UNS S44600 Stainless Steel Plate Alloy 446 SS Plate 1.0 - 30.0mm Cold Rolled Hot Rolled
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | UNS S44600 / 446 |
| Minimum Order Quantity | 500 kgs |
| Price | 2100-2500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | UNS S38815 / Alloy 825 / 1.4858 |
|---|---|---|---|
| Width | 1500mm 1219mm 1000mm | Surface | NO.1 2B |
| Brand | POSCO TISCO BAOSTEEL | Standard | ASTM A240/240M |
| Loading Port | Shanghai Port | Thickness | 1.0 - 30.0mm |
| Highlight | Alloy 446 Stainless Steel Plate,UNS S44600 Stainless Steel Plate,30mm Hot Rolled Stainless Steel Plate |
||
Product Description
Products Specification
| Product name | 446 Stainless Steel Plate |
| Standard | GB,JIS,DIN,AISI,ASTM,AISI,ASME |
| Thickness | 1.0- 30.0mm |
| Width | 1219 ,1500mm, or as your requirements |
| Length | 3000,6000mm, or as your requirements |
| MOQ | 1MT |
| Surface | 2B NO.1 HL NO.4 8K,checkered |
| Other Grade |
201 304 304L 309S 310S 316L 317L 316LN 321 347 329 409L 410 415 416 420 430 431 436L 439 440A/B/C 444 446 904L 2205 2507 254SMO 253MA ,1.4529,1.4828 Monel400 k500, Inconel 600,601,625,718, Incoloy 800 800H,C276.etc |
| Packing | standard export packing (inside:water proof paper,outside:steel covered with strips and pallets) |
| Cargo ready date | within 25-35 days after confirming orders |
| Delivery Time | About 5-7 days after receive the deposit. |
1. Basic introduction
446 stainless steel is a high chromium ferritic stainless steel (chromium content of about 23-30%), with excellent high temperature oxidation resistance, corrosion resistance and good mechanical properties. Because of its high chromium content, it is especially suitable for high temperature vulcanization and oxidation environment, but its toughness is low, and it should be avoided in low temperature or impact environment.
2. Main parameters (typical values)
Item parameter value
- Chemical composition of C 0.20% or less, Cr: 23-27% Mn 1.5% or less, Si 1.0% or less, P 0.04% or less, S 0.03% or less, N 0.25% or less
- Density 7.7 g/cm³
- Melting point 1425-1510°C
- Tensile strength ≥515 MPa
- Yield strength ≥275 MPa
- Elongation ≥20%
- Hardness (Brinell) ≤201 HB
- Thermal conductivity 24 W/m·K (20°C)
- Magnetic magnetic (ferrite structure)
3. Main features
- High temperature oxidation resistance: can be used continuously below 1100°C, high temperature oxidation resistance is better than 304/316 stainless steel.
- Corrosion resistance: It has good resistance to nitric acid, organic acid and vulcanization environment, but it is not as resistant to chloride corrosion as austenitic stainless steel.
- Vulcanization resistance: Suitable for sulfur-containing fuel combustion environment (such as boilers, incinerators).
- Disadvantages: low temperature brittleness (avoid using below 0°C), poor welding performance, need to control the heat input.
4. Common specifications
- Thickness: 1.0mm ~ 30mm (cold rolled/hot rolled plate)
- Width: 1000mm ~ 2000mm (conventional)
- Length: 2000mm ~ 6000mm (customizable)
- Surface treatment: 2B (cold rolling bright), No.1 (hot rolling pickling), BA (bright annealing), etc.
5. International standard comparison
Standard system brand
- ASTM UNS S44600
- JIS SUS 446
- GB 1Cr25Mo3Ti (approximate)
- EN 1.4713
6. Typical application areas
- High temperature equipment: furnace components, heat exchangers, annealing hoods, burner nozzles.
- Environmental protection energy: waste incinerator, boiler lining, exhaust pipe.
- Chemical equipment: nitric acid production equipment, pickling tank (avoid chlorine-containing media).
- Others: solar thermal power components, automotive exhaust system high temperature section.
7. Precautions
- Welding: A low heat input process, such as TIG welding, is required and preheated to 150-200°C to reduce the risk of cracking.
- Processing: Annealing (780-850°C) is recommended after cold forming to restore corrosion resistance.
- Avoid: chloride-containing solution and low temperature impact on the environment.
For more specific performance data or selection recommendations, refer to ASTM A240/A240M or consult the material supplier.
