Alloy S41500 / 1.4418 / 0Cr13Ni5Mo / F6NM Alloy Stainless Steel Round Bar Hot Rolled ASTM A276

Place of Origin	China
Brand Name	Delta
Certification	ISO 9001
Model Number	1.4418 / S135 / F6NM / 0Cr13Ni5Mo / S41500
Minimum Order Quantity	500 kgs
Price	2500-3200 USD/Ton
Packaging Details	wooden box or water resistant paper surround
Delivery Time	5 - 10 days
Payment Terms	T/T, Western Union
Supply Ability	50 Ton per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Products Name	1.4418 Stainless Steel Bar	Diameter	10 - 350mm
Length	6m Or Cutting Any Length As Request	Surface	Pickling Or Bright
Service	Cutting	Standard	ASTM DIN GB EN
Other Products	Round Bar, Square Bar, Flat Bar.etc	Technique	Hot Rolled
Highlight	1.4418 Stainless Steel Round Bar , S41500 Stainless Steel Round Bar , ASTM A276 Stainless Round Bar

Leave a Message

Product Description

Alloy S41500 / 1.4418 / 0Cr13Ni5Mo / F6NM Alloy Stainless Steel Round Bar Hot Rolled ASTM A276

Products Specification

Products Name	Stainless Steel Round Bar
Grade	1.4418 / S135 / F6NM / 0Cr13Ni5Mo / S41500
Products Diameter Range	φ10mm - φ350mm
Length	6.1m/pcs or cutting any length as request
Surface	Pickling finishing, bright finishing
Other Grade	304,304L,309S,310S,310H,316L,316Ti,316H,317L,321,329,347,410,415,420, 430F,431,440A/B/C,2205,2507,904l,254SMO,253MA,CD4MCU,XM-19,17-4PH,15-5PH,17-7PH,C276,600,601,625,718,800,800H,825,926.etc
Standard	ASTM JIS,GB,DIN EN
Service	Cutting
Other Shape	Square , Flat, Hexagonal, Round.etc
Loading Port	Shanghai Port
MOQ	500 kgs

0Cr13Ni5Mo Stainless Steel Bar: Properties, Applications & SEO-Optimized Guide

What Is 0Cr13Ni5Mo Stainless Steel Bar?

0Cr13Ni5Mo is a martensitic stainless steel grade renowned for its exceptional balance of high strength, toughness, and corrosion resistance. Widely used in critical industrial applications, this alloy is recognized for its ability to withstand harsh environments while maintaining structural integrity. In international standards, it may be equivalent to grades like ASTM A240 Type 415 or UNS S41500, though regional specifications may vary.

Chemical Composition of 0Cr13Ni5Mo

Key chemical elements (in weight percentage):

Carbon (C): ≤0.05%
Chromium (Cr): 12.0–14.0%
Nickel (Ni): 4.5–5.5%
Molybdenum (Mo): 0.5–1.0%
Manganese (Mn): ≤1.0%
Silicon (Si): ≤0.75%
Phosphorus (P): ≤0.04%
Sulfur (S): ≤0.03%

Chromium provides corrosion resistance, nickel enhances toughness and weldability, and molybdenum improves strength and resistance to pitting corrosion.

Mechanical Properties

Typical mechanical properties after quenching and tempering:

Tensile Strength: ≥780 MPa (113 ksi)
Yield Strength: ≥620 MPa (90 ksi)
Elongation at Break: ≥15%
Hardness: 22–32 HRC
Impact Toughness: ≥50 J (at room temperature)

These properties make it suitable for high-stress applications requiring resistance to both mechanical load and corrosion.

Corrosion Resistance

0Cr13Ni5Mo exhibits excellent corrosion resistance in:

Atmospheric conditions
Freshwater and seawater environments
Mild acidic or alkaline solutions
Chloride-containing media (better than standard martensitic steels)

While not as corrosion-resistant as austenitic grades like 316L, its martensitic structure allows heat treatment for tailored strength, making it ideal for applications where both durability and resistance to moderate corrosion are critical.

Fabrication and Heat Treatment

Machinability: Good machinability when annealed; proper lubrication and tooling are recommended for optimal results.
Weldability: Can be welded using TIG, MIG, or submerged arc welding. Preheating (100–200°C) and post-weld tempering (600–650°C) are advised to prevent hydrogen cracking.
Heat Treatment Steps:
- Annealing: 800–850°C, slow cooling to improve ductility.
- Quenching: 950–1050°C, oil or air cooling to achieve martensitic structure.
- Tempering: 200–650°C (adjusted based on required hardness-toughness balance).

Common Applications of 0Cr13Ni5Mo Stainless Steel Bar

Marine Engineering: Ship propeller shafts, offshore platform components, and seawater pumps.
Oil & Gas Industry: Valves, wellhead equipment, and pipelines in mildly corrosive environments.
Aerospace: Landing gear components, structural parts, and fasteners.
Hydraulic Systems: High-pressure cylinders and shafts.
Chemical Processing: Equipment for non-aggressive chemical media.
Military & Defense: Armor components and tactical gear.

Advantages of 0Cr13Ni5Mo Stainless Steel

High Strength-to-Weight Ratio: Suitable for lightweight, load-bearing structures.
Toughness in Low Temperatures: Maintains ductility in cold environments.
Weldability with Proper Procedures: Enables complex component fabrication.
Cost-Effective vs. High-Nickel Alloys: Balances performance and affordability.
Customizable Properties: Heat treatment allows tailoring for specific applications.

SEO-Optimized Keywords for 0Cr13Ni5Mo

0Cr13Ni5Mo stainless steel bar
0Cr13Ni5Mo steel properties
0Cr13Ni5Mo chemical composition
Martensitic stainless steel 0Cr13Ni5Mo
0Cr13Ni5Mo stainless steel applications
0Cr13Ni5Mo equivalent ASTM/UNS
0Cr13Ni5Mo mechanical properties
0Cr13Ni5Mo stainless steel suppliers

Standards and Specifications

Chinese Standards:
- GB/T 20878 (Stainless Steel Grades)
- GB/T 1220 (Stainless Steel Bars)
International Equivalents:
- ASTM A276 (Type 415)
- UNS S41500
- EN 10088-3 (X2CrNiMo13-5-2)
