Corrosion Resistant 316LN Stainless Steel Sheet and Plate with 1.0 - 80.0mm Thickness for Chemical Processing
Product Details
| Model NO. | 316LN | Shape | Flat |
|---|---|---|---|
| Technique | Hot Rolled | Surface Treatment | Pickling |
| Thickness | 1.0 - 80.0mm | Process | Cutting |
| Quality | Class 1 | Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm |
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316LN, 316TI, 317L, 321, 321H, 347, 348, 409, 410, 410S, 420, 430, 441, 904L, 630, 631, 254SMO, 654SMO, 253MA, 2205, 2304, 2507 | Width | 1250mm, 1500mm, 1800mm, 2000mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm | Form | Plate / Sheet |
| Cutting Shape | Round, Square | Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA |
| Chemical Composition | Fe (Balance), Cr (16.00-18.00%), Ni (10.00-14.00%), Mo (2.00-3.00%), Mn (2.00% Max), Si (1.00% Max), P (0.045% Max), S (0.030% Max), N (0.10-0.16%), C (0.03% Max) | ||
| Highlight | Corrosion Resistant 316LN Stainless Steel Sheet,1.0 - 80.0mm Thickness 316LN Stainless Steel Plate,Chemical Processing 316LN SS Sheet |
||
Product Description
Durable 316LN Stainless Steel Sheet & Plate
High-performance stainless steel sheets and plates with thickness range 1.0 - 80.0mm, specifically engineered for demanding chemical processing applications.
Product Specifications
| Products Name | 316LN Stainless Steel Plate Sheet |
|---|---|
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316LN, 316TI, 317L, 321, 321H, 347, 348, 409, 410, 410S, 420, 430, 441, 904L, 630, 631, 254SMO, 654SMO, 253MA, 2205, 2304, 2507, etc. |
| Thickness | 0.6 - 80.0mm |
| Width | 1250mm, 1500mm, 1800mm, 2000mm, or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER'S REQUIREMENT |
| Service | Laser Cutting |
| Form | Plate / sheet |
| Cutting Shape | Round, Square, or any special shape as request |
| Test Certificate | Yes |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA |
| Brand | TISCO, LISCO, BAOSTEEL, POSCO, JISCO |
Material Description
316LN stainless steel is an enhanced version of standard 316 stainless steel, specifically alloyed with nitrogen to provide superior performance in critical applications. This versatile material offers high strength, excellent corrosion resistance, and improved mechanical properties.
Chemical Composition
| Element | % by Weight |
|---|---|
| Iron (Fe) | Balance |
| Chromium (Cr) | 16.00 - 18.00% |
| Nickel (Ni) | 10.00 - 14.00% |
| Molybdenum (Mo) | 2.00 - 3.00% |
| Manganese (Mn) | 2.00% max |
| Silicon (Si) | 1.00% max |
| Phosphorus (P) | 0.045% max |
| Sulfur (S) | 0.030% max |
| Nitrogen (N) | 0.10 - 0.16% |
| Carbon (C) | 0.03% max |
Product Features
- Corrosion Resistance: Superior resistance to pitting, crevice corrosion, and general corrosion, particularly effective against sulfuric and hydrochloric acids
- High Strength & Durability: Higher tensile and yield strength compared to standard 304 stainless steel with excellent strength retention at high temperatures
- Enhanced Weldability: Low carbon content reduces risk of carbide precipitation during welding, minimizing corrosion potential
- Excellent Toughness at Low Temperatures: Maintains reliable performance in cryogenic and subzero conditions
- Resistance to Chloride Stress Corrosion Cracking: Nitrogen addition provides crucial protection in high-chloride environments
- Easy Formability and Fabrication: Excellent processability for machining and fabrication into custom components
Production Process
- Melting and Alloying: Raw materials melted in electric arc furnace with precise alloying element addition
- Casting: Alloy cast into billets or slabs for cooling and solidification
- Hot Rolling: Slabs heated and passed through rollers to achieve desired thickness and improve mechanical properties
- Cold Rolling: Fine-tuning dimensions and surface finish while enhancing strength and hardness
- Annealing: Furnace treatment to relieve internal stresses and improve ductility and corrosion resistance
- Pickling & Passivation: Acid treatment to remove scale and impurities, followed by protective oxide layer formation
- Cutting & Finishing: Custom sizing based on specifications with quality inspection and final finishing
Applications
- Chemical Processing: Storage tanks, pipes, reactors, and heat exchangers for handling aggressive chemicals
- Pharmaceutical Industry: Mixers, reactors, and containers for sensitive substance processing
- Marine & Offshore Applications: Ship hulls, offshore platforms, and piping systems exposed to seawater
- Aerospace: Exhaust systems, airframes, and fuel systems requiring extreme temperature endurance
- Food Processing: Machinery, pipes, and containers where hygiene and non-reactivity are paramount
- Architectural Applications: Exterior cladding, handrails, and facades with atmospheric corrosion resistance
Export Packaging
- Wooden Pallets: Secure packing on ISPM 15 compliant pallets to prevent shifting during transportation
- Plastic Wrapping & Shrink Film: High-quality film protection against moisture, dust, and handling damage
- Corrosion Protection: Additional inhibitors for long-distance transportation in humid environments
- Custom Markings: Clear product details including material grade, size, and weight for easy identification
- Shipping Containers: Sturdy, labeled containers to prevent damage during international transit
316LN stainless steel sheets and plates are engineered to meet the toughest requirements in chemical processing, marine, aerospace, and various industrial applications. With superior corrosion resistance, high strength, and versatile formability, our 316LN products provide long-lasting performance and value for critical applications.
