0.26mm Thickness Zinc Coated Steel Sheet for Building with JIS G3302 Standard and Container Plate Application
Product Details
| Thickness | 0.26mm | Material | Zinc Coated Steel |
|---|---|---|---|
| Sheet Width | 914mm,1000mm,1200mm,1219mm,1220mm,1250mm | Sheet Length | Custom Length |
| Coil Weight | 2Ton - 8 Tons | Coil Inner Diameter | 508mm Or 610mm |
| Zinc Coating | Z30 - Z275 | Aluminum Coating | AZ40 - AZ180 |
| Painting Type | PE,HDP,SMP,PVDF | Surface Finish | Regular Spangle / Non-spangle |
| Sheet Dimensions | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Coating Thickness | 20-25um/5-10um |
| Coating Layers | Above 2 Layer, Bottom 1 Layer | Heat Resistance | 300 Degrees Celsius |
| Standard | JIS G3302 | ||
| Highlight | 0.26mm Thickness Zinc Coated Steel Sheet,JIS G3302 Standard Galvanized Steel Sheet,Container Plate Application Prepainted Galvanized Steel Sheet |
||
Product Description
0.26mm Thickness Zinc Coated Steel Sheet Metal for Building JIS G3302 Standard
Product Specifications
| Products Name | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
|---|---|
| Thickness | Galvanized steel sheet: 0.12 - 3.0mm Galvalume Steel Sheet: 0.25 - 3.0mm Prepainted Galvanized Steel Sheet: 0.12 - 1.2mm |
| Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom requirements |
| Length | Custom length as per customer requirements |
| Coil Weight | 2 - 8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface | Galvanized steel sheet: Regular spangle / non-spangle Zinc: Z30 - Z275 Galvalume Steel Sheet: AZ40 - AZ180 Prepainted Galvanized Steel Sheet: PE, HDP, SMP, PVDF coatings |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, AS, etc. |
Prepainted Galvanized Steel Coil
Prepanited galvanized steel coil, also known as PPGI or color plate, is manufactured using cold rolled steel plate and galvanized steel plate as base materials. After surface pretreatment including degreasing, cleaning, and chemical conversion treatment, the coating is applied continuously using the roller coating method, followed by baking and cooling processes.
The coated steel plate offers lightweight construction, attractive appearance, and excellent anti-corrosion performance. It can be directly processed and serves as an innovative raw material for the construction industry, shipbuilding industry, vehicle manufacturing, home appliances, electrical industry, and more. This product effectively replaces wood with steel, enabling efficient construction while conserving energy and preventing pollution.
Galvanized Steel Coil
Galvanized sheet refers to steel plate with zinc coating on the surface. Galvanizing represents an economical and effective rust prevention method, with approximately half of the world's zinc production utilized for this process.
Surface Requirements:
- Surface state varies based on coating process treatments: regular spangle, small spangle, big spangles, etc.
- Galvanized sheet must exhibit good appearance without defects affecting product use
- No plating defects, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, or white rust permitted
- Specific appearance defects should be specified in ordering contracts
Galvalume Steel Coil
Galvalume steel sheet consists of an aluminized zinc alloy structure composed of 55% aluminum, 43% zinc, and 2% silicon solidified at 600ºC. The complete structure features aluminized iron, silicon, and zinc forming dense tetrad junction crystals.
This product offers superior corrosion resistance - three times that of pure galvanized sheet - with decorative zinc flower patterns suitable for building exterior panels. The corrosion protection primarily derives from aluminum's protective functionality.
Galvalume steel sheet demonstrates excellent heat resistance, withstanding temperatures exceeding 300 degrees Celsius. Its high-temperature oxidation resistance resembles aluminum-plated steel plate, making it ideal for chimney tubes, ovens, illuminators, and solar lampshades.
Pattern Print Prepainted Steel Sheet
| Products | Pattern print prepainted steel sheet |
|---|---|
| Introduction | Color plate printed on galvanized plate, aluminized zinc plate and other substrates using transfer printing or film covering technology |
| Features | Wide application range including marble grain, camouflage, wood grain printing with bright colors and diverse varieties |
| Size | Thickness: 0.17 - 1.5mm, Width less than 1.5mm |
| Color and Pattern | Customized according to client requirements |
| Base Material | Galvanized steel sheet / Galvalume steel sheet |
| Coating Thickness | 20-25um/5-10um |
| Coating Type | Above 2 layers, bottom 1 layer |
| Coil ID | Φ510mm/610mm |
| Application | Household appliances, furniture, doors and windows, indoor and outdoor decoration |
Trade Information
| MOQ | 5 Tons |
|---|---|
| Payment Term | TT or 100% LC at sight |
| Packing | Standard Sea Worthy Package |
| Loading Port | Shanghai Port, Qingdao Port, Tianjin Port |
| Container Loading | 20ft container FCL, LCL |
| Delivery Time | Within 15 days |
Company Information
Our company is a modern enterprise specializing in high-end coating plate processing, sales, and circulation, registered in Wuxi City. We manufacture premium products including color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.
We maintain excellent cooperative relationships with several major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, and Jiangyin ZongCheng Steel. Our products are extensively used in steel structure buildings, metal building materials, steel silos, ventilation pipes, mechanical and electrical housing, home appliance plates, elevators, purification plates, automotive stamping parts, and related fields.
Since establishment, our company has collaborated with factories to provide material supply and technical services for numerous medium and large engineering projects domestically and internationally. Our employees average over 8 years of industry experience, enabling us to develop customized supply solutions that enhance supply chain efficiency as your optimal partner.
Moving forward, we remain committed to our core value of sustainable development, dedicated to providing customers with perfect demand solutions. Jiufu International will continue working with domestic and foreign clients to establish ourselves as China's premier high-end coating and plating steel products service provider.
