Heat Resistant 310S 309S 321 347 800H Stainless Steel Pipe / Seamless Steel Pipe for Boiler

Heat Resistant 310S 309S 321 347 800H Stainless Steel Pipe / Seamless Steel Pipe for Boiler

This grade of stainless steel is suitable for the manufacture of vehicle or other motor exhausts.

These stainless steel have the good heat-resisting performance, is suitable in the steam environment or 550℃ and the above temperature.

• 310S Stainless steel is a combination of good strength and corrosion resistance in temperature up to 2100oF (1149℃). Due to its relatively high chromium and nickel content it is superior in most environments to 304 or 309 stainless.
• 309S High corrosion-resistant, chromium nickel grade with carbon limited to .08 to reduce carbon precipitation during welding. Maximum Recommended Service Temperature Continuous 1100℃ /Intermittent 980℃
• 304H the carbon content is controlled to a range of 0.04-0.08 to provide improved high temperature strength to parts exposed to temperatures above 800°F (427℃)
• 321H advantage an excellent resistance to intergranular corrosion following exposure to temperatures in the chromium carbide precipitation range from 800 to 1500°F (427℃ to 816°C).
• 347H in higher elevated temperature allowable stresses for these stabilized alloys for ASME Boiler and Pressure Vessel Code applications. The 321 and 347 alloys have maximum use temperatures of 1500°F (816°C)

Heat exchanger Tubes are used in all types of process industries. Characteristic requirements are: bead worked weld, fixed lengths and extensive testing.

In order to meet the demand for rapid delivery, we have a strip stock with both standard and special grades of steel in the most common thicknesses.

We supply both seamless and welded tubes which meet the requirements for shell and tube heat exchangers:

• ASTM A213/A213M Seamless tube
• ASTM A556M-88/ASME SA556 heater tubes 1
• ASTM A249/A249M Welded tube

Size range 6.35mm - 76.2mm OD x 0.91mm – 3.25mm wall thickness

Heat exchanger tubes are supplied in Standard Wire Gauge (SWG) or Birmingham Wire Gauge (BWG)

Popular grades: 1.4306 (304L), 1.4404 (316L)

ASTM A213 SA213 304H 321H 316H 347H 309S 310S 310H S30432 Stainless Steel Pipe

These Stainless Steel Pipe have the good heat-resisting performance, is suitable in the steam environment or 550°C and the above temperature. Mainly grade include: 253MA S30815, 353MA S35315, 254SMo S31254, N04400 / Monel 400, N06600 / Inconel 600, N06601 / Inconel 601, N06617, N06625 / Inconel 625, N06690 / Inconel 690, N08800 / Incoloy 800, N08810 Incoloy 800H, N08811 Incoloy 800HT, N08825 Incoloy 825, N08020 / Alloy 20, N08367, N08028, N06985, N06022, N10276 C276.

310S Stainless steel is a combination of good strength and corrosion resistance in temperature up to 2100°F (1149°C). Due to its relatively high chromium and nickel content it is superior in most environments to 304 or 309 stainless steel.

309 Stainless Steel High& corrosion-resistant, chromium nickel grade with carbon limited to .08 to reduce carbon precipitation during welding. Maximum Recommended Service Temperature Continuous 1100°C /Intermittent 980°C

304H the carbon content is controlled to a range of 0.04-0.08 to provide improved high temperature strength to parts exposed to temperatures above 800°F (427°C)

321H advantage an excellent resistance to intergranular corrosion following exposure to temperatures in the chromium carbide precipitation range from 800°F to 1500°F (427°C to 816°C).

347H and 347HFG in higher elevated temperature allowable stresses for these stabilized alloys for ASME Boiler and Pressure Vessel Code applications. The 321 and 347 alloys have maximum use temperatures of 1500°F (816°C)

Reheater Tubes and Superheater Tubes Boiler Tube Mechanical Properties and Working Temperatures

310S | 309S | 304H | 321H | 347H

Standard: ASTM A213,EN 10216-5

Anticorrosion environment: The temperature may reach 800°C

• Application: Boiler,etc
• 310S | 309S | 304H | 321H | 347H
• Standard: ASTM A213, EN 10216-5
• Anticorrosion environment: The temperature may reach 800°C
• Application: Boiler Tube
• 1.4828-X15CrNiSi20-12
• Standard :SEW 470,DIN EN 10095
• Equal to :Avesta 4828,Uginox R20-12,Cronifer 2012
• Anticorrosion environment: The temperature may reach 1000°C , the oxygen content low azotic gas.
• Apply to: Makes the furnace, the petrochemical industry
• 1.4841-X15CrNiSi25-21
• Standard :SEW 470,DIN EN 10095
• Equal to :Cronifer 2520
• Anticorrosion environment: The temperature may reach 1100°C , the oxidation and the reducing gas (low sulphur content)
• Apply to: Makes the furnace, the petrochemical industry
• 1.4876-X10NiCrAITi32-21
• Standard:SEW 470,VdTUV-Wbl.412,DIN EN 10095
• Equal to:Nicrofer 3220/3220H,Incoloy 800
• Anticorrosion environment: The temperature may reach 1100°C , the long time barometric pressure or the vapor tension
• Apply to: The heat change installment, the steam response ins tallment, make the furnace, the petrochemical industryTable 1 Short Term Tensile Strength vs Temperature (in the annealed condition except for 410)

* heat treated by oil quenching from 1800° F and tempering at 1200° FTable 2 Generally Accepted Service Temperatures
