Hot Rolled Pickling Surface Treatment Stainless Steel Channel Bar U Channel 30*30-100*100mm
Product Details
| Shape | U Channel | Technique | Hot Rolled |
|---|---|---|---|
| Surface Treatment | Pickling | Specification | 30*30-100*100 |
| Grade | 201 304 310S 316L 321 2205 | Angle Bar Size | 30*30*3 - 200*200*10mm * 6m |
| Channel Bar Size | 50*30*3 - 200*100*10mm * 6m | Angle Bar Thickness | 3-10mm |
| Channel Bar Thickness | 3-12mm | Angle Bar Weight | 0.894-15.0 Kg/m |
| Channel Bar Weight | 1.79-35.8 Kg/m | Standard | ASTM GB DIN |
| Length | 6m | Material | Stainless Steel |
| Service | Cutting | ||
| Highlight | Hot Rolled Stainless Steel Channel Bar,Pickling Surface Treatment Stainless Steel U Channel,30*30-100*100mm Stainless Steel C Channel |
||
Product Description
Factory Direct Stainless Steel Channel Bars, Angle Bars & Flat Bars
Premium quality 201, 304, and 316L stainless steel structural profiles available at competitive factory prices.
Product Specifications
Product Types: Stainless Steel Angle Bar / Stainless Steel Channel Bar
Available Grades: 201, 304, 310S, 316L, 321, 2205, and more
Standards: ASTM, GB, DIN
Angle Bar Sizes: 30×30×3mm to 200×200×10mm × 6m length
Channel Bar Sizes: 50×30×3mm to 200×100×10mm × 6m length
Services: Custom cutting available
Packaging: Waterproof paper wrapping or wooden pallets
Brand: TSINGSHAN
Stainless Steel Angle Bar Specifications
| Size A×B (mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm |
|---|---|---|---|---|---|---|---|---|
| 20×20 | 0.894 | 1.13 | 1.38 | |||||
| 25×25 | 1.13 | 1.45 | 1.77 | 2.06 | ||||
| 30×30 | 1.37 | 1.77 | 2.17 | 2.53 | ||||
| 35×35 | 1.61 | 2.09 | 2.57 | 3.01 | ||||
| 40×40 | 1.85 | 2.41 | 2.97 | 3.49 | ||||
| 45×45 | 2.12 | 2.76 | 3.40 | 4.00 | ||||
| 50×50 | 2.36 | 3.07 | 3.79 | 4.46 | 5.13 | 5.76 | 6.42 | 7.06 |
| 60×60 | 4.58 | 5.42 | 6.24 | 7.03 | ||||
| 63×63 | 5.03 | 5.95 | 6.84 | 7.71 | 8.60 | 9.48 | ||
| 70×70 | 5.42 | 6.42 | 7.39 | 8.34 | 9.31 | 10.3 | ||
| 75×75 | 5.82 | 6.89 | 7.95 | 8.97 | 10.0 | 11.1 | ||
| 80×80 | 7.37 | 8.50 | 9.61 | 10.7 | 11.8 | |||
| 90×90 | 8.33 | 9.65 | 11.90 | 12.2 | 13.4 | |||
| 100×100 | 9.28 | 10.8 | 12.20 | 13.6 | 15.0 |
* All weights shown in kg per meter
Stainless Steel Channel Bar Specifications
| Size H×B (mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm | 12mm |
|---|---|---|---|---|---|---|---|---|---|
| 40×20 | 1.79 | ||||||||
| 50×25 | 2.27 | ||||||||
| 60×30 | 2.74 | 3.56 | 4.37 | 5.12 | |||||
| 70×35 | 3.23 | 4.21 | 5.17 | 6.08 | |||||
| 80×40 | 3.71 | 4.84 | 5.96 | 7.03 | |||||
| 90×45 | 4.25 | 5.55 | 6.83 | 8.05 | |||||
| 100×50 | 4.73 | 6.18 | 7.62 | 8.98 | 10.3 | 11.7 | 13.0 | 41.2 | |
| 120×60 | 9.20 | 10.9 | 12.6 | 14.2 | |||||
| 130×65 | 10.1 | 11.9 | 13.8 | 15.5 | 17.3 | 19.1 | |||
| 140×70 | 12.9 | 14.9 | 16.8 | 18.8 | 20.7 | ||||
| 150×75 | 13.9 | 16.0 | 18.1 | 20.2 | 22.2 | 26.3 | |||
| 160×80 | 14.8 | 17.1 | 19.3 | 21.6 | 23.8 | 28.1 | |||
| 180×90 | 16.7 | 19.4 | 22.0 | 24.5 | 27.0 | 32.0 | |||
| 200×100 | 18.6 | 21.6 | 24.5 | 27.4 | 30.2 | 35.8 |
* All weights shown in kg per meter
About Our Company
We are a comprehensive stainless steel enterprise specializing in wholesale distribution, material processing, storage, and logistics. Located in Wuxi - the stainless steel trading hub - with total investment of 10 million yuan and annual sales exceeding 300 million yuan.
Manufacturing Partnerships
We maintain long-term cooperative relationships with leading steel mills including Taiyuan Steel, East Steel, Zhang Pu Steel, Hongxing Steel, Zhejiang Qingshan, and others. We also distribute imported stainless steel plates from Sweden, North America, South Africa, Japan, and South Korea.
Material Range & Processing Capabilities
- Material Grades: 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205, 904L
- Specialty Series: High-temperature resistant, duplex stainless steel, and super stainless steel
- Processing Equipment: Plasma cutting, coil material opening, laser cutting, 8K mirror finishing, grinding, wire drawing, film and titanium plating
- Specialized Services: Thick plate cutting (up to 150mm), custom shapes, casting parts, forging parts
Industry Applications: Machinery, chemical processing, petroleum, boilers, heat exchangers, food machinery, beverage equipment, medical devices, and more.
Product Gallery
Applications
Stainless steel angle bars and channel bars are essential structural components used in:
- Frame structures for high-voltage power transmission towers
- Main beam frameworks for steel structure bridges
- Columns and booms for construction site tower cranes
- Workshop columns and beams
- Air conditioning and solar panel mounting systems
- Building structures and engineering construction
- Ship beams and industrial furnace construction
Our stainless steel angle bars and channel bars serve diverse applications across multiple industries including construction, marine, industrial, and renewable energy sectors.
