Laser Cutting 431 Stainless Steel Plate Thickness 10mm 12mm 16mm SS Plate Alloy 431
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 304 304L 316L 310S 321 2205 2507 904L 254SMO.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 5000 - 7200 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 304 304L 316L 310S 321 2205 2507 904L 254SMO.etc |
|---|---|---|---|
| Thickness | 0.6 - 30.0mm | Width | 1219mm 1500mm 1800mm 2000mm |
| Surface | NO.1 2B | Brand | BAOSTEEL TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
Product Description
Laser Cutting 431 Stainless Steel Plate Thickness 10mm 12mm 16mm SS Plate Alloy 431
Products Specification
| Products Name | Laser Cutting Stainless Steel Plate |
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 317L, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,654SMO,253MA,2205,2507.etc |
| Thickness | 0.6 - 30.0mm |
| Width | 1250mm,1500mm ,1800mm,2000mm, or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Service | Laser Cutting |
| Form | Plate / sheet |
| Cutting Shape | Round , Square, or any special shape as request |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Brand | TISCO, LISCO,BAOSTEEL , POSCO, JISCO |
431 is a martensitic stainless steel known for its high strength, good corrosion resistance, and moderate toughness, primarily alloyed with chromium and nickel.
-
Chemical Composition (wt%):
- Carbon (C): 0.15% max
- Chromium (Cr): 15.00–17.00%
- Nickel (Ni): 1.25–2.50%
- Manganese (Mn): 1.00% max
- Silicon (Si): 1.00% max
- Phosphorus (P): 0.040% max
- Sulfur (S): 0.030% max
-
Mechanical Properties (annealed condition):
- Tensile strength: ≥620 MPa
- Yield strength (0.2% offset): ≥430 MPa
- Elongation: ≥20%
- Hardness: ≤235 HB (brinell) or ≤99 HRB (rockwell)
-
Physical Properties:
- Density: ~7.75 g/cm³
- Thermal conductivity: ~25 W/(m·K) (at 20°C)
- Coefficient of thermal expansion: ~10.0×10⁻⁶/°C (20–100°C)
Standards
431 stainless steel is specified under the following standards:
- ASTM A240/A240M: Covers plates, sheets, and strips, designated as 431.
- UNS: Unified Numbering System designation is S43100.
- EN 10088-2: European standard, classified as X5CrNi17-2 (material number: 1.4057).
Equivalent Grades
- USA: UNS S43100, ASTM 431
- Europe: EN 1.4057 (X5CrNi17-2)
- Japan: JIS SUS431
- China: GB 1Cr17Ni2
Applications
431 stainless steel is valued for its balance of strength and corrosion resistance, making it suitable for:
- Automotive industry: Components like valve stems, exhaust systems, and high-strength fasteners.
- Aerospace: Parts requiring high tensile strength and resistance to atmospheric corrosion, such as aircraft fittings.
- Oil and gas: Valves, pumps, and shafts for medium-corrosion environments.
- Medical equipment: Surgical instruments and orthopedic implants (due to biocompatibility and strength).
- General engineering: Gear shafts, bolts, and high-strength structural parts in mildly corrosive conditions.
Laser Cutting of 431 Stainless Steel Plate
Laser cutting is a highly effective method for processing 431 stainless steel, offering distinct advantages for both thin and medium-thickness plates.
-
Processing Range:
- Suitable for plate thicknesses typically up to 20mm, depending on laser power (e.g., 3–6 kW fiber lasers handle 1–15mm efficiently; higher-power lasers can cut thicker materials).
- Capable of cutting complex shapes, precision holes, slots, and custom profiles with minimal setup changes.
-
Key Advantages:
- High Precision: Narrow kerf width (0.1–0.3mm) and tight tolerances (±0.05mm), ideal for intricate designs.
- Minimal Heat-Affected Zone (HAZ): Reduces material distortion and preserves the mechanical properties (e.g., strength, corrosion resistance) of 431, unlike plasma or oxy-fuel cutting.
- Clean Edges: Produces burr-free, smooth edges, eliminating the need for post-processing (e.g., grinding).
- Efficiency: Faster cutting speeds for thin to medium plates compared to mechanical methods (e.g., sawing), with no tool wear.
- Versatility: Adaptable to various plate sizes and geometries, supporting both small-batch prototyping and large-scale production.
