NM360 NM400 NM450 NM500 Hot Rolled Abrasion Resistant Steel Plate for Metallurgical Machinery
Product Details
| Technique | Hot Rolled | Width Range | 10-2600mm |
|---|---|---|---|
| Thickness Range | 5.0 - 80.0mm | Length Options | 6m, 8m, 10m Or Custom |
| Hardness Range | 450-540 (AR500), 420-500 (AR450), 360-480 (AR400) | Yield Strength | 1250 MPa (AR500), 1200 MPa (AR450), 1000 MPa (AR400), 900 MPa (AR300) |
| Tensile Strength | 1450 MPa (AR500, AR450), 1250 MPa (AR400), 1000 MPa (AR300) | Elongation | 8% (AR500, AR450), 10% (AR400), 11% (AR300) |
| Impact Strength | -30°C (AR500), -40°C (AR450, AR400, AR300) | Carbon Content | 0.30% (AR500), 0.26% (AR450), 0.25% (AR400), 0.18% (AR300) |
| Manganese Content | 1.70% | Chromium Content | 1.00% (AR500, AR450), 1.50% (AR400, AR300) |
| Production Capacity | 50000kgs | Container Size | 20ft: 5.8x2.13x2.18m, 40ft: 11.8x2.13x2.72m |
| Delivery Time | 7-30 Days | ||
| Highlight | NM360 NM400 NM450 NM500 Abrasion Resistant Steel Plate,Hot Rolled Abrasion Resistant Steel Plate,Abrasion Resistant Steel Plate for Metallurgical Machinery |
||
Product Description
Abrasion Resistant Steel Plate for Metallurgical Machinery
High-performance NM360, NM400, NM450, and NM500 abrasion resistant steel plates specifically engineered for demanding applications in metallurgical machinery and heavy industrial environments.
Product Specifications
| Description | Abrasion Resistant Steel Plate |
|---|---|
| HRC | 5.0 - 80.0mm |
| Related Material | NM360, NM400, NM450, NM500, NM550, NM600, AR360, AR400, AR450, AR500, AR600 |
| Thickness | 5mm - 80mm |
| Width | 1500mm, 2000mm, 2200mm |
| Length | 6m, 8m, 10m or custom lengths as requested |
| Price Term | EX-Work, FOB, CFR, CIF |
| Payment Term | T/T, L/C, Western Union |
Chemical Composition
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | B |
|---|---|---|---|---|---|---|---|---|---|
| AR500 | 0.30 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
| AR450 | 0.26 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
| AR400 | 0.25 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.70 | 0.50 | 0.005 |
| AR300 | 0.18 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.40 | 0.50 | 0.005 |
Mechanical Properties
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation A | Impact Strength Charpy V 20J | Hardness Range |
|---|---|---|---|---|---|
| AR500 | 1250 | 1450 | 8 | -30°C | 450-540 |
| AR450 | 1200 | 1450 | 8 | -40°C | 420-500 |
| AR400 | 1000 | 1250 | 10 | -40°C | 360-480 |
| AR300 | 900 | 1000 | 11 | -40°C | - |
Applications by Grade
- AR400: Premium abrasion resistant steel plates with heat treatment and through-hardening. Features improved forming and welding capabilities.
- AR450: Used in applications requiring slightly greater strength beyond AR400 specifications.
- AR500: Ideal for mining, forestry, and construction applications with demanding wear requirements.
- AR600: Utilized in high-wear areas including aggregate removal, mining, and manufacturing of buckets and wear bodies.
Product Benefits
Abrasion resistant steel plates are specifically developed for long service life in harsh conditions. These through-hardened plates offer excellent resistance to sliding and impact abrasion, making them ideal for mining, quarrying, material handling, construction, and earthmoving applications. The high carbon content in the alloy increases hardness and toughness, providing superior performance in high-impact environments.
Shipping & Delivery
| Delivery Time | 7-30 days after order confirmation |
|---|---|
| Packaging | Standard seaworthy export packaging with bundled steel straps. Custom packaging available upon request. |
| Shipping Method | By sea (bulk or container) |
| Shipping Port | Shanghai |
