Grade 304 6m Length ISO 9001 Stainless Steel U Channel Bar with Bright Surface

Cantidad de orden mínima	30 kilos
Precio	US $1.75-3.46 / kg

Datos del producto

Forma	canal U	Técnica	laminado en caliente
Tratamiento superficial	Brillante	Rango de especificaciones	3030-100100
Calificación	304	Longitud	6m
Tamaño de la barra angular	30303 - 20020010mm	Tamaño de la barra de canales	50303 - 20010010mm
Rango de espesor	3-12 mm	Peso por el metro	0,894-15,0 kg
Material	Acero inoxidable	Estándar	ASTM GB DIN
Servicio de procesamiento	Corte	embalaje	Palets de papel o madera impermeables.
Rango de tamaño	20×20 - 200×100mm
Resaltar	Grade 304 Stainless Steel U Channel , 6m Length Stainless Steel Channel Bar , ISO 9001 U Channel Bar

Deja un mensaje

Descripción de producto

Grade 304 6m Length ISO 9001 Stainless Steel U Channel

Product Specifications

Product Name: Stainless Steel Angle Bar / Stainless Steel Channel Bar
Available Grades: 201, 304, 310S, 316L, 321, 2205, etc.
Standards: ASTM, GB, DIN
Angle Bar Size Range: 30×30×3 - 200×200×10mm × 6m length
Channel Bar Size Range: 50×30×3 - 200×100×10mm × 6m length
Services: Custom cutting available
Packaging: Waterproof paper wrapping or wooden pallets
Brand: TSINGSHAN

Standard Stainless Steel Angle Bar Dimensions & Weights

Size A×B (mm)	3mm	4mm	5mm	6mm	7mm	8mm	9mm	10mm
20×20	0.894	1.13	1.38
25×25	1.13	1.45	1.77	2.06
30×30	1.37	1.77	2.17	2.53
35×35	1.61	2.09	2.57	3.01
40×40	1.85	2.41	2.97	3.49
45×45	2.12	2.76	3.40	4.00
50×50	2.36	3.07	3.79	4.46	5.13	5.76	6.42	7.06
60×60			4.58	5.42	6.24	7.03
63×63			5.03	5.95	6.84	7.71	8.60	9.48
70×70			5.42	6.42	7.39	8.34	9.31	10.3
75×75			5.82	6.89	7.95	8.97	10.0	11.1
80×80				7.37	8.50	9.61	10.7	11.8
90×90				8.33	9.65	11.90	12.2	13.4
100×100				9.28	10.8	12.20	13.6	15.0

Standard Stainless Steel Channel Bar Dimensions & Weights

Size H×B (mm)	3mm	4mm	5mm	6mm	7mm	8mm	9mm	10mm	12mm
40×20	1.79
50×25	2.27
60×30	2.74	3.56	4.37	5.12
70×35	3.23	4.21	5.17	6.08
80×40	3.71	4.84	5.96	7.03
90×45	4.25	5.55	6.83	8.05
100×50	4.73	6.18	7.62	8.98	10.3	11.7	13.0	41.2
120×60			9.20	10.9	12.6	14.2
130×65			10.1	11.9	13.8	15.5	17.3	19.1
140×70				12.9	14.9	16.8	18.8	20.7
150×75				13.9	16.0	18.1	20.2	22.2	26.3
160×80				14.8	17.1	19.3	21.6	23.8	28.1
180×90				16.7	19.4	22.0	24.5	27.0	32.0
200×100				18.6	21.6	24.5	27.4	30.2	35.8

About Our Company

Our company is a comprehensive stainless steel enterprise specializing in wholesale distribution, material processing, storage, and logistics. Located in Wuxi, a major stainless steel trading hub, we have a total investment of 10 million yuan with annual sales exceeding 300 million yuan.

We maintain long-term partnerships with leading steel mills including Taiyuan, East Steel, Zhang Pu, Hongxing, Zhejiang Qingshan, and others. We also distribute imported stainless steel plates from Sweden, North America, South Africa, Japan, South Korea, and other international sources.

Material Range: 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205-904L, high-temperature stainless steel series, duplex stainless steel series, and super stainless steel series.

Processing Capabilities: Plasma cutting, coil material opening, laser cutting, 8K mirror finishing, grinding, wire drawing, film coating, and titanium plating. We offer slitting, strip cutting, plate cutting, oil mill wire drawing, full coil oil film wire drawing, 8K mirror finishing, and titanium processing.

Specialized Services: Thick plate zero cutting, circular cutting, square cutting, shaped cutting, casting parts, forging parts (up to 150mm thickness). Custom materials and specifications can be ordered directly from steel mills according to customer requirements.

Our materials are widely used in machinery, chemical processing, petroleum, boiler manufacturing, heat exchangers, food machinery, beverage machinery, medical equipment, and various other industries.

Product Gallery

Applications

Stainless steel angle bars and channel bars are primarily used for constructing frame structures, including:

High-voltage power transmission towers
Main beam frames for steel structure bridges
Columns and booms of construction site tower cranes
Workshop columns and beams
Air conditioning and solar panel mounting brackets
Window hanging systems

These structural components are widely used in building construction and engineering projects, including house beams, ship beams, industrial furnaces, and various industrial applications across multiple sectors.
