DX51D RAL Zinc Coated Prepainted PPGI Steel Coil for Container Plate Applications
Product Details
| Thickness | 0.12 - 3.0mm (Galvanized), 0.25 - 3.0mm (Galvalume), 0.12 - 1.2mm (Prepainted) | Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm Or Custom |
|---|---|---|---|
| Length | Custom Length | Coil Weight | 2Ton - 8 Tons |
| Coil Inner Diameter | 508mm Or 610mm | Zinc Coating | Z30 - Z275 |
| Aluminum-Zinc Coating | AZ40 - AZ180 | Painting Type | PE, HDP, SMP, PVDF |
| Surface Finish | Regular Spangle, Non-spangle, Or Custom | Coating Thickness | 20-25um/5-10um (Prepainted) |
| Coating Layers | Above 2 Layer, Bottom 1 Layer | Pattern Print Thickness | 0.17 - 1.5mm |
| Heat Resistance | >300°C (Galvalume) | Edge Type | Slit Edge |
| Sheet Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | ||
| Highlight | DX51D PPGI Steel Coil,RAL Zinc Coated PPGI Steel Coil,Container Plate Prepainted Galvanized Steel Coil |
||
Product Description
CGCC DX51D RAL Zinc Coated Prepainted PPGI Steel Coil
High-quality prepainted galvanized steel coil with zinc coating and RAL color standards for superior corrosion resistance and aesthetic appeal.
Product Specifications
| Products Name | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
|---|---|
| Thickness |
Galvanized steel sheet: 0.12 - 3.0mm Galvalume Steel Sheet: 0.25 - 3.0mm Prepainted Galvanized Steel Sheet: 0.12 - 1.2mm |
| Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom requirements |
| Length | Custom length as per customer requirements |
| Coil Weight | 2 - 8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface |
Galvanized steel sheet: Regular spangle / non-spangle Zinc: Z30 - Z275 Galvalume Steel Sheet: AZ40 - AZ180 Prepainted Galvanized Steel Sheet: Painting Type: PE, HDP, SMP, PVDF |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, AS, etc. |
Products Center
Prepainted Galvanized Steel Coil (PPGI)
Color coated steel plate manufactured using cold rolled steel plate and galvanized steel plate as base materials. After surface pretreatment including degreasing, cleaning, and chemical conversion treatment, the coating is applied using continuous roller coating method followed by baking and cooling processes.
Features lightweight construction, attractive appearance, and excellent anti-corrosion performance. Suitable for direct processing applications in construction industry, shipbuilding, vehicle manufacturing, home appliances, electrical industry, and more. Provides efficient steel-for-wood substitution, rapid construction, energy conservation, and pollution prevention.
Galvanized Steel Coil
Steel sheet with zinc-coated surface providing economical and effective rust prevention. Approximately half of global zinc production is utilized for galvanization processes.
Surface specifications include various states such as regular spangle, small spangle, and big spangles depending on coating process treatments. Products feature excellent appearance quality free from defects including no plating, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, and white rust.
Galvalume Steel Coil
Alloy composition of 55% aluminum, 43% zinc, and 2% silicon solidified at 600°C. Structure consists of aluminized iron, silicon, and zinc forming dense tetrad junction crystal.
Offers superior corrosion resistance - three times greater than pure galvanized sheet. Features decorative zinc flower surface pattern suitable for building exterior panels. Aluminum component provides primary protective function. Excellent heat resistance withstands temperatures exceeding 300°C, similar to aluminum plated steel plate high temperature oxidation resistance. Commonly used in chimney tubes, ovens, illuminators, and solar lampshades.
Featured Products
| Products | Pattern Print Prepainted Steel Sheet |
|---|---|
| Introduction | Color plate printed on galvanized plate, aluminized zinc plate and other substrates using transfer printing or film covering technology |
| Features | Main applications include marble grain, camouflage, wood grain printing color board with bright colors and extensive variety |
| Size | Thickness: 0.17 - 1.5mm Width less than 1.5mm |
| Color and Pattern | Customized according to client requirements |
| Base Material | Galvanized steel sheet / Galvalume steel sheet |
| Coating Thickness | 20-25um/5-10um |
| Coating Type | Above 2 layers, bottom 1 layer |
| Coil ID | Φ510mm/610mm |
| Application | Widely used in household appliances, furniture, doors and windows, indoor and outdoor decoration and other fields |
Trade Information
| MOQ | 5 Tons |
|---|---|
| Payment Term | TT or 100% LC at sight |
| Packing | Standard Sea Worthy Package |
| Loading Port | Shanghai Port, Qingdao Port, Tianjin Port |
| Container Loading | 20ft container FCL, LCL |
| Delivery Time | Within 15 days |
Company Information
Our company is a modern enterprise specializing in high-end coating plate processing, sales, and circulation, registered in Wuxi city. Core products include color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.
We maintain strong cooperative relationships with major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, and Jiangyin ZongCheng Steel. Products are extensively applied in steel structure building, metal building materials, steel silo, ventilation pipes, mechanical and electrical housing, home appliance plate, elevator, purification plate, automotive stamping parts and related fields.
Since establishment, we have collaborated with factories to provide material supply and technical services for numerous medium and large engineering projects domestically and internationally. Our employees average over 8 years of industry experience, enabling customized supply solutions and enhanced supply chain efficiency.
Committed to the value concept of sustainable development, we focus on providing perfect demand solutions while working with domestic and international customers to establish ourselves as China's premier high-end coating and plating steel products service provider.
