AISI 309 Stainless Steel Sheet 309S 0.6-16.0mm 1500mm 1219mm 1000mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 309S |
| Minimum Order Quantity | 500 kgs |
| Price | 2100-5300 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 309S/1.4833/S30908 |
|---|---|---|---|
| Thickness | 0.4 - 16.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 2B | Brand | TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | AISI 309 stainless steel sheet,309 stainless steel sheet 309S,1000mm ss sheets |
||
Product Description
AISI309 Stainless Steel Plate Alloy 309S Stainless Plate Thickness 0.6 - 16.0mm Cutsom Cutting
Stainless steel 309 309S 310 310S grade:
The 309 stainless steel has a higher corrosion resistance and strength compared to 304 stainless steel. This product is versatile and known for its high heat treatment capabilities.Great ductility, weldability, and high-temperature properties make 310 Stainless Steel the ideal choice for projects that require service at temperatures up to 1150 degrees Celsius. Grade 310 resists oxidation and is also used at temperatures up to 1040 degrees Celsius intermittently. Similar to other austenitic steel grades, toughness down to cryogenic temperatures is another feature of 310.
AISI309 309S stainless steel plate Specification
| Item | Description |
| Standard | ASTM A240 / AISI / DIN / JIS / GB |
Grade |
201/202 |
| 304/304L/304H/309S/310S/316L/316Ti/317L/321//S31803/S32205/904L | |
| 409L/410S/420J1/J2/430 439 441 444 446 | |
| Thickness | 0.3-6.0mm for cold sheet scope; 3.0-100mm for hot rolled scope |
| Width&Length | 1000mm/1219mm/1500mm/1800mm/2000mm |
| Length from cutting, as requirement | |
| Surface | Mill surface: 2B/BA/No.1 |
| Processing surface: 8k mirror/Hairline/No.4 Satin/Bead blast/Color etched | |
| Protection | Transparent film/ Blue fulm/PVC film or laser film |
| Package | Standard export package with metal pallet + angle bar protection + |
| Processing | Edging/Laser(Plasma/Water Jet) cutting/Leveling/Slitting |
Regular Size of our 309S Stainless Steel Plate in stock
| Thickness/mm | Size 1 / mm | Size 2 / mm | Size 3 / mm |
| 0.6mm | 1000*2000mm | 1219*2438mm | / |
| 0.8mm | 1000*2000mm | 1219*2438mm | 1500*3000mm |
| 1.0mm | 1000*2000mm | 1219*2438mm | 1500*3000mm |
| 1.2mm | 1000*2000mm | 1219*2438mm | 1500*3000mm |
| 1.5mm | 1000*2000mm | 1219*2438mm | 1500*3000mm |
| 2.0mm | 1000*2000mm | 1219*2438mm | 1500*3000mm |
| 2.5mm | 1000*2000mm | 1219*2438mm | 1500*3000mm |
| 3.0mm | 1000*2000mm | 1219*2438mm | 1500*6000mm |
| 4.0mm | / | / | 1500*6000mm |
| 5.0mm | / | / | 1500*6000mm |
| 6.0mm | / | / | 1500*6000mm |
| 8.0mm | / | / | 1500*6000mm |
| 10.0mm | / | / | 1500*6000mm |
| 12.0mm | / | / | 1500*6000mm |
| 14.0mm | / | / | 1500*6000mm |
| 16.0mm | / | / | 1500*6000mm |
Stainless steels are a family of iron based alloys that contain a minimum of 10.5% chromium (CR). The presence of chromium creates an invisible surface film that resists oxidation and makes the material passive or corrosion resistant (stainless). There are multiple families of stainless steel which are designed for various applications and uses. Stainless grades can be further modified to meet various processing, corrosion, temperature and strength conditions.
About 309/309S Stainless Steel
Type 309 (UNS S30900)
Description
Type 309 is a high temperature chromium nickel austenitic stainless steel that resists oxidation at temperatures up to 1900˚F in dry air at constant temperature. Under thermal cycling conditions this grade resists oxidation up to a temperature of approximately 1850˚F. Type 309 has good sulfidation resistance but low resistance to carburization and should not be used in highly carburizing atmospheres. Type 309 is non-magnetic in the annealed and cold worked conditions and is as resistant to corrosion as Type 304/304L.
Chemical Composition of 309/309S Stainless Steel
| Element | 309 |
| Carbon | 0.20 |
| Chromium | 22.0-24.0 |
| Nickel | 12.0-15.0 |
| Manganese | 2.00 |
| Silicon | 0.75 |
| Phosphorus | 0.045 |
| Sulfur | 0.030 |
Mechanical Properties of 309/309S Stainless Steel
| Property | 309 |
| Yield Strength, min. (ksi) | 30 |
| Tensile Strength, min. (ksi) | 75 |
| Elongation, min. (%) | 40 |
| Hardness, max. (Rb) | 95 |
Physical properties of 309/309S stainless steel
| Property | 309 |
| Density, lb/in3 | 0.285 |
| Modulus of Elasticity, psi | 29.0 x 106 |
| Coefficient of Thermal Expansion, 68-212˚F, /˚F | 8.7 x 10-6 |
| Thermal Conductivity, Btu/ft hr ˚F | 9.0 |
| Specific Heat, Btu/lb ˚F | 0.12 |
| Electrical Resistivity, Microohm-in | 30.7 |
Features
- Corrosion Resistance: 309 stainless stands-up excellently in a range of atmospheric environments even when exposed to corrosive elements.
- Heat Resistance: Can be hot worked at 1177C and then can be quenched rapidly.
- Easy to weld by using fusion or resistance welding methods (preferably not oxyacetylene though).
- Can be headed, upset, drawn, and stamped even though it has high work hardening rate.
Applications
The 309 can be applied to a range of applications including a variety of accessories and equipment such as boiler baffles, furnace components, oven linings, fire box sheets, and other high temperature containers.
AISI309 309S stainless steel plate
