SS 316L Stainless Steel Angle Bar NO1 Finished 30*30-100*100mm for Engineering Structure
Product Details
| Shape | U Channel | Technique | Hot Rolled |
|---|---|---|---|
| Surface Treatment | Bright | Specification | 30*30-100*100 |
| Grade | 201 304 310S 316L 321 2205 | Angle Bar Size | 30*30*3 - 200*200*10mm * 6m Length |
| Channel Bar Size | 50*30*3 - 200*100*10mm * 6m Length | Angle Bar Thickness | 3-10mm |
| Channel Bar Thickness | 3-12mm | Angle Bar Weight | 0.894-15.0 Kg/m |
| Channel Bar Weight | 1.79-35.8 Kg/m | Material | Stainless Steel |
| Standard | ASTM GB DIN | Length | 6m |
| Packing | Waterproof Paper Or Wooden Pallets | ||
| Highlight | SS 316L Stainless Steel Angle Bar,NO1 Finished Stainless Steel Channel Bar,30*30-100*100mm U Channel Bar |
||
Product Description
SS 316L Angle Bar - NO1 Finished for Engineering Structures
High-quality stainless steel angle bars and channel bars designed for robust engineering applications and structural frameworks.
Product Specifications
Product Name: Stainless Steel Angle Bar / Stainless Steel Channel Bar
Grades Available: 201, 304, 310S, 316L, 321, 2205, etc.
Standards: ASTM, GB, DIN
Angle Bar Size Range: 30×30×3mm - 200×200×10mm × 6m length
Channel Bar Size Range: 50×30×3mm - 200×100×10mm × 6m length
Services: Custom Cutting
Packing: Waterproof paper wrapping or wooden pallets
Brand: TSINGSHAN
Stainless Steel Angle Bar - Standard Sizes & Weights
| Size A×B (mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm |
|---|---|---|---|---|---|---|---|---|
| 20×20 | 0.894 | 1.13 | 1.38 | |||||
| 25×25 | 1.13 | 1.45 | 1.77 | 2.06 | ||||
| 30×30 | 1.37 | 1.77 | 2.17 | 2.53 | ||||
| 35×35 | 1.61 | 2.09 | 2.57 | 3.01 | ||||
| 40×40 | 1.85 | 2.41 | 2.97 | 3.49 | ||||
| 45×45 | 2.12 | 2.76 | 3.40 | 4.00 | ||||
| 50×50 | 2.36 | 3.07 | 3.79 | 4.46 | 5.13 | 5.76 | 6.42 | 7.06 |
| 60×60 | 4.58 | 5.42 | 6.24 | 7.03 | ||||
| 63×63 | 5.03 | 5.95 | 6.84 | 7.71 | 8.60 | 9.48 | ||
| 70×70 | 5.42 | 6.42 | 7.39 | 8.34 | 9.31 | 10.3 | ||
| 75×75 | 5.82 | 6.89 | 7.95 | 8.97 | 10.0 | 11.1 | ||
| 80×80 | 7.37 | 8.50 | 9.61 | 10.7 | 11.8 | |||
| 90×90 | 8.33 | 9.65 | 11.90 | 12.2 | 13.4 | |||
| 100×100 | 9.28 | 10.8 | 12.20 | 13.6 | 15.0 |
Weight values shown in kg/m
Stainless Steel Channel Bar - Standard Sizes & Weights
| Size H×B (mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm | 12mm |
|---|---|---|---|---|---|---|---|---|---|
| 40×20 | 1.79 | ||||||||
| 50×25 | 2.27 | ||||||||
| 60×30 | 2.74 | 3.56 | 4.37 | 5.12 | |||||
| 70×35 | 3.23 | 4.21 | 5.17 | 6.08 | |||||
| 80×40 | 3.71 | 4.84 | 5.96 | 7.03 | |||||
| 90×45 | 4.25 | 5.55 | 6.83 | 8.05 | |||||
| 100×50 | 4.73 | 6.18 | 7.62 | 8.98 | 10.3 | 11.7 | 13.0 | 41.2 | |
| 120×60 | 9.20 | 10.9 | 12.6 | 14.2 | |||||
| 130×65 | 10.1 | 11.9 | 13.8 | 15.5 | 17.3 | 19.1 | |||
| 140×70 | 12.9 | 14.9 | 16.8 | 18.8 | 20.7 | ||||
| 150×75 | 13.9 | 16.0 | 18.1 | 20.2 | 22.2 | 26.3 | |||
| 160×80 | 14.8 | 17.1 | 19.3 | 21.6 | 23.8 | 28.1 | |||
| 180×90 | 16.7 | 19.4 | 22.0 | 24.5 | 27.0 | 32.0 | |||
| 200×100 | 18.6 | 21.6 | 24.5 | 27.4 | 30.2 | 35.8 |
Weight values shown in kg/m
About Our Company
Our company is a comprehensive stainless steel enterprise specializing in wholesale distribution, material processing, storage, and logistics. Located in Wuxi - the stainless steel trading hub - with total investments exceeding 10 million yuan and annual sales over 300 million yuan.
Strategic Partnerships
We maintain long-term cooperative relationships with leading steel mills including Taiyuan Steel, East Steel, Zhang Pu Steel, Hongxing Steel, Zhejiang Qingshan, and distribute imported stainless steel plates from Sweden, North America, South Africa, Japan, and Korea.
Material Portfolio
Our product range includes 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205, 904L, high-temperature resistant stainless steel series, duplex stainless steel series, and super stainless steel series.
Processing Capabilities
- Plasma cutting machines
- Coil material opening equipment
- Laser cutting machines
- 8K mirror finishing
- Grinding and wire drawing
- Film coating and titanium plating
- Thick plate cutting up to 150mm thickness
- Custom cutting of rounds, squares, and shaped components
Industry Applications
Our materials serve diverse industries including machinery, chemical processing, petroleum, boilers, heat exchangers, food machinery, beverage equipment, and medical devices.
Product Gallery
Industrial Applications
Stainless steel angle bars and channel bars are essential components for constructing robust frame structures across multiple industries:
- High-voltage power transmission towers
- Steel structure bridge frameworks
- Tower crane columns and booms on construction sites
- Industrial workshop columns and beams
- Air-conditioning and solar power mounting systems
- Building structures and engineering construction
- Ship building frameworks
- Industrial furnace structures
Our stainless steel angle bars and channel bars deliver reliable performance across all industrial applications, providing structural integrity, corrosion resistance, and long-term durability.
