. EN 1.4410
| Property | EN 1.4462 (Duplex 2205) | EN 1.4410 (Super Duplex 2507) |
|---|---|---|
| UNS Equivalent | S32205 / S31803 | S32750 |
| Type | Standard Duplex | Super Duplex |
| Microstructure | ~50% Austenite + 50% Ferrite | Balanced dual-phase (optimized for strength & corrosion) |
| PREN (Pitting Resistance)* | 34–38 | 40–45 |
| Yield Strength (Rp0.2) | ≥450 MPa | ≥550 MPa |
| Tensile Strength (Rm) | 620–750 MPa | 750–950 MPa |
| Max Service Temp | ~300°C | ~280°C |
| Key Alloying Elements | Cr 22%, Ni 5.5%, Mo 3.2%, N 0.17% | Cr 25%, Ni 7%, Mo 4%, N 0.28% |
| Typical Applications | Chemical tanks, heat exchangers, pipelines | Subsea manifolds, seawater systems, FGD scrubbers |
*PREN = %Cr + 3.3×%Mo + 16×%N — higher = better pitting resistance.
Laser Cutting Capabilities: 2.0–80.0 mm with Smooth Edges
Cutting thick duplex stainless steel requires specialized expertise to avoid microstructural degradation and edge defects. Our hybrid approach ensures quality across the full thickness range:
| Thickness Range | Cutting Technology | Edge Quality | Notes |
|---|---|---|---|
| 2.0 – 25.0 mm | High-power fiber laser | ISO 9013 Class 2 | Ultra-smooth, vertical kerf; minimal dross |
| 25.1 – 50.0 mm | High-precision CO₂ laser | ISO 9013 Class 2–3 | Clean cut with slight taper (<2°); nitrogen assist |
| 50.1 – 80.0 mm | Advanced oxygen-assisted CO₂ laser + post-processing | ISO 9013 Class 3 | Smooth finish achieved via optimized parameters and light grinding if required |
✅ All cuts use high-purity nitrogen or argon assist gas to prevent oxidation
✅ Heat input is tightly controlled to avoid sigma/chi phase formation in the HAZ
✅ Edges are smooth enough for direct welding or assembly in most cases
✅ Heat input is tightly controlled to avoid sigma/chi phase formation in the HAZ
✅ Edges are smooth enough for direct welding or assembly in most cases
Technical Specifications
| Feature | Details |
|---|---|
| Material Grades | EN 1.4462 (X2CrNiMoN22-5-3), EN 1.4410 (X2CrNiMoN25-7-4) |
| Thickness Range | 2.0 mm to 80.0 mm |
| Standard Plate Sizes | 2000×6000 mm, 2500×6000 mm, 3000×12000 mm (custom blanks available) |
| Surface Finish | Hot-rolled (standard), pickled & passivated (optional) |
| Dimensional Tolerance | ±0.1 mm (≤10 mm), ±0.2 mm (10–30 mm), ±0.5 mm (>30 mm) |
| Edge Roughness (Ra) | ≤12.5 µm (typically 6.3–10 µm for <25 mm) |
| Certifications | EN 10204 3.1/3.2, ASTM A240, NORSOK M-650 (1.4410), PMI traceable |
| File Formats Accepted | DXF, DWG, STEP, IGES, PDF (with dimensions) |
Why Smooth Edges Matter in Duplex Steels
Rough or oxidized cut edges can:
- Act as initiation sites for pitting or crevice corrosion
- Require time-consuming grinding before welding
- Compromise fatigue performance in dynamic loads
Our smooth-edge laser process eliminates these issues by:
- Preventing scale formation through inert gas shielding
- Minimizing recast layer and micro-cracks
- Maintaining the alloy’s natural passive layer integrity
This is especially critical for EN 1.4410, which is often used in seawater, sour gas, or high-chloride environments where surface quality directly impacts service life.
Applications by Industry
| Industry | Typical Components (Laser-Cut from 1.4462 / 1.4410) |
|---|---|
| Oil & Gas | Christmas trees, manifolds, choke valves, flowlines |
| Offshore & Marine | Riser clamps, seawater piping, ballast system parts |
| Chemical Processing | Reactor internals, distillation trays, acid storage vessels |
| Desalination | High-pressure RO housings, brine heater tubesheets |
| Power & Energy | Flue gas desulfurization (FGD) ducts, heat exchanger plates |
| Pulp & Paper | Bleach plant towers, digester components |
Quality Assurance Process
- Material Verification: All plates sourced from certified mills with full MTRs
- PMI Testing: Optional XRF/OES verification before and after cutting
- Process Control: Laser parameters logged per job (power, speed, gas pressure)
- Inspection: Visual + dimensional checks per ISO 9013; UT available for >40 mm
- Finishing: Optional pickling/passivation or light grinding for ultra-smooth edges
Ordering Information
- Minimum Order: 1 piece
- Lead Time: 5–15 working days (depending on thickness and complexity)
- Secondary Services: Beveling, marking (laser/engraving), protective film, export packaging
- Global Shipping: FOB, CIF, or DDP options available
Simply send your CAD drawing, specify EN 1.4462 or 1.4410, thickness, and quantity—we’ll handle the rest.
Sustainability & Lifecycle Value
EN 1.4462 laser cutting, EN 1.4410 stainless steel plate, duplex steel smooth edge cut, 2mm to 80mm laser cut duplex, Super Duplex 2507 plate cutting, 1.4410 smooth edge laser, thick duplex stainless steel fabrication, PREN 40 plate laser cut, offshore grade stainless steel parts, CNC laser cut 1.4462 1.4410.
